的雷蒙磨粉机/雷蒙德粉碎机应用

本机适用于磨削重晶石，石灰石，高岭土，瓷土，化渣等，以下规模的莫氏硬度和280多名各种非易燃非易爆的东西，在开采行业，冶金工业9.3， 化工，建材的高细制粉加工。 该产品的大小可调在80-325的范围内（600最大）的网格。 是可能的产品30-80通过在机器特殊装置目的粗粉。

雷蒙磨粉机的主要配件

该雷蒙磨粉机由电动机，减速器，案例，铣设备，分离器，插座，送煤管，加载装置，控制箱和密封装置。 该配件是所有卓越的性能在目前世界上。 我们保证整个雷蒙磨粉机机良好的品质和耐用性。

该功能与雷蒙磨粉机的好处

一个。 所需的混凝土底座重量只有3倍，是其他同类机器从而建设费用大大降低;

湾 而使用，并不需要缓冲装置小的震动;

C。 大的载荷调整范围内，所以可以在各种环境下运行;

ð。 能承受很强的爆炸压力;

即 磨辊采用新材料，新工艺，确保使用寿命长，维护成本低;

F。 还有就是磨部件之间的间隙; 它可以与负载或卸载开始。

雷蒙磨粉机的工作原理

当它投入使用后，将粉碎的物料放入主框架通过侧盖馈入箱。 然后，它公转的磨煤辊的纵轴线挂在明星架子。 用的离心力由旋转，外和压力机碾磨辊翼快速上铣环铣削辊和环之间，使减轻刀具进料，从而将材料通过研磨辊的轧制和碾磨粉碎。

维护雷蒙磨粉机的小常识

1）。 安装前的装备，所有谁将会被分配到操作设备的人都必须经过技术培训，以了解原理和操作规则。 有人应精心挑选，并投入了负责操作。

2）。 为了保证设备的正常运行，包括它的运行，维护和修理严格的规则和程序手册应做好充分准备，并紧随其后。 工具，零件的维护，修理和润滑油及油脂一定是可立即使用。

3）。 经过一段时间的使用，该设备应进行检查，更换破旧和破坏的零件，如辊，戒指和铲子。 一定要拧紧连接螺栓，螺母项圈妥善解决辊。 一定要润滑部位充分。

4）。 辊应500小时的使用时间后进行更换。 要检查轴承在其中并更换破损的，然后填入足够的润滑油和润滑脂（油泵或润滑脂枪）。

雷蒙粉碎机，雷蒙磨粉机出售

雷蒙德粉碎机（雷蒙磨）是相当通用的，雷蒙德粉碎机（雷蒙磨）可以用来研磨重晶石，方解石，钾，滑石，大理石，玻璃，长石，等。 雷蒙粉碎机（雷蒙磨粉机）广泛应用于冶金，建材，化工，矿山领域。 在雷蒙磨的腔室，由于雷蒙德粉碎机（雷蒙磨）的东西可包含湿气在一定程度上时产生的热量使水分蒸发。 雷蒙粉碎机其他功能可能涉及钻孔，镗孔或槽中产。 雷蒙磨可以概括地描述为降低材料微细化的大小虽然雷蒙磨是从粉碎和造粒不同的过程。

雷蒙磨粉机的技术参数

Application of Raymond mill / Raymond grinder

The machine is used for grinding the barite, limestone, kaolin, porcelain clay, and slag, etc, below scale 9.3 of Mohs hardness and 280-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgical industrial, chemical engineering and building material for high fine powder generation and processing. The product size is adjustable in the range of 80-325 (600 the largest) meshes. It is possible to product 30-80 mesh coarse powder through special device in the machine.

Main fittings of Raymond mill

The Raymond mill consists of motor, reducer, case, milling device, separator, outlet, coal feeding pipe, loading device, control box and sealing apparatus. The fittings are all of superior performance in the world at present. We ensure good quality and durability of the whole Raymond mill machine.

The features & benefits of Raymond mill

a. The concrete base weight required is only 3 times of that of other similar machines thus the construction expenses is greatly reduced;

b. Small vibration while using and doesn't need shock-absorbing device;

c. Large load adjustment scope, so it can run under various environments;

d. Can bear very strong explosion pressure;

e. The grinding roller adopts new material and new craft, which ensures long service life and low maintenance cost;

f. There is gap between the grinding parts; it can start with load or offload.

Working principle of Raymond mill

When it is put into use, the materials to be grinded are put into the main frame through the feed-in bin on the side cover. Then it revolves round the vertical axis line by the milling roller hung on the star rack. With the centrifugal force by rotation, milling roller wings outside and presses fast on milling rings to make relieving tool carry materials between milling roller and ring, thus the materials are crushed by the rolling and milling of the milling roller.

Little common knowledge on maintenance of Raymond mill

1) . Prior to installation of the equipment, all the people who will be assigned to operate the equipment have to be technically trained to know the principle and rules of operation. Someone should be specially selected and put in charge of the operation.

2) . To ensure normal operation of the equipment, a manual containing strict rules and procedures for its operation, maintenance and repair should be well prepared and followed. Tools, replacement parts for maintaining, repairing and lubricating oil and grease must be available for immediate use.

3) . After a period of usage, the equipment should be checked, to replace worn-and-torn parts such as rollers, rings and shovels. Be sure to fasten connecting-bolts, nut collars to fix rollers properly. Be sure to lubricate the parts sufficiently.

4) . Roller should be replaced after 500-hours use. To check bearing in them and replace broken ones, and then fill enough oil and grease (with oil-pump or grease-gun) .

Raymond grinder, Raymond mill for sale

The Raymond grinder (Raymond mill) is rather versatile and the Raymond grinder (Raymond mill) can be used to grind barite, calcite, kalium, steatite, marble, glass, feldspar, ect. Raymond grinder (Raymond mill) is widely used in the metallurgy, building, chemical industry, mine field. In the chamber of Raymond mill, since the stuff of Raymond grinder (Raymond mill) may contain moisture to some extent, the heat generated during makes the moisture evaporated. Raymond grinder further functions may involve drilling, boring or slot producing. Raymond mill can be broadly described as the process of reducing the material to finer size though Raymond mill is different from crushing and granulation.

Technical parameters of Raymond mill
