Hot Sale Transparent LED Display High Brightness for Window/Building Video Wall

Hot Sale Transparent LED Display High Brightness for Window/Building Video Wall

热销透明LED显示屏高亮度的窗/建筑视频墙

1850-2100 USD

加入意向
型号。 P15.625
IP等级 IP65
像素配置 1r,1g,1b
平均功耗 288瓦特/平方米
扫描模式 静态恒流
应用 广告
寿命 10万小时
工厂价格 可得到
规范 ce,rohs,emc,ccc,
管芯颜色 饱满的色彩
像素间距 15.625毫米
显示功能 视频显示
像素密度 4096dots / M2
显示类型 LED视频显示
证明 ce,rohs,ccc
保证 2年
商标 英雄
起源 中国广东省深圳市
热卖透明LED显示器高亮度的窗/建筑视频墙
规范:

零件号

英雄-OD

解析度

32(H)×8(v)的ES; 8(v)的es;8(V)

像素间距

15.625毫米

LED配置

1r1g1b smd3535

像素密度
4096像素/平方米

模块尺寸
500 *125毫米

驱动IC

MBI5024

驾驶方法

静态扫描,恒定电流

机柜重量

16公斤/平方米。

机械等级

悬挂重量支持

2T

表面平整度

±0.25smn; 0.25smn;0.25

光学等级

亮度

5500〜6500cd / m2

视角

140°/ 140°/ 140°deg;/140°

灰度

16位

显示颜色

281万亿

亮度调整

0~100%

电源

操作电源

ac220v / 50hz或ac110v / 60hz

最大。能量消耗

7200W / m2

平均功耗

288W / m2

控制系统

控制模式

DVI同步显示控制PC

帧更新频率

60-85hz

屏幕刷新频率
300-1000hz

伽玛校正

-5.0~+5.0

支持输入

复合,S视频,组件,VGA,DVI,HDMI,HD_SDI

控制距离

以太网电缆<120m or Fiber Optic<10Kmlt;10Km

支持VGA模式

1024x768,1280x1024,1600x1200,1920x1280

亮度校正

像素,模块,机柜

环境的

工作温度

-20°〜+ 60°〜+ 60°deg;~+60°

工作湿度

10〜95%rh

使用寿命

100000小时

MTBF

万小时

防护等级

~

失控率

<0.02%

描述:
高透明度在80%以上,可以从内到外看清楚。
2.重量轻,约12kg / m2,玻璃壁几毫米,厚度10mm,占用空间小。
3.安装方便,维修方便,安全稳定。
4.与LED照明产品相比,具有更好的广告效益,节省了大量成本,不会改变建筑外观。
5.节能,无需冷却系统和空调,散热和抗氧化保护。
6.易于操作同步控制,程序可随时更改。
使用范围广:
可广泛应用于商店窗口广告和建筑视频墙和玻璃墙后面的任何地方。
包装运输:
专业包装:木箱或飞行箱。
包装方式可以防止LED屏幕在运输过程中的碰撞,如损坏等。
无故解决您在运输中的烦恼。
关于英雄:
LED屏幕7年的经验,我厂具有加工,研发LED显示屏的能力,确保多样化。严格的质量控制流程,确保LED显示屏具有高品质。
售后服务:
1)保修:
免费解决质量问题,确保设备在保修期内正常运行。在任何时候,我们承担所有的责任,当问题来自产品本身。
2)免费维护:
保修期内免费保修。
仅在保修期内收取原材料成本,提供最低价格的备件和维修服务。
3)快速反应:
2小时内响应,24小时内无人为故障,一般故障解决,48小时内可接受故障解决。
4)免费支持:
通过电话或网络实时提供服务支持,或借助网络进行远程调试支持(软件),解决问题。
官员网站:http://www.led-hero.com
Model NO. P15.625
IP Rating IP65
Pixel Configuration 1R, 1G, 1B
Average Power Consumption 288W/M2
Scanning Mode Static Constant Current
Application Advertising
Lifespan 100,000 Hours
Factory Price Available
Specification CE, ROHS, EMC, CCC,
Tube Chip Color Full Color
Pixel Pitch 15.625mm
Display Function Video Display
Pixel Density 4096dots/M2
Display Type LED Video Display
Certification CE, RoHS, CCC
Warranty 2 Years
Trademark HERO
Origin Shenzhen City, Guangdong Province, China
Hot sale Transparent LED Display High Brightness for Window/Building Video Wall
specification:

Part Number

HERO-OD

Resolution

32(H)×8(V)es;8(V)es;8(V)

Pixel Pitch

15.625mm

LED Configuration

1R1G1B SMD3535

Pixel Density
4096pixels/ m2

Module Size
500*125mm

Driving IC

MBI5024

Driving Method

Static Scan, Constant Current

Cabinet Weight

16kg/sq.m.

Mechanical Ratings

Hanging Weight Support

2T

Surface Flatness

±0.25smn;0.25smn;0.25

Optical Ratings

Brightness

5500~6500cd/ m2

View Angle

140°/140°/140°deg;/140°

Gray Scale

16bits

Display COLOR

281 trillion

Brightness Adjustment

0~100%

Power Supply

Operation Power

AC220V/50HZ or AC110V/60Hz

Max. Power Consumption

7200W/ m2

Average Power Consumption

288W/ m2

Control System

Control Mode

Synchronous display with control PC by DVI

Frame Update Frequency

60-85HZ

Screen Refresh Frequency
300-1000HZ

Gamma Correction

-5.0~+5.0

Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance

Ethernet cable<120m or Fiber Optic<10Kmlt;10Km

Support VGA Mode

1024x768,1280x1024,1600x1200,1920x1280

Brightness Correction

Pixel, Module, Cabinet

Environmental

Operating Temperature

-20°~+60°~+60°deg;~+60°

Operating Humidity

10~95% RH

Operating Life

100,000hours

MTBF

10000hours

Protection Level

~

Out of Control Rate

<0.02%

Description:
1.High transparency above 80%,can see through from the inside to the outside clearly.
2.Light weight,about 12kg/m2,few load to the glass wall,10mm thickness,occupies little space.
3.Easy installation and convenient maintenance,safe and stable.
4.Comparing to LED lighting product,it has better advertising benefit and will save much cost,wont change the building appearance.
5.Energy saving,no need cooling system and air-condetioner.good heat dissipation andanti-oxidation protection.
6.Easy operation by synchronous control,program can be changed anytime.
Wide use range:
Can be widely used for shop Window advertising and building video wall and anywhere behind the glass wall.
Packing and transportation:
Professional packaging:wooden box or flight case.
The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.
Faultlessly solve your worries in the transportation.
About Hero:
7-year's experience in LED screen, our factory has the ability of processing, researching and developing led display to ensure the prolificacy.A strict quality control process to make sure the led display screens is with high quality.
After-sale service:
1) Warranty:
Free to solve the quality problems to ensure that equipment normal operation in the warranty period . At any time, we bear all the responsibility, when the problem is from the product itself.
2) Free maintenance:
Free warranty in the warranty period.
Only charge the cost of raw materials, provide spare parts and maintenance services for the lowest price after the warranty period.
3)quick response:
Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
4) Free support:
Through telephone or network to provide service support in real time, or with the help of a network for remote debugging support (software), to solve the problem.
Officer website: Http://www.led-hero.com
