Cone Crusher
圆锥破碎机
议价
加入意向简要说明圆锥破碎机
圆锥破碎机 是一种新型的破碎机具有高工作性能和世界先进水平的由我们公司开发的技术水平，该机拥有金属与非金属矿，水泥厂，砂石冶金等行业广泛应用。
圆锥破碎机的主要类型
根据的破碎腔的种类 圆锥破碎机 ，它可分为标准型，中间型和短双头型; 并根据其不同的工作原理，它可以被分成 西蒙斯圆锥破碎机 ，弹簧圆锥破碎机和 液压圆锥破碎机 。 不同圆锥破碎机可以根据客户的具体要求来选择。
二级圆锥破碎机的主要特点
1.更高的容量和更低的磨损费用。
2.广泛的应用适用性。
3.易于维护，减少停机时间和维护成本。
4.稳定的运行性能，操作简便。
中国圆锥破碎机的结构
中国圆锥破碎机包括帧，发送装置，中空偏心轴，碗形轴承，破碎圆锥，弹簧和液压站，用于调节卸料口的。 在操作期间，马达驱动的偏心轴壳掉头通过水平轴和一对锥齿轮。 破碎圆锥摆动用的偏心轴壳上的力的轴，以使破碎壁的表面是接近辊砂浆壁不时。 以这种方式，将矿石和岩石将被压和弯曲和粉碎。
一个专业的圆锥破碎机供应商来自中国
河南红星矿山机器有限公司是一家专业 圆锥破碎机生产厂家 在中国，与 摇滚圆锥破碎机 本公司提供具有最好的质量和最具竞争力的价格。
圆锥破碎机技术参数
| 模型 | 破碎圆锥的直径（mm） | 最大。 进料尺寸（mm） | 宽排料口（毫米） | 处理能力（T / H） | 电机功率（kw） | 摇摆frequ-ency主轴 | 重量（t） | 外形尺寸（长*宽*高）（mm） | |
| PYB | 600 | 600 | 65 | 12-25 | 40 | 30 | 356 | 5 | 2234*1370*1675 |
| PYD | 35 | 3-13 | 12-23 | 5.5 | 2234*1370*1675 | ||||
| PYB | 900 | 900 | 115 | 15-50 | 50-90 | 55 | 333 | 11.2 | 2692*1640*2350 |
| PYZ | 60 | 5-20 | 20-65 | 11.2 | 2692*1640*2350 | ||||
| PYD | 50 | 3-13 | 15-50 | 11.3 | 2692*1640*2350 | ||||
| PYB | 1200 | 1200 | 145 | 20-50 | 110-168 | 110 | 300 | 24.7 | 2790*1878*2844 |
| PYZ | 100 | 8-25 | 42-135 | 25 | 2790*1878*2844 | ||||
| PYD | 50 | 3-15 | 18-105 | 25.3 | 2790*1878*2844 | ||||
| PYB | 1750 | 1750 | 215 | 25-50 | 280-480 | 160 | 245 | 50.3 | 3910*2894*3809 |
| PYZ | 185 | 10-30 | 115-320 | 50.3 | 3910*2894*3809 | ||||
| PYD | 85 | 5-13 | 75-230 | 50.2 | 3910*2894*3809 | ||||
| PYB | 2200 | 2200 | 300 | 30-60 | 59-1000 | 280-260 | 220 | 80 | 4622*3302*4470 |
| PYZ | 230 | 10-30 | 200-580 | 80 | 4622*3302*4470 | ||||
| PYD | 100 | 5-15 | 120-340 | 81.4 | 4622*3302*4470 | ||||
Brief Description of Cone Crusher
Cone crusher is a new crushing machine with high working performance and world advanced technical level developed by our company and this machine has wide application in metal and non-metallic ore and cement plant, sand and stone and metallurgy industry.
Major Types of Cone Crusher
According to the types of the crushing cavity of cone crushers, it can be divided into standard type, middle type and short-headed type; and according to their different working principle, it can be divided into Symons cone crusher, spring cone crusher and hydraulic cone crusher. Different cone crushers can be selected according to the specific requirements of the customers.
Main Features of Secondary Cone Crushers
1. Higher capacity and less wear costs.
2. Wide range of application suitability.
3. Easy to maintain, reduce the downtime and maintenance costs.
4. Stable running performance and easy operation.
Structure of China Cone Crusher
China cone crusher consists of frame, transmission device, hollow eccentric shaft, bowl-shaped bearing, crushing cone, springs and hydraulic pressure station for adjusting discharge opening. During operation, the motor drives the eccentric shaft shells to turn around through horizontal axle and a pair of bevel gear. The axle of crushing cone swings with the force of eccentric shaft shell so that the surface of the crushing wall is close to the roll mortar wall from time to time. In this way, the ores and rocks will be pressed and crooked and crushed.
A Professional Cone Crusher Supplier in China
Henan Hongxing Mining Machinery Co. , Ltd is a professional cone crusher manufacturer in China, and the rock cone crusher provided by our company has the best quality and the most competitive price.
Technical parameters of Cone crusher
| Model | Diameter of crushing cone (mm) | Max. feeding size (mm) | Width of discharge opening (mm) | Processing capacity (t/ h) | Motor power (kw) | Swing frequ-ency of main shaft | Weight (t) | Dimensions (L*W*H) (mm) | |
| PYB | 600 | 600 | 65 | 12-25 | 40 | 30 | 356 | 5 | 2234*1370*1675 |
| PYD | 35 | 3-13 | 12-23 | 5.5 | 2234*1370*1675 | ||||
| PYB | 900 | 900 | 115 | 15-50 | 50-90 | 55 | 333 | 11.2 | 2692*1640*2350 |
| PYZ | 60 | 5-20 | 20-65 | 11.2 | 2692*1640*2350 | ||||
| PYD | 50 | 3-13 | 15-50 | 11.3 | 2692*1640*2350 | ||||
| PYB | 1200 | 1200 | 145 | 20-50 | 110-168 | 110 | 300 | 24.7 | 2790*1878*2844 |
| PYZ | 100 | 8-25 | 42-135 | 25 | 2790*1878*2844 | ||||
| PYD | 50 | 3-15 | 18-105 | 25.3 | 2790*1878*2844 | ||||
| PYB | 1750 | 1750 | 215 | 25-50 | 280-480 | 160 | 245 | 50.3 | 3910*2894*3809 |
| PYZ | 185 | 10-30 | 115-320 | 50.3 | 3910*2894*3809 | ||||
| PYD | 85 | 5-13 | 75-230 | 50.2 | 3910*2894*3809 | ||||
| PYB | 2200 | 2200 | 300 | 30-60 | 59-1000 | 280-260 | 220 | 80 | 4622*3302*4470 |
| PYZ | 230 | 10-30 | 200-580 | 80 | 4622*3302*4470 | ||||
| PYD | 100 | 5-15 | 120-340 | 81.4 | 4622*3302*4470 | ||||
