Wall Mounted Exhaust Fan
壁挂式抽风机
议价
加入意向基本信息。
型号：QOMA-EF
认证：ISO，SGS
电流类型：AC
安装：壁扇
刀片材质：不锈钢
尺寸：Shm50inch
商品：壁挂式排风扇
用途：适用于空调
出口市场：南美，东欧，东南亚，非洲，大洋洲，中东，东亚
产品描述
1.公司简介
青岛超畜牧机械有限公司是一家知名企业从事牧业通风设备的研究，设计和制造，以及畜禽通风。 这是一个喜欢快的发展速度，伴随着最有效的技术和一流的销售量子高新技术企业。
同时，它具有发展，工程师设计，安装和维修的同时的能力。
我们一直在提供我们的产品在中国及海外市场，如东南亚，中东，阿拉伯国家，南美等优异的性能和服务得到了客户良好的口碑，我们一直努力工作，以提供更好，更优质的产品 并为越来越多的客户服务。
2.主要patrs的细节
*刀片：在镜面不锈钢刀片是从德国进口，整机经过平衡测试。
*开放系统：特殊和先进的离心系统保证活门的打开角度，使空气流可以保持在光滑高电平
*电机：西门子电机。 转速：1440 /分钟。 噪声：≤64分贝
*轴承：质量等级：P 6; 噪音等级：Z 1
*腰带：导入feom MITSUBOSHI日本
3.产物排气风扇的细节
青岛超畜牧机械有限公司是一家知名企业从事牧业通风设备的研究，设计和制造，以及畜禽通风。 这是一个喜欢快的发展速度，伴随着最有效的技术和一流的销售量子高新技术企业。
同时，它具有发展，工程师设计，安装和维修的同时的能力。
我们一直在提供我们的产品在中国及海外市场，如东南亚，中东，阿拉伯国家，南美等优异的性能和服务得到了客户良好的口碑，我们一直努力工作，以提供更好，更优质的产品 并为越来越多的客户服务。
2.主要patrs的细节
*刀片：在镜面不锈钢刀片是从德国进口，整机经过平衡测试。
*开放系统：特殊和先进的离心系统保证活门的打开角度，使空气流可以保持在光滑高电平
*电机：西门子电机。 转速：1440 /分钟。 噪声：≤64分贝
*轴承：质量等级：P 6; 噪音等级：Z 1
*腰带：导入feom MITSUBOSHI日本
3.产物排气风扇的细节
| 尺寸 | SHM-1000 |
| 外形尺寸 | 1380X1380X450mm（54 X54 X18） |
| 直径叶片 | 1270毫米 |
| 风量 | 43170m³/小时 |
| 功率 | 1.1KW |
| 电压 | 380V |
| 法时频 | 50赫兹 |
| 重量 | 88千克 |
| 应用 | 畜牧场。 温室。 作坊 |
| 认证 | ISO9001：2000 CE |
| 起源 | 中国 |
| 提单的OPRT | 青岛 |
Basic Info.
Model NO.: QOMA-EF
Certification: ISO, SGS
Electric Current Type: AC
Mounting: Wall Fan
Blade Material: Stainless Steel
Size: Shm50inch
Commodity: Wall Mounted Exhaust Fan
Usage: for Air Conditioner
Export Markets: South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Product Description
1. Company profile
Qingdao Super Husbandry Machinery Co. , Ltd is a famous enterprise engages in the study, designing and manufacturing of the husbandry ventilation equipments as well as the livestock and poultry ventilation. It is a hi-tech enterprise that enjoys the fast development speed, accompanied by the most effective technologies and top-ranking sales quantum.
Meanwhile, it has the ability of development, engineer designing, installing and servicing at the same time.
We have been supplying our products in China and overseas markets like the Asia, Middle East, Arab Countries, South America, etc. The excellent performance and services get a good reputation from the clients, we keep hard working to provide the better and better products and service for more and more customers.
2. The details of main patrs
*Blades: The mirror face stainless steel blades are imported from Germany, the whole machine goes through balance test.
*Opening system: The special and advanced centrifugal system assures the opening angle of the shutter so that air flow can be kept on the smooth high level
*Motor: Siemens motor. RPM: 1440/ min. Noise: ≤ 64dB
*Bearing: Quality grade: P 6; Noise grade: Z 1
*Belt: Being imported feom Japan of Mitsuboshi
3. The details of the product-exhaust fan
Qingdao Super Husbandry Machinery Co. , Ltd is a famous enterprise engages in the study, designing and manufacturing of the husbandry ventilation equipments as well as the livestock and poultry ventilation. It is a hi-tech enterprise that enjoys the fast development speed, accompanied by the most effective technologies and top-ranking sales quantum.
Meanwhile, it has the ability of development, engineer designing, installing and servicing at the same time.
We have been supplying our products in China and overseas markets like the Asia, Middle East, Arab Countries, South America, etc. The excellent performance and services get a good reputation from the clients, we keep hard working to provide the better and better products and service for more and more customers.
2. The details of main patrs
*Blades: The mirror face stainless steel blades are imported from Germany, the whole machine goes through balance test.
*Opening system: The special and advanced centrifugal system assures the opening angle of the shutter so that air flow can be kept on the smooth high level
*Motor: Siemens motor. RPM: 1440/ min. Noise: ≤ 64dB
*Bearing: Quality grade: P 6; Noise grade: Z 1
*Belt: Being imported feom Japan of Mitsuboshi
3. The details of the product-exhaust fan
| Size | SHM-1000 |
| Outer size | 1380X1380X450mm (54 X54 X18 ) |
| Diameter blades | 1270 mm |
| Air volume | 43170m³ / h |
| Power | 1.1KW |
| Voltage | 380V |
| Frenquency | 50Hz |
| Weight | 88Kg |
| Application | Livestock farm. greenhouse. workshop |
| Certification | ISO9001: 2000 CE |
| Origin | China |
| The oprt of lading | Qingdao |
