CNC FRP/GRP Lighting Pole Filament Winding Machine with Good Quality
数控FRP / GRP照明杆灯丝绕线机质量好
产品描述
数控FRP / GRP管丝灯绕线机质量好
FRP管缠绕机，grp管丝缠绕机，cnc缠绕机，制管机，纤维缠绕机，grp管丝缠绕机，frp管生产线，frp管材设备。
Frp管卷绕机：
计算机控制
2易于控制。
3Factory直接供货
4管卷绕直径定制
FRP绕线机性能特点
特点：生产技术控制简单，工作气氛好，管道质量稳定，管长可调，规格更易于操作，操作更方便等优点。
| fwjs-1500 | fwjs-2600 | fwjs-3000 | |||
管径（mm） | dn300-dn1500 | dn300-dn2600 | dn300-dn3000 | |||
生产长度（mm） | ≤12300 | ≤12300 | ≤12300 | |||
绕组角度范围 | 45°-90° | 45°-90° | 45°-90° | |||
添加砂的方式 | 干和湿 | 干和湿 | 干和湿 | |||
添加砂的最大厚度（mm） | ≤20 | ≤20 | ≤20 | |||
主轴转速（r / min） | ≤85 | ≤85 | ≤85 | |||
牵引纱最大速度（m / min） | ≤120 | ≤120 | ≤120 | |||
生产能力（kg / h） | 1800 | 2300 | 3200 | |||
总装机容量（KW） | 110 | 120 | 120 | |||
生产线覆盖的面积（长×宽）m | 54x24 | 60x24 | 60x24 |
frp制管机的基本配置
FRP管衬机
它配有Taida PLC数控装置。缠绕膜，垫和网格织物可以通过张紧支架装置自动控制，使搭接接头光滑精确，从而防止人为不均匀和浪费现象。
FRP管缠绕机
砂添加法包括许多模式：中，底，干，湿和干 - 湿法。通过设置自动供胶泵站和搅拌机，夹砂比率全自动，分布均匀，设备操作方便，准确，耗能低。
GRP管固化站
它包括开放式和封闭式。它配有红外加热系统，模具自动旋转。
玻璃钢脱模机
采用液压传动，运动平稳。爪的柔性距离长，直径适用范围宽。它节省了模具拉拔环的使用，使操作更容易。
Product Description
CNC FRP/GRP Pipe Filament Winding Machine with good quality
FRP pipe winding machine,grp pipe filament winding machine,cnc winding machine,pipe making machine,filament winding machine,grp pipe filament winding machine,frp pipe production line,frp pipe equipment.
Frp pipe winding machine sepcification:
1Computer control
2Easy control.
3Factory directly supply
4Pipe winding diameter customized
FRP winding machine Performance feature
Feature: the great advantages are simple control on producing techniques, better working atmosphere, stable pipe quality, adjustable pipe length, easier to change specifications, more convenient operation, etc.
| FWJS-1500 | FWJS-2600 | FWJS-3000 | |||
Pipe diameter(mm) | DN300-DN1500 | DN300-DN2600 | DN300-DN3000 | |||
Production length(mm) | ≤12300 | ≤12300 | ≤12300 | |||
Winding angle range | 45°-90° | 45°-90° | 45°-90° | |||
The way of adding sand | Both dry and wet | Both dry and wet | Both dry and wet | |||
Max thickness of adding sand a time(mm) | ≤20 | ≤20 | ≤20 | |||
Rotating speed of main shaft(r/min) | ≤85 | ≤85 | ≤85 | |||
Max speed of pulling yarn(m/min) | ≤120 | ≤120 | ≤120 | |||
Production capacity(kg/h) | 1800 | 2300 | 3200 | |||
Total installed capacity(KW) | 110 | 120 | 120 | |||
Areas covered by production line(length×width)m | 54x24 | 60x24 | 60x24 |
Basic allocation of frp pipe making machine
FRP pipe Liner making machine
It is set up with Taida PLC numerical control device. The winding film, mat and gridding fabric can be controlled automatically by the tension bracket device which makes the lap joint is smooth and precise, so the artificial nonuniformity and waste phenomenon will be prevented.
FRP pipe Winding machine
The sand-adding method includes many modes: intermediate, bottom, dry, wet and dry-wet method. By being set up with automatic glue-supplying pumping station and mixer, ratio of sand inclusion is fully automatic and well-distributed, so the operation of the equipment is pretty convenient and accurately, low energy-consuming.
GRP pipe Curing station
It includes open style and closed style. It's allocated with infrared heating system and the mould revolves automatically.
Fiberglass Demoulding machine
It adopts hydraulic transmission and the movement is stable. The flexible distance of claw is long and the applying scope of diameter is wide. It saves the usage of mould-extracing loop so the operation is easier.
