Low Hardness Silicone Foam Seal Strip

低硬度硅胶发泡密封条

议价

译文
原文

低硬度硅胶发泡密封条

低硬度硅胶发泡密封条是高档硅橡胶材料和独特的技术，具有耐高温，耐老化，耐臭氧，绝缘性能，燃油性，耐润滑油，无异味的人品好，经久耐用。高压缩和低压缩变定在宽的温度范围内，和良好的声和热绝缘性能。适用于-50℃〜+ 280℃保护和隔热长期连续使用和-70℃〜+280℃，对各种机器的间歇性使用。

奥科测试	标准	指标	结果
密度	ASTM D 1056	350-550kg /㎡	510千克/㎡
Hardenss邵氏A	ASTM D 1056	5-35 A	20A
吸水率	ASTM D 570	(5%	2.7%
低温韧性	ASTM D1056	-55℃	-63℃
气温	SAEJ2236	200℃	240℃
压缩变形	ASTM D 1056	）60kPa	67千帕 TEL：13222978488
22小时@ 70℃	ASTM D 1056	(1%	0.63%
22小时@ 100℃	ASTM D 1056	(5%	1.9%
断裂拉伸应力	ASTM D 412	）250kPa	360千帕 QQ：188585998
断裂伸长率	ASTM D 412	) 50%	73%
拉伸强度	ASTM D 1056	）10千克/厘米	的12.7公斤/平方厘米
环境保护	ROHS / FDA	通过	通过

如果您有兴趣，请拨打咨询电话0512-63935021或发送电子邮件judge20111 @ 126。 COM，QQ：188585998 SKYPE：aotemakejdl

Low hardness silicone foam seal strip

Low hardness silicone foam seal strip is with high grade silicone rubber material and inimitable technique, with Good character of high temperature resistant, aging resistant, ozone resistant, insulation property, fuel Oil resistance, lubes resistance, no smell and wear well. High compressibility and low compression set Over a wide temperature range, and good acoustic and thermal insulation properties. Apply to -50C ~+280C protect and heat insulation for long term continuous use and -70C ~ +280 C for intermittent Use on all kinds of machine.

AOKE Test	Standard	Indicators	Results
Density	ASTM D 1056	350-550kg/ ㎡	510 kg/ ㎡
Hardenss Shore A	ASTM D 1056	5-35 A	20A
Water absorption	ASTM D 570	(5%	2.7%
low-temperature toughness	ASTM D1056	-55℃	-63℃
The temperature	SAEJ2236	200℃	240℃
Compression Deflection	ASTM D 1056	) 60kPa	67 kPa TEL: 13222978488
22hrs@70℃	ASTM D 1056	(1%	0.63%
22hrs@100℃	ASTM D 1056	(5%	1.9%
Tensile stress at break	ASTM D 412	) 250kPa	360 kPa QQ: 188585998
Elongation at break	ASTM D 412	) 50%	73%
The tensile strength	ASTM D 1056	) 10kg/ cm	12.7 kg/ cm
Environmental protection	ROHS / FDA	PASS	PASS

If you are interested, please call TEL 0512-63935021 OR Email judge20111@126. com, qq: 188585998 skype: aotemakejdl
