此LED门灯可以是程序自动在车门打开的时候。

Outpower：3W / 5W

电压：12V / 24V

工作温度：-40度〜105度

材质：铝合金外壳

使用寿命：30，000-50万小时

认证：E4 / RDW

安装：

这种LED灯可以在门口火焰底部安装，并确保莱恩与地面垂直;

1.拉下车门内板第一。 标记合适的位置钻一个洞。

2.钻在门板与我们的蛀虫孔。

3.插图来自汽车车门底部的产品，然后安排电源线。

4.通过安装在内部的孔电源线螺母; 拧紧螺母;

5.根据安装指南连接电源线;

6.调节灯泡投影到合适的地方用扳手工具。

7.重新安装内部门板，然后检查的最终效果。

This LED Door Lights can be automaticlly on when car doors open.

Outpower: 3W/ 5W

Voltage: 12V/ 24V

Working Temp: -40 degrees~ 105 degrees

Material: Aluminium alloy casing

Life span: 30, 000-50, 000 hours

Certification: E4 / RDW

Installation:

This LED lights can be installed at the bottom of the door flame and make sure the Len vertical with the ground ;

1. Pull down the inside door board first. Mark the suitable location for drilling a hole.

2. Drill the hole on the door board with our borer .

3. Inset the product from the bottom of car door , then arrange the power cord.

4. Install the nut through the power cord upon the hole inside; Tighten the nut;

5. Connect the power cord according to the installation guide;

6. Adjust the lamp projection to the suitable place with wrench tool.

7. Reinstall the inside door board, then check the final effect.
