Low Magnification Zoom Stereo Microscope 3D For Clinical
低倍率变焦体视显微镜3D临床
议价
加入意向快速详细信息
BS-1000单目变焦显微镜是提供高分辨率，锋利和强大的立体图像的精密的光学系统。
介绍
BS-1000单目变焦显微镜是提供高分辨率，锋利和强大的立体图像的精密的光学系统。 7 * -45 *缩放图像可以通过轻松的操作来观察。 这是一个非常好的显微镜，可以在半导体和集成电路板检查和测量中使用。 它也可以在教育示范和农业研究领域中使用。
单眼变焦机构BS-1000还可以灵活地配备的半导体的帧和集成电路板的生产线。 用显微镜目镜数字MDE-130，它会变成数字显微镜。 然后，它可以被连接到PC，并分析样品。
特征
1.无限和高质量变焦光学系统1：6.5。
2.一体化结构设计使其占用较少的工作空间。
3.高清晰度摄像头，USB2.0输出。
要配备显微镜多用途4.广泛的配件。
5.数码相机连接到电脑，实现分析功能。
6.更宽的视野（目测达85毫米），。
7.高倍（高达400倍15'monitor）。
MDE-130数码目镜
应用
BS-1000系列单筒显微镜放大广泛应用于教育示范，农业研究，半导体和集成电路的检查等。
规范
模型 | BS-1000 | BS-1000A | |||
体 | 目镜WF10 * | • | • | ||
辅助物镜 | 0.3* | • | • | ||
0.5* | • | • | |||
2* | • | • | |||
中等适配器0.5 * | • | • | |||
变焦比：1：6.5（0.7 * -4.5 *） | • | • | |||
总放大倍率：7 * -45 * | • | • | |||
工作距离为90mm | • | • | |||
站 | 对焦范围：55毫米 | • | |||
Φ90mm磨砂玻璃或黑色/白色盘子和夹子 | • | ||||
各种支架 | • | ||||
机械舞台 | • | ||||
照明 | 反映照明 | 6V / 15W卤素灯带反射 | • | ||
环形LED照明灯 | • | ||||
冷光源 | • | • | |||
底照度 | 6V / 20W卤素灯 | • | |||
视频系统 | C接口 | • | • | ||
MDE-130数码相机目镜 | • | • | |||
ScopeImage 9.0分析软件 | • | • | |||
尺寸和G.W. | 38.5厘米*34厘米* 37厘米，7千克 | • | |||
注：•标准配置。 •标准可选
通用产品信息
| 原始地点： | 中国 |
| 品牌： | BestScope |
| 认证： | ISO CE QS |
| 型号： | BS-1000 |
美国商务部项目
| 最小起订量： | 一 |
| 价格： | 面议 |
| 包装细节： | 根据客户的要求 |
| 交货时间： | 根据订购数量 |
| 付款条件： | T / T提前 |
Quick Detail
BS-1000 Monocular Zoom microscope is a precise optical system providing high resolution, sharp and strong stereoscopic images.
Introduction
BS-1000 Monocular Zoom microscope is a precise optical system providing high resolution, sharp and strong stereoscopic images. 7*-45* zoom images can be observed by easily operation. It is a very good microscope and can be used in semi-conductor and integrated circuit board inspection and measurement. It is also can be used in educational demonstration and agriculture research area.
Monocular Zoom Body BS-1000 also can be flexibly equipped with a frame of semi-conductor and integrate circuit board production line. With a microscope digital eyepiece MDE-130, it turns a digital microscope. It then can be connected to a PC and analyze the samples.
Features
1. Infinite and high quality zoom optical system 1: 6.5.
2. Integration structure design makes it occupy less working Space.
3. High-resolution camera, USB2.0 output.
4. A wide range of accessories to be equipped with the microscope for multi-purpose.
5. Digital camera connected to computer to achieve analysis function.
6. Wider viewing field (eye survey up to 85mm) .
7. Higher magnification (up to 400X with 15'monitor) .
MDE-130 Digital Eyepiece
Application
BS-1000 series Monocular Zoom Microscope are widely used in educational demonstration, agriculture research, semi-conductor and integrated circuit inspection and so on.
Specification
Model | BS-1000 | BS-1000A | |||
Body | Eyepiece WF10* | • | • | ||
Auxiliary Objective | 0.3* | • | • | ||
0.5* | • | • | |||
2* | • | • | |||
Medium Adapter 0.5* | • | • | |||
Zoom Ratio: 1: 6.5 (0.7*-4.5*) | • | • | |||
Total Magnification: 7*-45* | • | • | |||
Working Distance: 90mm | • | • | |||
Stand | Focusing Range: 55mm | • | |||
Φ90mm Frosted Glass or Black/ White Plate & Clips | • | ||||
Various Stand | • | ||||
Mechanical Stage | • | ||||
Illumination | Reflect Illumination | 6V/ 15W Halogen Lamp with Reflector | • | ||
Annular LED Illuminator | • | ||||
Cold Light Illuminator | • | • | |||
Bottom Illumination | 6V/ 20W Halogen Lamp | • | |||
Video System | C Mount | • | • | ||
MDE-130 Digital Camera Eyepiece | • | • | |||
ScopeImage 9.0 Analysis Software | • | • | |||
Dimension & G.W. | 38.5cm*34cm*37cm, 7kg | • | |||
Note: •Standard Outfit. • Standard Optional
Universal product information
| Place of Origin: | China |
| Brand Name: | BestScope |
| Certification: | ISO CE QS |
| Model Number: | BS-1000 |
The Commerce Item
| Minimum Order Quantity: | One |
| Price: | Negotiable |
| Packaging Details: | According to the Requirements of Clients |
| Delivery Time: | According to the order quantity |
| Payment Terms: | T/ T in advance |
