雷蒙磨粉机

本机适用于磨削重晶石，石灰石，高岭土，金属陶瓷，矿渣等，下面的莫氏硬度和280多名各种非易燃非易爆的东西，在开采行业，冶金工业，化学工程规模9.3 和建筑物料的高细制粉加工。 该产品的大小可调在80-325的范围内（600最大）的网格。 它可以生产30-80目粗粉通过特殊设备在机器中。

工作原理：

当它投入使用后，将粉碎的物料放入主框架通过侧盖馈入箱。 然后，它公转的磨煤辊的纵轴线挂在明星架子。 用的离心力由旋转，外和压力机碾磨辊翼快速上铣环铣削辊和环之间，使减轻刀具进料，从而将材料通过研磨辊的轧制和碾磨粉碎。

雷蒙磨粉机特点：

1.三维结构。
2，土地节约。
3.屏幕通过率能达到99％以上。
4.传动平稳可靠。
5.大型机的发送装置采用气密齿轮箱和纬向轮。
6.集中控制的电力系统，操作方便。

雷蒙磨粉机的技术参数

Raymond mill

The machine is used for grinding the barite, limestone, kaolin, ceramet, slags, etc, below scale 9.3 of Mohs hardness and 280-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgical industrial, chemical engineering and building material for high fine powder generation and processing. The product size is adjustable in the range of 80-325 (600 the largest) meshes. It is possible to produce 30-80 mesh coarse powder through special device in the machine.

Working principles:

When it is put into use, the materials to be grinded are put into the main frame through the feed-in bin on the side cover. Then it revolves round the vertical axis line by the milling roller hung on the star rack. With the centrifugal force by rotation, milling roller wings outside and presses fast on milling rings to make relieving tool carry materials between milling roller and ring, thus the materials are crushed by the rolling and milling of the milling roller.

Raymond Mill Features:

1. Three-dimensional structure.
2. Land-saving.
3. The screen-passing rate can reach to 99%.
4. The transmission is steady and reliable.
5. The transmission device of mainframe adopts airtight gear case and zonal wheel.
6. Centralized control for the electric system, convenient to operate.

Technical parameters of Raymond mill
