96 kg\m3 fireproof insulating blanket for heating furnace

96 kg\m3 fireproof insulating blanket for heating furnace

加热炉96个千克/立方米防火绝缘毯

0.9 USD

加入意向

快速详细信息

  • 等级：HP（高纯度）
  • 应用：衬板工业炉
  • 厚度：10-50mm
  • 宽度：610毫米
  • 长度：7200毫米3600毫米
  • 化学成份：AL2O3 52-55％
  • 极限强度（≥兆帕）：0.08-0.12
  • 工作温度：1200℃
  • 收缩（1800℉，3H）-4（1000℃）
  • 密度（公斤/立方米）：160
  • 型号：高维毯
  • 品牌名称：云台山
  • 产地：山东省，中国（大陆）
  • 颜色：白

包装及送货

包装细节： 纸箱或编织袋
交货详细信息： 根据客户需求

技术指标

1.长陶瓷纤维
2.密度= 64 96 128个千克/立方米
3.炉，窑衬
4. customersized服务

1.温度分类

COM硅酸铝摆动纤维毡1100℃

ST硅酸铝摆动纤维毡1260Ç

HP硅酸铝摆动纤维毡1260 CHA硅酸铝摆动纤维毡1360Ç

HAZ硅酸铝摆动纤维毡1360Ç

HZ硅酸铝摆动纤维毡1430Ç

2.工作温度

工作温度是通过使用条件下，加热方式及环境气氛等确定

3.生产ENGEERING

摆动纤维毯具有长纤维甚至直径和低沉积物球，在纤维交织改进的功能，抗层个划分的耐风蚀，柔韧性和抗张强度，从而提高了应用函数和减小的材料的损失。 摆动blandest不使用任何具有约束力的准备，以确保该产品具有在各种环境下的完美责任和稳定性。

4.技术特点：

低导热率和低蓄热

优良的热稳定性及抗热振性

优异的耐侵蚀性

优良的隔热，防火和处理功能

5.应用：

工业炉，炉，高温管道的内壁。

电力炉，核电站和隔热。

化学工业高温反应设备及隔热衬垫。

防火，高层建筑的保温。

隔热窑门和盖子。

高温过滤材料。

项目

COM

ST

生命值

哈

HAZ

赫兹

分类温度℃

1100

1260

1260

1360

1360

1430

工作温度℃

1000

1050

1100

1200

1200

1350

密度千克/立方米

96

128

96

128

96

128

128

160

128

160

128

160

永久线性收缩（％）（保持​​温度24小时，密度128千克/立方米）

-4 (1000'C)

-3 (1000'C)

-3 (1100'C)

-3 (1250'C)

-3 (1250'C)

-3 (1350'C)

热导率（W / m.k的）密度128千克/立方米）

0.09 (400'C)

0.176 (800'C)

0.09 (400'C)

0.176 (800'C)

0.09 (400'C)

0.176 (800'C)

0.22 (1000'C)

0.132 (600'C)

0.22 (1000'C)

0.132 (600'C)

0.22 (1000'C)

0.176 (600'C)

0.22 (1000'C)

拉伸强度（Mpa）density128kg /立方米）

0.08-0.12

0.08-0.12

0.08-0.12

0.08-0.12

0.08-0.12

0.08-0.12

化学药品

组成

(%)

AL2O3

42-44

45-46

47-49

52-55

45-46

39-40

AL2O3 + SIO2

96

97

99

99

-

-

AL2O3 + SiO2和氧化锆

-

-

-

-

99

99

氧化锆

-

-

-

-

5-7

15-17

氧化铁

(1.2

(1.0

0.2

0.2

0.2

0.2

的Na2O + K2O

(0.5

(0.5

0.2

0.2

0.2

0.2

尺寸（mm）

常见7200X610X10-50; 7200x1220x10-50

其它可根据客户的要求做

Quick Details

  • Grade: HP (High Pure)
  • Application: Liners Of Industrial Furnace
  • Thickness: 10-50mm
  • Width: 610mm
  • Length: 7200mm 3600mm
  • Chemical Composition: AL2O3 52-55%
  • Ultimate Strength (≥ MPa) : 0.08-0.12
  • Working Temperature: 1200℃
  • Shrinkage (1800 ℉, 3h) : -4 (1000℃)
  • Density (kg/ m³ ) : 160
  • Model Number: kaowool blanket
  • Brand Name: Yuntai
  • Place of Origin: Shandong, China (Mainland)
  • color: white

