简介颚式破碎机

颚式破碎机 是的主要类型的矿山或矿石加工厂主要破碎机之一。 它是一种碎石机的这也可以称为 碎石机 ，颚式破碎，石颚式破碎机，单肘颚式破碎机和聚集颚式破碎机。 这一系列的碎石机植物能达到4-6的破碎比和最终产品的形状是偶数。

特点和移动颚式破碎机的优点：

1.所述的腔 移动石颚式破碎机 深且无死区，以促进饲养能力和产出。

2.还原率的大小是大和生产规模是偶数。

3.调整垫片式的排矿口的设备方便可靠。 和初级颚式破碎机的调节范围大，从而提高了设备​​的灵活性。

的4润滑系统 移动式颚式破碎机 安全可靠。 部件更换方便。 和维护工作少。

5.它的结构简单，操作可靠。 操作费用低。

6.节能：单机节能减排是高，机器系统节能是两倍以上的单机。

7.出口的调节范围大，所以它能够满足不同客户的需求。

8.中国颚式破碎机的噪音低，粉尘少，当初级破碎机的工作。

石颚式破碎机的广泛应用：

该 石颚式破碎机 适合于所有和岩石一级和二级破碎与抗压强度小于320兆帕的行业如矿山，建材，化工，冶金等领域。 由于该石颚式破碎机主要用于破碎大型石头或石头，它也被称为岩石破碎机。 作为一家专业的颚式破碎机的供应商，宏兴机械移动式碎石机已经销售到75个国家; 颚式破碎机的价格和质量的广泛认可; 我们始终坚持为您满意的合作伙伴。

颚式破碎机的结构与工作原理：

颚式破碎机的主要结构是由机架，偏心轴，皮带轮，飞轮，动颚板，手腕板，可调间隙螺丝，弹簧抵消和固定颚板。 手腕板也有守卫的效果。

颚式破碎机采用电动机作为动力。 马达驱动带和皮带轮，使可动爪移动通过偏心轴。 当移动颚是向上，衬板和动颚之间的角度变大，这将推动移动颚板接近固定颚板。 在此过程中，将材料粉碎和研磨，从而粉碎将完成。 当移动颚是向下，衬板和动颚变小，动颚板将离开固定颚板是考虑的牵引杆和弹簧，然后，破碎的材料的效果之间的角度会从下部排出 开放粉碎室。 与电机连续旋转和材料周期性粉碎并排出由破碎机，大量生产，可以实现。

颚式破碎机技术参数

Brief Introduction to Jaw Crusher

Jaw crusher is one of the main types of primary crushers in a mine or ore processing plant. It is a kind of stone crusher which can also be called rock crusher, jaw breaker, stone jaw crusher, single toggle jaw crusher and aggregate jaw crusher. This series of stone crusher plant can reach the crushing ratio of 4-6 and the shape of final product is even.

Features and Benefits of Mobile Jaw Crusher:

1. The cavity of mobile stone jaw crusher is deep and with no dead area, to promote feeding capacity and output.

2. The size of the reduction ratio is big and the production size is even.

3. Adjustment device of the spacer style discharge mouth is convenient and reliable. And primary jaw crusher's adjustment range is big, which improves the flexibility of equipment.

4. Lubrication system of the mobile jaw crusher is safe and reliable. Unit replacement is convenient. And the work of maintenance is small.

5. Its structure is simple and operation is reliable. The operation charge is low.

6. Energy conservation: single machine's energy conservation is high and the machine system energy conservation is more than twice of the single machine.

7. The adjustment range of the outlet is big, so it can satisfy the requirement of different customers.

8. The noise of China jaw crusher is low and dust is little when primary crushers work.

Wide application of Stone Jaw Crusher:

The stone jaw crusher is suitable for primary and secondary crushing for all and rocks with compressive strength less than 320 MPa in the industries as mining, building materials, chemical industry and metallurgy. Since this stone jaw crusher is mainly used for crushing large-sized stone or rocks, it is also called rock crushers. As a professional jaw crusher supplier, Hongxing Machinery mobile stone crushing machine has been sold to 75 countries; the price and quality of jaw crushers are widely recognized; we always stick to being your satisfying partner.

The Structure and Working Principle of Jaw Crusher:

The main structure of the jaw crusher is composed of stander, eccentric shaft, belt pulley, flywheel, movable jaw plate, wrist plate, adjustable gap screw, offsetting spring and fixed jaw plate. The wrist plate also has the effect of guarding.

Jaw crusher uses motor as its power. The motor drives the belt and belt pulley to make the moveable jaw move through the eccentric shaft. When the moving jaw is up, the angle between lining plate and moving jaw becomes large, and this will push moving jaw plate close to the fixed jaw plate. During this process, the material is crushed and ground, thus the crushing will be done. When the moving jaw is down, the angle between lining plate and moving jaw becomes small, the moving jaw plate will leave the fixed jaw plate on account of the effect of pulling bar and spring, and then the crushed material will be discharged from the lower opening of the crushing room. With the motor continuously rotating and the material periodically crushed and discharged by the crusher, the mass production can be realized.

Technical parameters of Jaw crusher
