High-strength Raymond mill

High-strength Raymond mill

高强度雷蒙磨粉机

议价

加入意向

高强度的雷蒙磨粉机用于粉碎重晶石，石灰石，高岭土，陶瓷，矿渣等，下面莫氏和280多名各种非易燃非易爆的东西规模9.3的硬度开采行业， 冶金，化工，建材物料的高细制粉加工。

该产品大小可调，在80-425的范围内（1000最好的）网格。 它可以生产30-80目粗粉通过特殊设备在机器中。

高强度雷蒙磨粉机的技术参数

类型 高strength97 高strength93 高strength86A 高strength66
进料尺寸（mm） (=25 (=25 (=20 (=15
成品尺寸（mm） 0.125-0.033 0.613-0.033 0.125-0.033 0.125-0.033
在不同的材质成色班产量（T） 4-55 3.5-40 3-33 1-20
旋转中心轴的转速（转/分） 130 160 160 180
pulverzing环的直径（mm） 1050 1006 907.5 725
pulverzing辊直径（mm） 310 300 270 210
粉碎辊的高度（mm） 170 160 150 150
主电机 y225s-4-37 Y225M-8-30 Y225M-8-32 y200L-8-15
风扇电动机 y200L-4-30 y200m-2-22 y160E-4-18.5 Y160M-4-11
分析电机 yc120-4A-5.5 yc122-6-3 Y112M-6-2.2 Y112M-6-2.2

High-strength Raymond mill is used for grinding the barite, limestone, kaolin, ceramics and slags, etc, with the hardness below scale 9.3 of Mohs and 280-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgical industry, chemical engineering and building material for high fine powder generation and processing.

The product size is adjustable in the range of 80-425 (1000 the finest) meshes. It is possible to produce 30-80 mesh coarse powder through special device in the machine.

Technical parameters of High-strength Raymond mill

Type High-strength97 High-strength93 High-strength86A High-strength66
Feeding size (mm) (=25 (=25 (=20 (=15
Size of finished product (mm) 0.125-0.033 0.613-0.033 0.125-0.033 0.125-0.033
shift output at different material fineness (t) 4-55 3.5-40 3-33 1-20
Rotate speed of central shaft (r/ min) 130 160 160 180
Diameter of pulverzing ring (mm) 1050 1006 907.5 725
Diameter of pulverzing roller (mm) 310 300 270 210
Height of pulverizing roller (mm) 170 160 150 150
Main Motor y225s-4-37 y225m-8-30 y225m-8-32 y200L-8-15
Fan Motor y200L-4-30 y200m-2-22 y160E-4-18.5 y160m-4-11
Analyzer motor yc120-4A-5.5 yc122-6-3 y112m-6-2.2 y112m-6-2.2
