| Features:
High Resolution:
By adopting Sony Ex-view HAD II CCD, the camera produces clear picture up to 700 TV Lines. Adaptive Tone-curve Reproduction (ATR)
By adopting Sony unique DSP Technology, automatically, detect dark zone of the image, perform real-time color
Adjustment & correction on backlight & dark zone, reproduce
Natural, clear image. Super Head-light Suppression
By adopting Sony unique DSP head-light suppression Technology
To ensure the image exposure evenly, view dark object which around strong light clearly. DNR (Digital Noise Reduction)
By adopting unique digital processing technology, it can reduce the luminance
And chrominance noise separately, and produce clear, obvious images by not affecting image resolution. OSD
Support OSD function. Specification: | Camera | | Image Sensor | 1/3' Sony Ex-view HAD II CCD | | Pixel | NTSC: 976 (H) x508 (V) ;PAL: 976 (H) x 596 (V) | | Scanning System | 2: 1 Interlace | | Sync System | Internal / External Sync. | | OSD | Support | | Video Output | 1.1Vp-p/ 75Ω | | High Resolution | 700 TV Lines | | S/ N Ration | ) 50dB | | Min. iIllumination | 0 Lux (When IR LED On) | | Shutter Speed | Auto: 1/60-1/100000sec (NTSC) ; 1/50-1/120000sec (PAL)
Fixed: 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000sec | | White Balance | ATW / Push / User1 / User2 / Anti CR / Manual / Push Lock Selectable
ATW: 1080K-10500K | | BLC | BLC / HLS (Head-light Supression) Selectable | | ATR | On (Brightness, Contrast adjustable) / Off | | Gain Control | 6- 44 . 8 dB Adjustable (Manual Shutter, AGC) | | 2D-DNR | On/ Off | | Motion Detection | On/ Off (4 zone) | | Privacy Masking | On/ Off (4 zone) | | Mirror | On/ off | | Day &Night | Color / B&W / Auto Selectable | | Image Adjustable | Brightness / Contrast / Sharpness / Hue / Gain Adjustable | | Lighting proof | Multi-level Lighting Proof | | Lens | | Lens | 3.6mm | | General | | IR | 24IR | | IR Distance | 15-20m | | Power Supply | DC12V | | Power Consumption | 300mA | | Working Temperature | -10°C~+50°C | |
