产品详情：

原始地点	广东省，中国（大陆）
品牌	JST BH
型号	KRC00004
类型	适配器，电源/信号连接器
应用	PCB
性别	女
牌	JST BH
沥青	3.5毫米
应用	背光灯电缆
材料	ROHS; SGS; UL
电路	2针
线的应用	24-28 AWG
性能	耐TEM /湿度/冲击/振动
规格	固定温度/电压/电流额定值
数量	最小起订量

详细信息

1.背光电缆与JST BH 3.5mm节距连接器
发货前2.100％的测试
3.免费样品，小订单
4. UL，SGS是西装

背光电缆与JST BH 3.5mm节距连接器

此线束是专为之间的快速，方便地连接 LED背光显示屏 与JST BHSR系列的连接器以及任何其他连接器。 我们提供一个2针连接器BHSMR-02V-S组装2股和插座外壳。 电缆的第二侧是未经处理的。

优点：

1.专业制造商超过10年

双方可能的2个人组装

3.可用2电路

4.该电缆将两侧包括匹配的连接器外壳提供拔出

5.交付的diferent len​​ght

6.颜色编码

技术数据：

ireechnological规格
额定电流	额定电压	温度范围	绝缘电阻	耐压	接触电阻
5A AC，DC	250V AC.DC	-25C- + 85℃	1000M /分钟	1500V AC /分钟	20MΩ/最大

. 方1：BHSMR-02V-S与压接触SBHSM-002T-P0.5

. 方2：未处理

. 钢绞线：UL 24-28AWG

我们也能够为您提供完整的组装就可以使用线束的样本。 我们将高兴地提交你非约束力的要约。

Product Details:

Place of Origin	Guangdong, China (Mainland)
Brand Name	JST BH
Model Number	KRC00004
Type	Adapter, Power/ Singal Connector
Application	PCB
Gender	Female
brand	JST BH
pitch	3.5mm
applications	backlight cable
material	ROHS; SGS; UL
Circuits	2 pin
Wire Application	24-28 AWG
Performance	Resistant Tem/ Moisture / Shock / Vibration
Spec	Fixed Temp/ Voltage/ Current Rating
Quantity	MOQ

Detailed Product Description

1. Backlight Cable with JST BH 3.5mm Pitch Connector
2.100% test before delivery
3. free sample, small order
4. UL, SGS are suit

Backlight Cable with JST BH 3.5mm Pitch Connector

This wiring harness is designed for a quick and easy connection between a LED-backlight display with a connector of the JST BHSR series and any other connector. We supply a 2-pin connector BHSMR-02V-S assembled with 2 strands and a socket housing. The second side of the cable is unprocessed.

Advantage:

1. Professional Manufacturer more than 10 years

2. individual assembling on both sides possible

3. Available 2 Circuits

4. this cable will be supplied unplugged on both sides including matching connector housings

5. Deliverable in diferent lenght

6. Color coded

Technical Data:

ireechnological Specification
current rating	voltage rating	temperature range	insulation resistance	withstanding voltage	contact resistance
5A AC, DC	250V AC.DC	-25C-+85C	1000M/ Min	1500V AC/ minute	20mΩ/ Max

.Side 1: BHSMR-02V-S with crimp contact SBHSM-002T-P0.5

.Side 2: Unprocessed

.Strands: UL 24-28AWG

We are also able to offer you samples of the full assembled ready to use wiring harness. We would be pleased to submit you a non-binding offer.
