低温空气分离设备生产不同品种的气体和液体的通过的低温空气分离过程中，使用空气和电功率作为唯一的原料。

范围：从50立方米/小时20000立方米/小时

输出：氧气，氩气，氮气和液态氧，氩，氮

空气

空气构成的氮78％，氧21％，氩气的1％。

氩气是一种惰性气体。 氪，氖和氙其他惰性气体和它们一起构成了不到01％的气氛。

工业气体

氧，氮和氩气从空气中分离回收。 它是一种低温方法。 空气被压缩和释放的蒸气，尘埃和二氧化碳。 然后冷冻以极低的温度，压缩成液体并通过蒸馏分离成氧，氮和氩气等稀有气体。

今天，其它物理方法也可用于分离和纯化空气组分：

分离：用膜的方法。

吸附：空气中各种成分被吸附到一种特殊的材料，而其他流通无阻碍。

我们的空气分离装置由HSGECO司建于内部。

吨位空分设备

空气分离设备通常产生氧气，氮气，氩气和 - 在一些特殊情况 - 等稀有气体（氪，氙，氦，氖）通过空气的低温精馏。 该产品可以以气态形式供管道供应或作为低温液体的储存和分配来制造。

吨位的空气分离植物是被单独设计为我们的客户的具体要求。 每日氧的生产能力为30吨/日和640吨/天之间。

低温液体植物

低温液体的植物是气体植物在低温过程中产生了液氧或液氮。 低温方法是在许多大型气体植物用于生产纯化的氧气或纯化的氮气中最流行的技术之一。 从工厂生产液态氧的输出可以存储在一液氧贮槽。 液氮作为副产品的产品同时高达99.999％的纯度。 该低温植物是非常通用的，安全，操作和所有被产生的可能的产品变体可以被视为或者100％的液态氧输出或50％的液态氧的输出直接进入气缸或50％的液态氮和50％的液态氧容易 。

www.hangzhouoxygen.com

Cryogenic Air Separation Plants produce different varieties of Gases & Liquids by the process of Cryogenic Air Separation, using air and electrical power as the only raw materials.

Range: From 50m3/ hr To 20000m3/ hr

Output: Oxygen, Argon, Nitrogen Gas & Liquid Oxygen, Argon, Nitrogen

Air

Air constitutes of nitrogen 78%, oxygen 21% and argon 1%.

Argon is a noble gas. Krypton, neon and xenon are other noble gases and together they constitute less than 01 percent of the atmosphere.

Industrial Gases

Oxygen, nitrogen and argon are recovered from the air by separation. It is a cryogenic method. The air is compressed and freed of vapour, dust and carbon dioxide. Then refrigerated to extremely low temperatures, compressed to a liquid and separated by distillation into oxygen, nitrogen and argon and other noble gases.

Today, other physical methods are also used to separate and purify air components:

Separation: by means of membranes.

Adsorption: various components of air are adsorbed onto a special material while others flow through without obstruction.

Our air separation units are constructed in-house by the HSGECO Division.

Tonnage Air Separation Plants

Air separation plants generally produce oxygen, nitrogen, argon and – in some special cases – other rare gases (krypton, xenon, helium, neon) by cryogenic rectification of air. The products can be produced in gaseous form for pipeline supply or as cryogenic liquid for storage and distribution.

Tonnage air separation plants are plants that are individually designed for the specific demands of our customers. Daily oxygen production capacities are between 30 tons/ day and 640 tons/ day.

Cryogenic liquid plants

Cryogenic liquid plants are gas plants producing liquid oxygen or liquid nitrogen in the cryogenic process. Cryogenic process is one of the most popular technique used in many large scale gas plants for producing purified oxygen or purified nitrogen. The output of liquid oxygen produced from the plant can be stored in a liquid oxygen tank. Liquid nitrogen is produced as a by product simultaneously up to 99.999% purity. The cryogenic plants are extremely versatile, safe and easy to operate and all the possible product variants that are produced can be taken as either 100% liquid oxygen output or 50% liquid oxygen output directly into cylinders or 50% liquid nitrogen and 50% liquid oxygen.
