谁拥有这个系统的驱动程序不需要按任何按钮，当他们锁定和解锁他们的汽车。 该系统可自动完成大部分工作。 司机只需要做的就是把智能钥匙在他们的口袋或钱包，并采取它。

这是我们的PKE产品的最新型号。 它是基于我们超过10年PKE的设计和制造经验而设计的。

自动功能：

1.自动锁定/解锁

2.自动布防/撤防

3.提醒有一个未关闭的门

4. 1.4.3信号关闭窗口（可选）

））以与智能钥匙和接近车子时，系统会验证它，撤防，然后解锁车门（你不需要按任何按钮）。

））关闭汽车电源，下车关门后，系统将手臂并锁住车门，当你离开走车2米。

））如果轿厢门一人未关好，当你离开时，系统会提醒你通过警笛和转向信号灯。

））如果离开，该系统还可以输出连续信号，其可以用来控制窗口关闭。 （有些车不支持此功能直接，你应该添加一个自动关窗器的PKE系统工作）。

使用智能钥匙的aremote手册函数 -

1.远程解锁/锁定

2.遥控行李箱开口（需要电机driventrunk）

3.汽车发现：按下锁定按钮，使汽车灯闪光灯和喇叭声。

报警及防盗功能

当系统布防，如果车子很震惊（震动传感器被触发），或者一个门被打开或汽车被启动时没有允许的话，系统会通过喇叭报警和转向灯。

时，有一个报警，系统会切断汽车的电源，以防止它窃取。

锁定在第一次制动（可选）

发动机启动后，系统将锁定所有车门你当你踩刹车。 系统会自动解锁车门，当您停止并打开汽车电源关闭。

三个有用的模式

1. 自功率谱节省： 如果你离开你的车独自为24小时以上时，系统将暂停PKE（依旧保持布防）节省汽车电池的电力。

2. 暂停/手动激活PKE： 你可以按下智能键，使PKE停用或激活按钮。

3. 静音解锁＆布防： 您可以让通过按下智能钥匙解锁和冲击报警按钮时，警号不发声。

技术指标

主机工作电压：DC 9.0V-18.0V
主机待机电流：（=30毫安@ 12V

LF检测距离：2米

智能钥匙工作电压：DC 2.0V〜4.0V DC

智能钥匙待机电流：（= 4uA的@ 3V

工作温度：-40〜+ 85摄氏度

遥控距离为30μm

Drivers who have this system don't need to press any button when they lock and unlock their cars. The system can finish most of the work automatically. Drivers only have to do is put the smart key in their pocket or purse and take with it.

This is the latest model of our PKE products. It is designed based on our over 10 years PKE designing and manufacturing experience.

Automatic Functions:

1. Automatic Locking / Unlocking

2. Automatic Arming/ Disarming

3. Reminding there is an unclosed door

4. Outputting signal to close windows (optional)

) ) Taking with the Smart Key and approach the car, the system will verify it, disarm, and then unlock the car door (You don't need to press any button) .

) ) Turn off the car power, get off and close the door, the system will arm and lock the car doors when you leave away the car 2 meters.

) ) If one of the car doors was not closed well when you leave, the system will remind you through the siren and turn signal lamp.

) ) When you leave, the system also can output a continuous signal, which can be used to control the windows closing. (Some cars don't support this function directly; you should add a Window Closer to work with the PKE system) .

Manual Functions- using the smart key as aremote

1. Remote unlocking / locking

2. Remote trunk opening (need motor-driventrunk)

3. Car finding: press the Lock button to make the car light flash and the horn sound.

Alarming & Immobilizer Function

When the system is arming, if the car was shocked (the shock sensor was triggered) , or one door was opened or the car was started without permitting, the system will alarm through the horn and turn light.

When there is an alarm, the system will cut off power supply of the car to prevent it from stealing.

Locking on first braking (selectable)

After the engine is started, the system will lock all the car doors for you when you step on the brake. The system will unlock the doors automatically when you stopped and turn the car power off.

Three useful modes

1.AutoPower-saving: if you leave your car alone for more than 24 hours, the system will suspend PKE (still keep arming) to save electricity of car battery.

2.Suspending/ Activating PKE manually: you can press buttons on the smart key to make PKE deactivate or activate.

3.Mute unlocking & arming: you can let the siren not sound when unlocking and shock alarming by press the buttons on the smart key.

Specifications

Main Unit Working Voltage: DC 9.0V-18.0V
Main Unit Standby Current: (=30mA@12V

LF Detecting Distance: 2m

Smart Key Working Voltage: DC 2.0V~DC 4.0V

Smart Key Standby Current: (=4uA@3V

Working Temperature: -40-+85 Centigrade

Remote Control Distance: 30m
