自动门操作员LS-100

议价
加入意向门自动
1.自动门,15种功能调节
2.自动门,数字显示
3. CE certifacated
| 门样式 | 单叶或双叶 |
| 门宽 | 650毫米〜1300毫米 |
| 门weight.max | 150kgs 150kgsX2 |
| 电源 | 90VAC〜250VAC,50 / 60Hz的 |
| 电压输出 | 12V DC,24V DC |
无刷电机 | 55W,24V DC |
| 打开速度和关闭速度 | 250〜550毫米/ S |
爬行速度 | 20〜百毫米/ S |
| 手动开启力 | (50N |
| 保持闭力 | 150N(F(250N |
| 保持开放时间 | 0-9s(可调) |
1.数码显示与指示灯直接提供有关门的状态信息。
2,采用数字通信模式设置参数,避免了使用螺丝刀设置参数,从而避免氧化,使参数改变长期的联系点。
3.宽电压范围可满足低电压和宽电压波动。
4.完成功能可以让用户选择不同的模式打开和关闭的门。
5,合理的机械结构,美观的表面处理,使安装和调试简便
6.有远程参数设置界面的控制器,实现无线遥控参数设置。
7.强大的智能自动关闭功能,在锁定时,计算机将输出多变的智能功率通过监测门的雕像电机,它是能源效率和可实现安全关闭。
8.主要功能接口包括:永久开放,部分开放,内锁,外锁,全锁,火灾报警,联锁,读卡器,安全光束传感器。
9.人性化的设计,使门的安装和接线方便。
10.手动模式和远程控制模式,实现快速方便的模式改变。
11.使用数字微处理器,并采用非接触式控制内部信号回路,开闭准确。
12.采用直流无刷电机,以及蜗轮,蜗杆旋转,启动转矩大,运行安静,使用寿命长,特别适用于安静的环境中,如办公楼,银行,公寓楼。
door automatic
1. Automatic door, 15 functions adjustable
2. Automatic door, digital display
3. CE certifacated
| Door style | single leaf or double leaf |
| Door width | 650mm~1300mm |
| Door weight.max | 150kgs 150kgsX2 |
| Power supply | 90VAC~250VAC, 50/60Hz |
| Voltage output | 12V DC, 24V DC |
Brushless Motor | 55W, 24V DC |
| Opening speed and closing speed | 250~550mm/ S |
Creep speed | 20~100mm/ S |
| Manual opening Force | (50N |
| Hold-Close Force | 150N (f (250N |
| Hold-open time | 0-9s (adjustable) |
1. A digital display and indicator light directly provides information regarding the status of the doors.
2. Adopting digital communication mode to set parameters, avoiding using screwdriver to set parameters, so avoiding long-term contact point oxidated to make parameter changed.
3. The wide voltage range can meet undervoltage and the wide voltage fluctuation.
4. Complete functions can make users to choose various modes to open and close doors.
5. Reasonable mechanical structure, and beautiful surface treatment, making installation and debugging easy
6. There are remote parameter setting interface in the controller, realizing wireless remote parameter setting.
7. Powerful intelligent self-closing function, at the statue of locked, computer will output changeable intelligent power to motor through monitoring doors, it is energy-efficient and can realize safe closing.
8. Main function interfaces include: permanent open, partial open, inside lock, outside lock, full lock, fire alarm, interlock, card reader, safety beam sensor.
9. Human design, making door installation and wiring easy.
10. Manual mode and remote control mode to realize quick and easy mode change.
11. Using digital microprocessor, and adopting contactless control for inside signal loop, open and close accurately.
12. Adopting DC brushless motor, and worm gear, worm rotation, starting torque is big, quiet running, long life, especially for quiet environments, such as office building, bank, apartment building.
