LED三面翻广告牌结合的优势ofLED屏幕和普通三面翻。 普通的三面翻面由ofprisms打开他们的桥，提供3旋转边，因此3advertising空间。 我们的LED三面翻开发一个面为LED屏幕andkept其他两个相同的普通三面翻。 在白天，我们的LED TrivisionBillboard显示两个印刷广告画册循环，晚上itturns到全彩LED屏。

P16规格：

点距：16.2毫米;

像素密度：3810dots /平方米;

平均功耗：195瓦特/平方米;

模块尺寸：123毫米*258毫米

模块像素：16 * 8

配置：1R + 1G + 1B;

芯片封装：DIP346;

控制方式：Synchoronic;

输入电压：220V / 50HZ;

刷新频率：540Hz;

驱动方式：静态的;

闵最佳视距：16.2米

灰色等级：单色12位

亮度：2800-2950CD /平方米;

防护等级：IP65;

缺陷率小于1/5000;

寿命：超过50000小时;

ModuleVoltage：12V;

外形尺寸为：W145mm * D155mm;

棱镜尺寸：125毫米;

电机功率：90W松下;

控制系统：SchneiderPCL / SR2;

最大工作周期：6;

暂停时间：0-99s;

软件：LED演播室;

LED Trivision Billboard combines the advantages ofLED screen and ordinary Trivision. The ordinary Trivision faces are made ofprisms turning on their axle offering 3 rotative sides and therefore 3advertising spaces. Our LED Trivision developed one face into LED screen andkept the other two same as ordinary Trivision. In daytime, our LED TrivisionBillboard displays two printing advertising pictures cyclically and at night itturns to the full color LED screen.

P16 Specifications:

Pixel Pitch: 16.2mm;

Pixel Density: 3810dots/ sq.m;

Average power consumption: 195w/ sq.m;

Module size: 123mm*258mm

Module pixels: 16*8

Configuration: 1R+1G+1B;

Chip Package: DIP346;

Control Mode: Synchoronic;

Input Voltage: 220V/ 50Hz;

Refresh Rate: 540Hz;

Driving Mode: Static;

Min best viewing distance: 16.2m

Gray Grade: monochromic 12bit

Brightness: 2800-2950CD/ sq.m;

IP Grade: IP65;

Defects Rate: less than 1/5000;

Life Span: more than 50000H;

ModuleVoltage: 12V;

Frame Size: W145mm*D155mm;

Prism Size: 125mm;

Motor Power: 90W Panasonic;

Control System: SchneiderPCL/ SR2;

Max Working Period: 6;

Suspend Time: 0-99s;

Software: LED studio;
