Carbide Serrated Blade Welding Equipment | Ultra-high Frequency Induction Equipment, Application For Heating Industry, Such As Welding, Forging, Brazing, Heat Through, Etc | HONGCHUANG CGP-6.0\20\30

Carbide Serrated Blade Welding Equipment | Ultra-high Frequency Induction Equipment, Application For Heating Industry, Such As Welding, Forging, Brazing, Heat Through, Etc | HONGCHUANG CGP-6.0\20\30

硬质合金锯齿刀片焊接设备| 超高频感应设备，应用程序对供热行业，如焊接，锻造，钎焊，热透，等| 宏创CGP-6.0 / 20/30

议价

加入意向
产品特点
体积小，节省空间，操作方便;
微机软件自动补货频率，以减少传感器头生产要求，面板只有一个电源开关和一个电源调节触摸一个按钮，操作非常简单;
高频加热输出稳定，工作加热无振动，以确保精确的焊接位置，焊接最小直径0.1毫米细金属。 传感器可以根据工件的不同形状进行定制。
范围
焊接材料：铜和黄铜焊接，钨钢和不锈钢的焊接，铁和铜，铜和铝焊的焊接;
消费品：眼睛饰品，珠宝，手表焊接，渔具，渔具，五金等产品的焊接;
工具行业：硬质合金锯片锯齿的焊接，焊接工具，产品的热处理的硬质合金刀具;
电子行业：电机转子热装配，刀柄与热电极银焊焊接，焊接振荡器，焊接接头;
娱乐：木管配件焊接，高尔夫球头的焊接;
金属植入物：灯泡播放电极。
型号/参数：

模型

CGP-6.0KW

CGP-12KW

（增强版）

CGP-20KW

CGP-30KW（

CGP-40KW

输入电源电压

单相220V 50-60赫兹

三相380V

电电流A

0.2-25

0.4-50

0.6-30

1.0-45

1.2-50

最大输出功率KW

0-5.2

0-11

20

30

40

输出振荡frequencyMHz

1-1.2

1-1.7

50-250

50-200

占空比

100%

冷却水温度

(35℃

冷却水压力

）1.1Mpa

）为0.5MPa

为0.2Mpa，6L /分钟

卷立方厘米

28*28.8*14.5

（主机）

37.5*35.5*18

（主机）

50*52*47

（主机）

12*60*10.5
（扩展）

26*40*39
（扩展）

31*45*44
（扩展）

36*55*49
（扩展）

感应回路管道

外径2.0毫米
内径1.4毫米

可以根据工件生产的尺寸和形状进行定制

重量（Kg）

18

25

34


Product Features
Small size, space-saving, easy to operate;
Microcomputer software automatic replenishment frequency to minimize the sensor head to production requirements, the panel has only a power switch and a power adjust the touch of a button, the operation is very simple;
High frequency heating output stable, working heating no vibration, to ensure precise welding position, welding minimum diameter 0.1mm fine metal. The sensors can be customized according to the different shapes of the workpiece.
Scope
Welding materials: copper and brass welding, tungsten steel and stainless steel welding, the welding of iron and copper, copper and aluminum welding;
Consumer goods: Eye jewelry, jewelery, watches welding, fishing gear, fishing tackle, hardware products such as welding;
Tool industry: Carbide serrated blade welding, welding tools, carbide cutting tools of the heat treatment of the product;
Electronics industry: motor rotor thermal assembly, shank heat with the electrode silver solder welding, welding oscillator, welding connector;
Entertainment: Woodwind accessories welding, golf head welding;
Metal implants: the bulb playing electrode.
Model / Parameters:

Model

CGP-6.0KW

CGP-12KW

(Enhanced)

CGP-20KW

CGP-30KW (

CGP-40KW

Input supply voltage

Single-phase220V 50-60Hz

Three-phase380V

Electric current A

0.2-25

0.4-50

0.6-30

1.0-45

1.2-50

Maximum output powerKW

0-5.2

0-11

20

30

40

Output oscillation frequencyMHz

1-1.2

1-1.7

50-250

50-200

Duty cycle

100%

Cooling water temperature

(35℃

Cooling water pressure

) 1.1Mpa

) 0.5Mpa

0.2Mpa, 6L/ min

Volume cm³

28*28.8*14.5

(Host computer)

37.5*35.5*18

(Host computer)

50*52*47

(Host computer)

12*60*10.5
(Extension)

26*40*39
(Extension)

31*45*44
(Extension)

36*55*49
(Extension)

An induction loop tube

Outer diameter 2.0mm
Inner diameter 1.4mm

Can be customized according to the size and shape of the workpiece production

Weight Kg

18

25

34
