型号Holder type: 3*8

标称频率Frequency: 28.375MHz

调整频差Frequency tolerance at 25ºC: ± 10ppm

温度频差Temperature tolerance: ± 30ppm

工作温度Operating temperature range: -20ºC ~+70ºC

保存温度 Storge temperature range: -40ºC ~+85ºC

负载电容Load capacitance (CL) : 20 pF

静电容Shunt capacitance (C0) : 5pF max.

振动模式Vibration mode: AT fund

等效电阻Equivalent series resistance: 30Ω

绝缘电阻 Insulation resistance: 500Ωmin (DC 100V)

老化率Aging: ± 5ppm/ year

激励功率Drive level: 0.1mw

外形尺寸: Size

Unit: mm 印字: Mark: Laser28.375N
