Flexible LED Curtain for TV Shows

Flexible LED Curtain for TV Shows

柔性LED幕帘电视节目

500 USD

加入意向
型号。 p15.625
IP等级 IP65
像素配置 1r,1g,1b
平均功耗 300W /m²m²up2;m²
显示类型 LED视频显示
寿命 10万小时
工厂价格 可得到
规范 ce,rohs,emc,ccc,iso9001
管芯颜色 饱满的色彩
像素间距 15.625毫米
显示功能 图像和文本显示splay
像素密度 4096像素/ M2
证明 ce,rohs,ccc,emc
保证 2年
商标 英雄
起源 中国广东省深圳市

柔性led幕布为电视节目
规范:

零件号

英雄ids4f

解析度

32(H)×16(V)S; 16(ⅴ)s;16(V)

像素间距

15.625毫米

LED配置

1r1g1b 3合1 smd

像素密度

4096像素/平方米

模块尺寸

320 *160毫米

驱动IC

my9221ss

驾驶方法

静态扫描,恒定电流

机柜重量

42公斤/平方米。

机械等级

悬挂重量支持

2T

表面平整度

间隙<0.5mm.5mm

光学等级

亮度

> 6500cd / m2 / m2

视角

150°/ 150°/ 150°deg;/150°

灰度

8位输入,14位校正

显示颜色

16.7M

亮度调整

0~100%

电源

操作电源

90〜260v 50〜60hz

最大。能量消耗

600W / m2

平均功耗

200W / m2

控制系统

控制模式

DVI同步显示控制PC

帧更新频率

60〜85Hz的

屏幕刷新频率

300〜1000Hz的

伽玛校正

-5.0~+5.0

支持输入

复合,S视频,组件,VGA,DVI,HDMI,HD_SDI

控制距离

以太网电缆<120m or Fiber Optic<10Kmlt;10Km

支持VGA模式

1024×768,1280×1024,1600×1200,1920×1280mes; 1200,1920×1280s;1280mes;1200, 1920×1280

亮度校正

像素,模块,机柜

环境的

工作温度

-20°〜+ 60°〜+ 60°deg;~+60°

工作湿度

10〜95%rh

使用寿命

100000小时

MTBF

5000小时

防护等级

~

失控率

<0.02%

描述:
良好的可视化
玻璃基设计允许光线穿过玻璃板,对建筑结构周围没有任何影响。玻璃屏幕的透明度可达85%。
2.超薄,超轻。
厚度可达1cm,重量可达7kg / m2
高亮度,高清晰度。
亮度可达6500 cd / m2。
4.维护方便。
可以从内部维护,更安全,更方便。
5.整个建筑物的照明费用。
除了良好的广告效果,LED玻璃显示屏还有助于照明玻璃墙,从而使玻璃墙更具吸引力,节省了大量的照明成本。
6.使用范围。
无论玻璃墙在哪里,都可以安装玻璃LED显示屏。如银行,超市,戏剧,商业街,酒店,公民建筑,地标建筑等。
应用:
广泛应用于玻璃幕墙场所,如银行,商场,剧院,商业街,商店,酒店,市政公共建筑,地标等广告。
包装运输
专业包装:木箱或飞行箱。
包装方式可以防止LED屏幕在运输过程中的碰撞,如损坏等。
无故解决您在运输中的烦恼。
关于英雄
LED屏幕7年的经验,我厂具有加工,研发LED显示屏的能力,确保多样化。严格的质量控制流程,确保LED显示屏具有高品质。
售后服务
1)保修:
免费解决质量问题,确保设备在保修期内正常运行。在任何时候,我们承担所有的责任,当问题来自产品本身。
2)免费维护:
保修期内免费保修。
仅在保修期内收取原材料成本,提供最低价格的备件和维修服务。
3)快速反应:
2小时内响应,24小时内无人为故障,一般故障解决,48小时内可接受故障解决。
4)免费支持:
通过电话或网络实时提供服务支持,或者借助网络进行远程调试支持(软件),解决问题。
Model NO. p15.625
IP Rating IP65
Pixel Configuration 1R, 1G, 1B
Average Power Consumption 300W / m²m²up2;m²
Display Type LED Video Display
Lifespan 100,000 Hours
Factory Price Available
Specification CE, ROHS, EMC, CCC, ISO9001
Tube Chip Color Full Color
Pixel Pitch 15.625mm
Display Function Image & Text Displayisplaysplay
Pixel Density 4096 Pixels/ M2
Certification CE, RoHS, CCC, EMC
Warranty 2 Years
Trademark HERO
Origin Shenzhen City, Guangdong Province, China

