蒙乃尔合金丝导电屏蔽密封

蒙乃尔合金丝导电屏蔽密封的金属丝网衬垫提供了一个很好的成本效益的EMI垫圈，提供屏蔽磁和电场。 Kemtron编织在四线类型，蒙乃尔合金，不锈钢，铝和锡的镀铜包钢。 针织网眼衬垫可以作为实体网格或针织超过弹性芯带或不带连续长环境密封或制造定制的设计。

本产品包含形成为固体型材即然后用针织制造连续的垫圈条的编织金属丝网带。 导电金属丝编织是柔性的和可压缩的，这使得一个极好的RFI / EMI / EMP垫圈。

性能

频域; 蒙乃尔合金; 铝; 锡; 不锈钢

10千赫H 45 40 60 40

100 KHzH 49 45 65 44

1兆周1 H 60 60 8558

1兆赫Ë125 125 125 125

10 MHzE 120 120 120 120

100兆赫ê100100 108 100

400 MHz的第98页95 99 94

1 GHz的第85页76 78 76

10 GHz的第80页65 62 60

如果您有兴趣，请拨打咨询电话0512-63935021或发送电子邮件judge20111 @ 126。 COM，QQ：188585998 SKYPE：aotemakejdl

Monel wire Conductive shielding seal

Monel wire Conductive shielding seal knitted wire mesh gaskets provide an excellent cost effective EMI gasket, providing shielding in the magnetic as well as electric fields. Kemtron knit in four wire types, Monel, Stainless steel, aluminium and tin plated copper clad steel. Knitted mesh gaskets can be supplied as solid mesh or knitted over elastomeric cores with or without environmental seal in continuous lengths or fabricated to custom designs.

This product consists of a knitted wire mesh tape that is formed into a solid profile that is then over knitted making a continuous gasket strip. The conductive metallic knitted wire is flexible and compressible which makes an excellent RFI/ EMI/ EMP gasket.

Performance

Frequency field; Monel; Aluminum; Tin; Stainless

10 KHz H 45 40 60 40

100 KHzH 49 45 65 44

1 MHz H 60 60 8558

1 MHz E 125 125 125 125

10 MHzE 120 120 120 120

100 MHz E 100100 108 100

400 MHz P 98 95 99 94

1 GHz P 85 76 78 76

10 GHz P 80 65 62 60

If you are interested, please call TEL 0512-63935021 OR Email judge20111@126. com, qq: 188585998 skype: aotemakejdl
