A simple description of HB1158CR1 GU3310A/ GU3311A controller

Harsen? Page 1/6

This information is for the use of GU3310A/ GU3311A controller provides fast operating guidelines, please refer to the instructions for use with standard.

A controller, the size of the:

Size of installation hole size

W120mm * H102mm * D48mm W109mm * H91mm

Two, parameter setting method:

1, the main keys

Automatic mode key / indicator

Manual mode key / indicator

The generator start / parameter settings to increase the + button

Stop key / reset / parameter settings to reduce the - key

Silencing key / lamp test (press two seconds all lights and bright)

PgUp / parameter settings of the entry and exit / parameter settings confirm key

2, setting method:

Example: set the controller's turning for the number 2

Description of operation

A long press enter two seconds, parameter settings menu, liquid crystal display then:

[setting]

The 0 exit

The 1 system parameters

2 generator parameters

The 3 engine parameter

According to the + button two times can press the key, the liquid crystal display then:

[parameters]

The 0 exit

The 1 type of engine

2. ECU type

The 3 engine rated speed

'+ button nine times can press the key, the liquid crystal display then:

[turning attempts]

3

According to the + or - key password prompt, enter password: 2213, according to

Enter.

[turning attempts]

Password: 0000

The correct password and press + or - key to change parameters. This modification is 2.

[turning attempts]

2

'Key confirm change, long press two seconds can exit the parameter settings menu ready

A simple description of HB1158CR1 GU3310A/ GU3311A controller

Harsen? Page 2/6

Three, parameter setting project:

1, the system parameters

Number of project preset value project preset number

1.1 language 1.10 voltage type 1

1.2 password 1.11 display contrast 5

1.3 hydraulic unit 1.12 the brightness of the display 5

1.4 1.13 1 unit energy-saving brightness temperature

1.5 open mode 1.14 without the use of an automatic page turning time

1.6 current transformer ratio 1000: 5 1.15 startup alarm 0

The 1.7 voltage transformer ratio 1.0: 1 1.16 switching pulse continuous

1.8 the rated voltage value 220V 1.17 reset to the manual mode 0

1.9 of the rated current value 1000A 1.18 to restore the default value

2, the generator parameters

Number of project preset value project preset number

2.1 power voltage monitoring type 12.10 power flow 1110%

The 2.2 generation low voltage 190% 2.11 power flow 2200%

The 2.3 generation low voltage 20% 2.12 power switch on for 5 seconds

The 2.4 generation high voltage of 1115% 2.13 power switching off 5 seconds

The 2.5 generation high voltage power load voltage of 95% 2999% 2.14

The 2.6 generation of low frequency 1 48.0Hz 2.15 power load frequency 48.0Hz

The 2.7 generation of low frequency 2 0.0Hz 2.16 power supply 5 second delay

The 2.8 generation high frequency 1 55.0Hz 2.17 soft unloading time of 5 seconds

The 2.9 generation high frequency 2 57.0Hz

3, the engine parameters

Number of project preset value project preset number

Do not use the 3.1 type of engine idling time 13.24

3.2 ECU type 0 does not use 3.25 preheating mode 1

The 3.3 engine rated speed 15003.26 preheating time of 3 seconds

3.4 speed sensor input 3.27 safety supervision 10 second delay

The 3.5 flywheel tooth number 1203.28 cooling mode 1

3.6 set the sensor frequency 3.29 cooldown by 300 seconds

3.7 generator poles 23.30 stop time of 20 seconds

3.8 oil supply valve type 3.31 external turning allows 0

3.9 start delay 10 seconds 3.32 charger failure 8.0V

3.10 turning to try 3 times 3.33 speed sensor signal function 1

3.11 critical turning speed 6 times 3.34 grade 11600 RPM

The 3.12 turning time of 8 seconds 3.35 overspeed level 21710 RPM

The 3.13 turning time increased without the use of 3.36 low - grade 1 1440RPM

The 3.14 turning 15 seconds 3.37 low - grade 20 RPM

3.15 ignition speed 200RPM 3.38 failed to start 6

3.16 speed of ignition delay 5 seconds 3.39 stop failure 3

3.17 ignition delay 5 seconds 3.40 battery of high voltage of 35 V

3.18 gas valve open delay 5 seconds 3.41 battery low voltage of 8 V

3.19 barring cut speed 300RPM 3.42 maintenance 1000

The 3.20 turning off power voltage of 85% 3.43 ECU data fault 2

The 3.21 turning off the charging voltage without the use of 3.44 ECU warning 2

The 3.22 turning off oil 2.2 Bar 3.45 ECU down 2

The 3.23 turning off oil pressure delay does not use

A simple description of HB1158CR1 GU3310A/ GU3311A controller

Harsen? Page 3/6

4, setting the analog input

Number of project preset value project preset number

4.1 pressure sensor type 44.13 low oil level value of 120%

4.2 low oil level value of 1 1.4Bar 4.14 low oil level value of 210%

4.3 low oil level value of 2 1.1Bar 4.15 oil pump drive level 20%

4.4 types of temperature sensors 34.16 pump stop level 70%

4.5 grade of high temperature value at 192 DEG 4.17 auxiliary low temperature 160 Degree grade

4.6 grade of high temperature value at 2100 DEG 4.18 auxiliary low temperature 250 Degreegrade

4.7 preheating on level 50 Degree 4.19 auxiliary grade of high temperature 190 Degree

4.8 preheating stop level 60 Degree 4.20 grade of high temperature 2100 Degree

4.9 cooling levels at 80 Degree preheated 1 open 4.21 level value of 50 Degree

4.10 cooling stop level 70 Degree 4.22 preheating 1 stop level value of 60 Degree

The 4.11 auxiliary sensor uses 14.23 cooling 1 level 80 Degree

The 4.12 auxiliary sensor type 34.24 cooling 1 stop level value of 70 Degree

5, set the input and output

Number of project preset value project preset number

The 5.1 switch input 1 defines 65.5 relay 2 defined 1

The 5.2 switch input 2 defines 25.6 relay 3 defined 0

The 5.3 switch input 3 defines 35.7 relay 4 defined 0

5.4 relay 1 definition 25.8 relay 5 defined 0

7, switching control

Number of project preset value project preset number

7.1 voltage monitoring type 17.9 electric high frequency return value 52.0Hz

7.2 electrical low voltage fault value 90% 7.10 electric fault recognition time of 5 seconds

7.3, low voltage electrical returns a value of 95% 7.11 city power delay of 5 seconds

7.4 city high voltage electrical fault value 115% 7.12 electric switch on for 5 seconds

7.5 electric high voltage returns the value 110% 7.13 electric switch off 5 seconds

7.6, low frequency electric fault value 45.0Hz 7.14 current input type 0 generation

7.7, low frequency electric return value 48.5Hz 7.15 limit returned 0 does not use

7.8, high frequency electric fault value 57.0Hz

8, maintenance settings

Number of project preset value project preset number

8.1 8.7 Wednesday 0 effective date and time

8.2 scheduling mode load 8.8 on Thursday 0

8.3 start time HH: MM 8.9 on Friday 0

8.4 duration 60 8.10 points Saturday 0

8.5 Monday 8.11 Sunday 0

8.6 on Tuesday 8.12