flexible led curtain for tv shows
specification:

Part Number

HERO-IDS4F

Resolution

32(H)×16(V)s;16(V)s;16(V)

Pixel Pitch

15.625mm

LED Configuration

1R1G1B 3-IN-1 SMD

Pixel Density

4096 pixels/ m2

Module Size

320*160mm

Driving IC

MY9221SS

Driving Method

Static Scan, Constant Current

Cabinet Weight

42kg/sq.m.

Mechanical Ratings

Hanging Weight Support

2T

Surface Flatness

Gap<0.5mm.5mm

Optical Ratings

Brightness

﹥6500cd/ m2/ m2

View Angle

150°/150°/150°deg;/150°

Gray Scale

8bits input, correction with 14bits

Display COLOR

16.7M

Brightness Adjustment

0~100%

Power Supply

Operation Power

90~260V 50~60Hz

Max. Power Consumption

600W/ m2

Average Power Consumption

200W/ m2

Control System

Control Mode

Synchronous display with control PC by DVI

Frame Update Frequency

60~85Hz

Screen Refresh Frequency

300~1000Hz

Gamma Correction

-5.0~+5.0

Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance

Ethernet cable<120m or Fiber Optic<10Kmlt;10Km

Support VGA Mode

1024×768, 1280×1024, 1600×1200, 1920×1280mes;1200, 1920×1280s;1280mes;1200, 1920×1280

Brightness Correction

Pixel, Module, Cabinet

Environmental

Operating Temperature

-20°~+60°~+60°deg;~+60°

Operating Humidity

10~95% RH

Operating Life

100,000hours

MTBF

5000hours

Protection Level

~

Out of Control Rate

<0.02%

Description:
1.Good visualization
Glassbased design allows the light to pass through the glass without any influence to the building structure around.Transparency of the glass screen can up to 85%.
2.Ultra-thin, and ultra-light.
The thick can up to 1cm, and the weight can up to 7kg/m2
High brightness, and high definition.
The brightness can up to 6500 cd/m2.
4.Easy and convenient maintenance.
It can be maintained from inside, safer and more convenient.
5.Saving lighting costs of the whole building.
Besides good advertising effect, LED glass display also helps lighting the glass wall, thus makes the glass wall more attractive and saving a lot lighting cost.
6.Wide use range.
Wherever the glass wall is, glass LED display can be installed. Such as bank, supermarket, theater, business street, hotel, public civic buildings, and landmark buildings, etc.
Applications:
Widely used in glass curtain wall places, such as banks, shopping malls, theaters, commercial streets, stores, hotels, municipal public buildings, landmarks and other advertising.
Packing and transportation
Professional packaging:wooden box or flight case.
The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.
Faultlessly solve your worries in the transportation.
About Hero
7-year's experience in LED screen, our factory has the ability of processing, researching and developing led display to ensure the prolificacy.A strict quality control process to make sure the led display screens is with high quality.
After-sale service
1) Warranty:
Free to solve the quality problems to ensure that equipment normal operation in the warranty period . At any time, we bear all the responsibility, when the problem is from the product itself.
2) Free maintenance:
Free warranty in the warranty period.
Only charge the cost of raw materials, provide spare parts and maintenance services for the lowest price after the warranty period.
3)quick response:
Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
4) Free support:
Through telephone or network to provide service support in real time, or with the help of a network for remote debugging support (software), to solve the problem.