Packaging & Delivery

Packaging Details: Carton Box or woven bag
Delivery Detail: according to customer requirement

Specifications

1. long ceramic fiber
2. density=64 96 128 kg/m3
3. furnace and kiln lining
4. customersized service

1. TEMPERATURE CLASSIFICATION

COM alumina silicate swinging fiber blankets 1100 C

ST alumina silicate swinging fiber blankets 1260 C

HP alumina silicate swinging fiber blankets 1260 CHA alumina silicate swinging fiber blankets 1360 C

HAZ alumina silicate swinging fiber blankets 1360 C

HZ alumina silicate swinging fiber blankets 1430 C

2. OPERATING TEMPERATURE

Operating temperature is determined by using conditions, heating manners and environment atmosphere, etc.

3. PRODUCTION ENGEERING

The swinging fiber blankets have long fibers with even diameters and low sediment balls with improved functions in fiber interweaving, resisting layers divided resisting wind erosion, pliability and tensile strength, thus have improved the applied function and reduced the loss of materials. The swinging blandest does not use any binding preparation to make sure that the products possess perfect liability and stability under all kinds of environment.

4. TECHNICAL FEATURE:

Low thermal conductivity and low heat storage

Excellent thermal stability and thermal vibration resistance

Excellent erosion resistance

Excellent heat insulation, fire proofing and processing function

5. APPLICATION:

Industrial furnace, heaters, inside wall of high temperature tube.

Electric power furnace, nuclear power station and heat insulation.

Liners of chemical industry high temperature reaction equipment and heat insulation.

Fire proofing and heat insulation of high building.

Heat insulation for kiln door and lid.

Filtration material of high temperature.

Item

COM

ST

HP

HA

HAZ

HZ

Classification Temperature C

1100

1260

1260

1360

1360

1430

Working Temperature C

1000

1050

1100

1200

1200

1350

Density kg/ m3

96

128

96

128

96

128

128

160

128

160

128

160

Permanent linear shrinkage (%) (holding temperature for 24h, density 128kg/ m3)

-4 (1000'C)

-3 (1000'C)

-3 (1100'C)

-3 (1250'C)

-3 (1250'C)

-3 (1350'C)

Thermal conductivity (w/ m.k) density 128kg/ m3)

0.09 (400'C)

0.176 (800'C)

0.09 (400'C)

0.176 (800'C)

0.09 (400'C)

0.176 (800'C)

0.22 (1000'C)

0.132 (600'C)

0.22 (1000'C)

0.132 (600'C)

0.22 (1000'C)

0.176 (600'C)

0.22 (1000'C)

Tensile strength (Mpa) density128kg/m3)

0.08-0.12

0.08-0.12

0.08-0.12

0.08-0.12

0.08-0.12

0.08-0.12

Chemical

Composition

(%)

AL2O3

42-44

45-46

47-49

52-55

45-46

39-40

AL2O3+SIO2

96

97

99

99

-

-

AL2O3+SIO2+ZrO2

-

-

-

-

99

99

ZrO2

-

-

-

-

5-7

15-17

Fe2O3

(1.2

(1.0

0.2

0.2

0.2

0.2

Na2O+K2O

(0.5

(0.5

0.2

0.2

0.2

0.2

Size (mm)

Common 7200X610X10-50; 7200x1220x10-50

Other made according to customer's requirement
