17-28 HP Forced Circulation Diesel Engines
17-28 HP强制循环柴油发动机
| 型号。 | 1105 1110 1115td km138 ld28 |
| 速度 | 速度 |
| 进气压力脉冲 | 自然吸气 |
| 汽油 | 柴油，柴油发动机 |
| 气缸排列形式 | H |
| 马力25HP： | 速度：2200R /分钟 |
| 规范 | ISO9001质量认证; |
| HS编码 | 84089091 |
| 点火模式 | 压缩点火 |
| 冷却气瓶 | 水冷 |
| 活塞运动 | 往复式 |
| 中风次数 | 四条线 |
| 气缸数 | 单缸机 |
| 商标 | LD |
| 起源 | 中国山东莱阳 |
17-28 HP强制循环柴油发动机
产品描述：1105系列TD型柴油机：直喷，易启动;技术成熟，兼容性好，
适用于拖拉机，农用运输机械，发电机组，抽水机组，小型系列1105 TD型柴油机：直喷，起动方便;技术成熟，兼容性好
适用范围适用于缺水区域
产品参数
| 型号。 | 燃烧形式 | 眼睛×中风中风 Stroke （毫米×毫米）MES;毫米）mes;mm) | 移位 (L) | 额定功率（kW）/额定转速（r / min） | 最大。扭矩（Nm）/额定转速（r / min） | 闵。比燃耗（g / kW.h） | 尺寸（mm） |
| 1105td | 直接注射 | 105×115mes; 115mes;115 | 0.996 | 13.2/2200 | 64.2/1650 | 242 | 781×432×668432×668es;668432×668 |
| 1110td | 直接注射 | 110×115mes; 115mes;115 | 1.093 | 14.7/2200 | 71.5/1650 | 242 | 781×432×668432×668es;668432×668 |
| 1115td | 直接注射 | 115×115mes; 115mes;115 | 1.194 | 16.2/2200 | 78.8/1650 | 242 | 781×432×668432×668es;668432×668 |
| ld24td | 直接注射 | 115×118mes; 118mes;118 | 1.225 | 17/2200 | 82.7/1650 | 242 | 781×432×668432×668es;668432×668 |
| km130td | 直接注射 | 118×118mes; 118mes;118 | 1.29 | 17.6/2200 | 85.8/1650 | 242 | 781×432×668432×668es;668432×668 |
| km138td | 直接注射 | 122×118mes; 118mes;118 | 1.38 | 18.38/2200 | 89.4/1650 | 242 | 781×432×668432×668es;668432×668 |
| ld28td | 直接注射 | 125×118mes; 118mes;118 | 1.448 | 20.2/2200 | 98.2/1650 | 242 | 781×432×668432×668es;668432×668 |
| Model NO. | 1105 1110 1115TD KM138 LD28 |
| Speed | Speed |
| Intake Pressure Impulse | Naturally Aspirated |
| Fuel | Diesel, Diesel Engine |
| Cylinder Arrangement Form | H |
| Horse Power 25HP: | Speed:2200r/Min |
| Specification | ISO9001 Quality Certificate; |
| HS Code | 84089091 |
| Ignition Mode | Compression-Ignition |
| Cooling Cylinder | Water-Cooled |
| Piston Movement | Reciprocating |
| Number of Strokes | Four-Stroke |
| Number of Cylinders | Single-Cylinder Machine |
| Trademark | LD |
| Origin | Laiyang, Shandong, China |
17-28 HP forced circulation diesel engines
Product Description:Series 1105 TD-type diesels: Direct injection, easy start; mature technology, well compatibility,
Adaptable for tractors, agricultural transport machinery, generating sets, pumping units, small-sized series 1105 TD-type diesels: Direct-injection, easy start; mature technology, great compatibility
Scope of application:Suitable for area that short of water
Product Parameters
| Model No. | Form of combustion | Bore × Stroke Stroke Stroke (mm×mm)mes;mm)mes;mm) | Displacement (L) | Rated Power (kW)/Rated speed (r/min) | Max. Torque (N.m)/Rated speed (r/min) | Min. specific fuel-consumption (g/kW.h) | Dimension(mm) |
| 1105TD | Direct injection | 105×115mes;115mes;115 | 0.996 | 13.2/2200 | 64.2/1650 | 242 | 781×432×668432×668es;668432×668 |
| 1110TD | Direct injection | 110×115mes;115mes;115 | 1.093 | 14.7/2200 | 71.5/1650 | 242 | 781×432×668432×668es;668432×668 |
| 1115TD | Direct injection | 115×115mes;115mes;115 | 1.194 | 16.2/2200 | 78.8/1650 | 242 | 781×432×668432×668es;668432×668 |
| LD24TD | Direct injection | 115×118mes;118mes;118 | 1.225 | 17/2200 | 82.7/1650 | 242 | 781×432×668432×668es;668432×668 |
| KM130TD | Direct injection | 118×118mes;118mes;118 | 1.29 | 17.6/2200 | 85.8/1650 | 242 | 781×432×668432×668es;668432×668 |
| KM138TD | Direct injection | 122×118mes;118mes;118 | 1.38 | 18.38/2200 | 89.4/1650 | 242 | 781×432×668432×668es;668432×668 |
| LD28TD | Direct injection | 125×118mes;118mes;118 | 1.448 | 20.2/2200 | 98.2/1650 | 242 | 781×432×668432×668es;668432×668 |
