主要规格

技术参数
压力：
最大材料压力为0.6MPa（6巴）
最大物化空气压力：1.2MPa时（12Bar）
最小雾化空气压力为0.5MPa（5Bar对照）
材料管道连接：材质软管6 * 4
物化空气软管：塑料软管NW8 / 9和G1 / 4AGA
重量：约800克
噪声：73-96分贝（约1米的距离测量的枪）
最高工作温度：43℃，
可选材料喷嘴：口径为0.50.81.01.21.51.82.0

五个的更新

1，喷嘴融入式之一
2，进液口设计更合理
3，枪的全新设计链接
4，增加控制阀
5，气体入口设计更为简单
保养
当做保养，你必须：
清洗枪，停止压缩空气的供给停止材料的供给，在枪不残留空气压力。
易损部件如密封件，喷嘴和针枪必须定期检查。 磨损程度是因为材料的喷涂不同。 从泄漏，泄漏和喷雾形状变化可以确定是否有磨损的零件。 喷嘴和针枪必须同时更换。 你不能用坚硬锋利的工具清洁喷嘴和气帽。
幻灯片的部件应定期注油，建议特殊润滑剂昶源给你。

颜色：白/蓝

Key Specification

Technology parameters
Pressure:
Maximum material pressure: 0.6MPa (6bar)
Maximum materialization air pressure: 1.2MPa (12Bar)
Minimum atomizing air pressure: 0.5MPa (5Bar)
Materials pipe connection: Material hose 6 * 4
Materialized air hose: plastic hose NW8 / 9 and G1/4AGA
Weight: about 800g
Noise : 73-96 dB (about 1 meter of the gun of the distance measurement)
Maximum operating temperature: 43 ° C
Optional materials nozzle: caliber were 0.50.81.01.21.51.82.0

Five of the update

1, nozzle integrated into one of formula
2, a liquid inlet design more reasonable
3, the new design of the gun linked
4, increase the control valve
5, a gas inlet design simpler
maintenance
When do maintenance you must:
Cleaning the gun to stop the supply of compressed air to stop the supply of materials, not residual air pressure in the gun.
Vulnerable parts such as seals, nozzle and needle gun must be checked regularly. The degree of wear is because the spraying of materials differ. From the leak, the leak and spray shape change can determine the parts for wear. Nozzle and needle guns must be replaced at the same time. You can not use a hard and sharp tools to clean the nozzle and gas cap.
Parts of the slide should be regular oiling, the recommended special lubricants CnSeiko to you.

Color: white/ blue
