该WXSG薄壁轴承由7开放和5密封系列，内孔直径从1.000英寸到20.000英寸。 系列范围从0.1875 X 0.1875英寸到1.000 X 1.000英寸的横截面。 在这些系列中，环的材料可以是GCr15钢和不锈钢连续环弹锁口袋，黄铜或不锈钢连续环圆形的口袋里，磁环（尼龙） ​​，钢铁间隔球分离。

以支持各种负载场景， WXSG薄截面轴承有三种基本类型可用：径向接触（ L型） ，角接触（类型M）和四点接触（ N型） 。 打开轴承有三种配置： L型， M型，类型N.密封轴承有L型和N，你可以选择密封轴承的应用场合的轴承需要保持清洁和良好的润滑

The WXSG Thin-section Bearings consists of 7 open and 5 sealed series, bore diameters ranging from 1.000 inch to 20.000 inch. Series range from 0.1875 X 0.1875 inch to 1.000 X 1.000 inch in cross section. In these series, the material of rings could be GCr15 and stainless continuous ring snap-over pocket, brass or stainless steel continuous ring circular pocket, toroid (Nylon) , and steel spacer balls separators.

To support various load scenarios, WXSG thin section bearings are available in three basic types: radial contact ( Type L) , angular contact (type M) and four-point contact (Type N) . Open bearings are available in three configurations: Type L, Type M, Type N. And Sealed bearings are available Type L & N, You could choose sealed bearings for applications where bearings need to be kept clean and well lubricated
