详细介绍 喷水织机与多臂：

Jw851喷水织机与多臂机，它可以在生产的主要高密度的使用，高权重织品种，具有高速，高效织造高密度，高克重面料经营能力的稳定性 ，当组织有着不错的表现。
适应范围广，特别是在高密度，高克重，超细织物，还具有高速度，高效率，极其稳定运行能力。 这种模式可以匹配机储纬器，电子储纬器，多喷，凸轮开口装置，多臂开口装置。

可选宽度：150190210230260280340360厘米。

（1或2泵; 1-6喷嘴喷水织机）

引纬率：大多数每分钟2280米
速度：400-700RPM（在根据织物规格确定的实际速度）
综框数：468pcs为平原; 2-10个凸轮; 2-16个为多臂。
主电机功率：1.5〜4.5KW
纬密范围：5〜80thread厘米

Detailed introduction to water jet loom with dobby:

Jw851 Water-jet Loom with dobby, it can be used in the production of major high-density, high weight weaving species, with high-speed, high efficiency and stability of the operating capacity of weaving in high-density, high-weight fabrics, when the organization has a good performance.
adapt to a wide range, especially in high density, high weight, ultrafine fabric , also with high speed, high efficiency, extremely stability operation capability. This model can match machine weft storage device, electronic weft storage device, multi-jet, cam openings devices, dobby opening device.

Optional width: 150190210230260280340360cm.

(1 or 2 pump; 1-6 nozzle water jet loom)

Weft insertion rate: most 2280 meter per minute
Speed: 400-700RPM (The actual speed determined in accordance with fabric specifications)
Number of heddle frame: 468pcs for plain; 2-10 pcs for cam; 2-16 pcs for dobby.
main motor power: 1.5~4.5KW
Range of weft density: 5~80thread cm
