工作原理：
INS-HAS03安防报警系统，包括报警主机，探测器（被动红外探测器和无线门磁探测器可以选择）和无线遥控器。 当传感器检测到的东西休息一下，马上要发射的入侵信号发送到报警主机密码的无线密码后，主机收到报警信号后，它会同时打开高分贝现场报警系统，面板显示区域和报警类型。 清楚地表明了侵略者的位置，同时，报警器通过网络拨号器旋转到电话号码哪些用户设置的主机，并播放录制的声音。 接到电话后，用户可根据需要做了一系列遥控操作。
INS-HAS03安防报警系统，它采用高科技微电脑控制系统，检测其距离较远，时尚造型，报警系统使用的边界时，他们不会互相干扰许多单位。 当主机电源切断，DC电源均可使用，会更经济和方便的

应用范围
房屋，建筑物，庭院，工厂，车库，办公室，财务室，市场，等等。

主要功能

• 它拥有100个无线防区报警
• 6标准的有线防区
• 2标准的插座
• 带液晶大屏幕
• 语音控制
• 通过键盘和盖板保护
• 检查布防，撤防，报警的问题，等等
• 随着2级汽车，撤防设定
• 跟接触ID
• 学习编码
• 凭借出色的密码，发动机密码，用户密码的显示器，方便用户操作和发动机监控
• 自动拨号6组电话号码，其中预设定
• 用其功能可以得到第一线时警报
• 高科技和性能

规范：

主要的
电源：交流220V，直流8.4V（7ktsAAA可充电镍氢电池）
电流在静止状态下：（15毫安
报警声级：百分贝
防区显示：）100区

无线红外探测器
探测距离：5-10米
电源：DC 9V
电流是静态的状态：（60μA

发射频率： 315MHz的
无线发射距离：）500米（露天）
温度：-30至42摄氏度

无线门磁

电源：DC 12V，采用12V / 23A电池
功耗处于静止状态：（5μA
发射频率： 315MHz的
无线遥控距离：）百米（露天）

无线遥控
无线发射距离：）50米（露天）
电源：DC 12V，采用12V / 23A电池
发射频率： 315MHz的

项目包括：

• 1个家庭安全Inteligent自动拨号无线报警器
• 1个无线红外探测器
• 2个遥控器
• 1个磁门磁
• 1个天线

Working Principle:
INS-HAS03 security alarm system, including alarm main unit, detector (PIR detector and wireless door detector can be chosen) and wireless remote control. When the sensor detect something in break, Immediately to transmit the wireless password of invasion signal to the alarm host password, after the main unit receive alarm signal, it will open high dB field alarm system at once, the panel shows zone and alarm type. Clearly shows that the position of the invaders, meanwhile, alarm host through the Network dialer rotary to the telephone number which user setting, and play the recorded voice. After receiving the call, user can do a series of remote control operation according to requirement.
INS-HAS03 security alarm system, it adopts high technology microcomputer-control system, its distance of detection is far and fashionable sculpt, Many units of alarm system use border upon, they will not disturb each other. When the host power-cut, DC power can be used, will be more economical and convenient

Range of application
House, building, courtyard, factory, garage, office, finance room, market, etc.

Main function

• It has 100 wireless zone alarm
• 6 standard wired zone
• 2 standard outlet
• Big screen with LCD
• Voice control
• With keyboard, and cover protected
• Checking arm, disarm, alarm issue, etc
• With 2 grade auto, disarm setting
• Connected with Contact ID
• Learning coding
• With outstanding password, engine password, user password monitor, convenient to user operation and engine monitor
• Auto-dialing 6 group telephone number which pre-setting
• With the function which can get the first line when alarm
• High technology and performance

Specification:

The Main
Power supply: AC 220V, DC 8.4V (7ktsAAA rechargeable Ni-MH battery)
Electric current in static state: (15mA
Alarm sound level: 100dB
Zone display: ) 100 zones

Wireless PIR detector
Detect distance: 5-10m
Power: DC 9V
Electric current is static state: (60μA

Emission frequency: 315MHz
Wireless emission distance: ) 500m (in the open air)
Temperature: -30 to 42 degree C

Wireless door sensor

Power: DC 12V, with 12V/ 23A battery
Power consumption in static state: (5μA
Emission frequency: 315MHz
Wireless control distance: ) 100m (in the open air)

Wireless remote control
Wireless emission distance: ) 50m (in the open air)
Power: DC 12V, with 12V/ 23A battery
Emission frequency: 315MHz

Item Includes:

• 1 x Home Security Inteligent Auto-dialing Wireless Alarm
• 1 x Wireless PIR detector
• 2 x Remote controller
• 1 x Magnetic Door Contact
• 1 x Antenna
