Ground Shot Blasting Machine (DISA & BLASTRAC tech)

Ground Shot Blasting Machine (DISA & BLASTRAC tech)

地面抛丸机(DISA&BLASTRAC科技)

议价

加入意向
产品详情:
条件
原始地点 山东省,中国(大陆)
品牌 青竹
电机功率 12千瓦
售后服务提供 提供服务机械海外工程师
详细信息

该系列混频器具有结构合理的参数; 高级; 混合切碎的短周期; 高效率

水平移动抛丸机
BLASTRAC高科技地面抛丸机
ISO和CE认证
有现货,交货及时

水平移动抛丸机简介:

新BLASTRAC产品,便携式抛丸机,主要用于去除油漆,沥青和漂油和清洁高速公路,机场跑道,船板,油箱和桥梁等大型沥青路面。 水平移动抛丸机的设计是一个创新的方式,因为是第一次它适应污染物的特殊分离系统。 除了我们使用涡轮是标准的,因此,零件具有非常低的成本。 这种创新系统的原理好处是增加寿命,降低维护成本。 它被电供电,自行式,并提供可变行程的速度控制,以提供一致的爆破模式。 混凝土粉尘由一个强大的灰尘收集系统中回收。 本机设计以去除油漆带200可以为1200mm,宽为无尘。 集尘器移除研磨粉碎,灰尘和污染物。 很少磨料会丢失,可用介质返回到喷砂轮储料斗用于再循环。

ZPX系列卧式可移动式抛丸机的技术参数:

类型

项目

ZPX75

ZPX110

ZPX150

ZPX110D

ZPX150D

工作宽度

毫米

200

250

300

600

800

爆破容量

m2/h

) 80

) 180

) 280

) 400

) 600

轮边功率

千瓦

7.5

11

15

2*11

2*15

整机重量

公斤

180

250

360

560

780

外部尺寸

毫米

适当除尘器

包括

包括

包括

包括

包括

类型

项目

ZPX400

ZPX600

ZPX800

ZPX1200

电压

380V

380V

380V

380V

功率

20KW

30KW

26 / 30KW

55KW

工作宽度

200毫米

450毫米

550毫米

900-1000mm

驱动模式

自动/手动

自动/手动

自动/手动

自动/手动

抛丸器数量

1

2

1

2

如果您想了解更多产品请登录到http://www.castingglobal.com/

Product Details:
ConditionNew
Place of OriginShandong, China (Mainland)
Brand NameQingzhu
Motor Power12kw
After-sales Service ProvidedEngineers available to service machinery overseas
Detailed Product Description

This series Mixer with parameters of reasonable structure; advanced; mixed with shredded short cycle; high efficiency

horizontal movable shot blast machine
BLASTRAC tech ground shot blasting machine
ISO&CE certificate
In stock, prompt delivery

Intro of horizontal movable shot blasting machine:

A new BLASTRAC product, the portable shot blasting machines , are mainly used to remove paint, pitch and floating oil and clean highways, airport runways, ship board, oil tank and bridges and other large asphalt surfaces. The horizontal movable shot blast machine is designed in an innovative way, since for the first time it adapts special separating system of pollutants. Besides the turbine we use is standard and therefore the spare parts have a very low cost. The principle benefits of this innovative system are the increase the life span and reduced maintenance costs. It is electrically-powered, self-propelled and offers variable travel speed control to provide a consistent blast pattern. The concrete dust is recovered by a powerful dust collection system. The machine is designed to remove paint strip from 200 to 1200mm wide and to be dust free. The dust collector removes pulverized abrasive, dust and contaminants. Very little abrasive is lost and the usable media is returned to the storage hopper for recirculation by the blast wheel.

The tech parameter of ZPX series horizontal movable shot blasting machine:

Type

Item

ZPX75

ZPX110

ZPX150

ZPX110D

ZPX150D

Working width

mm

200

250

300

600

800

Blasting capacity

m2/h

) 80

) 180

) 280

) 400

) 600

Wheel power

kw

7.5

11

15

2*11

2*15

Machine weight

kg

180

250

360

560

780

Outside measurement

mm

Appropriate dust collector

include

include

include

include

include

Type

Item

ZPX400

ZPX600

ZPX800

ZPX1200

Voltage

380V

380V

380V

380V

Power

20KW

30KW

26/30KW

55KW

Working width

200mm

450mm

550mm

900-1000mm

Drive mode

Auto / Manual

Auto / Manual

Auto / Manual

Auto / Manual

Quantity of blast wheel

1

2

1

2

if you want to know more products , please visit to http: //www.castingglobal.com/
