Belt Conveyor

Belt Conveyor

皮带传输机

议价

加入意向

用法：

我公司生产的皮带输送机具有输送量大，结构简单，维修方便和标准件的优点，因此被广泛应用于矿山，冶金，煤炭行业输送松散物料及成品。 根据不同的技术要求，本机可以单独输送材料来形成，或者输送系统与其他输送设备，以满足工作线路的不同的要求。
的工作温度为-20o C至+ 40o C和输送物料的温度低于50oC.

附件：

1.输送量由以下条件计算出：材料密度在1.0吨/米3 -1.6t /平方米3 ; 输送带倾角小于18o 并且材料储存角为30o.
2.密度材料的小于2.5吨/米3.
3.传送长度不限于形式; 不同的长度可根据客户的要求进行生产。


皮带输送机的技术参数

皮带宽度（mm） 输送长度（m）
功率（kw）

输送速度（m / s）的

输送量（T / H）

500

(=12
3
12-20
4-5.5
20-30
5.5-7.5

1.3-1.6

78-191

650

(=12
4
12-20
5.5
20-30
7.5-11

1.3-1.6

131-323

800

(=6
4
6-15
5.5
15-30
7.5-15

1.3-1.6

278-546

1000

(=10
5.5
10-20
7.5-11
20-40
11-22

1.3-2.0

435-853

1200

(=10
7.5
10-20
11
20-40
15-30

1.3-2.0

655-1284

Usage:

The Belt conveyor manufactured by our company has the advantages of big conveying capacity, simple structure, convenient repair and standard parts, so it is widely used in the industries of mine, metallurgy and coal to convey loose materials and finished products. According to different technique requirements, the machine can convey material singly or be formed conveying system with other conveying equipments to meet different requirements of working line.
The working temperature is from -20oC to +40oC and the temperature of conveying material is under 50oC.

Accessory:

1. The conveying quantity is worked out by the following conditions: material density is between 1.0t/ m3-1.6t/ m3; conveyor obliquity is less than 18o and the material stockpile angle is 30o.
2. Density of material is less than 2.5t/ m3.
3. The conveying length is not restricted to the form; different length can be manufactured according to customers demands.


Technical parameters of belt conveyor

Belt width (mm) Conveying length (m)
Power (kw)

Conveying speed (m/ s)

Conveying amount (t/ h)

500

(=12
3
12-20
4-5.5
20-30
5.5-7.5

1.3-1.6

78-191

650

(=12
4
12-20
5.5
20-30
7.5-11

1.3-1.6

131-323

800

(=6
4
6-15
5.5
15-30
7.5-15

1.3-1.6

278-546

1000

(=10
5.5
10-20
7.5-11
20-40
11-22

1.3-2.0

435-853

1200

(=10
7.5
10-20
11
20-40
15-30

1.3-2.0

655-1284
