CE, RoHS Certificates Full Color P5 Indoor LED Display for Advertising/Decoration/Lighting

CE, RoHS Certificates Full Color P5 Indoor LED Display for Advertising/Decoration/Lighting

CE,RoHS证书全彩P5室内LED显示屏广告/装饰/照明

1+
900 USD
100+
800 USD
500+
700 USD

加入意向
型号。 P5
显示功能 视频显示
像素配置 红,绿,蓝3合1
扫描模式 1/8扫描
显示类型 LED视频显示
IP等级 IP43
寿命 10万小时
功能 显示,装饰,促进
规范 ce,rohs,emc,ccc,iso9001
HS编码 8528591090
管芯颜色 饱满的色彩
像素间距 5毫米
像素密度 40,000点/平方米up2;m²
系统操作平台 Windows XP,Win98,Win7
应用 广告
证明 ce,rohs,ccc
保证 2年
商标 的LED英雄
起源 中国广东省深圳市

P5 LED显示屏规格:

零件号

英雄ids4f-8S


解析度

32(H)×32(V)S; 32(ⅴ)s;32(V)


像素间距

5毫米


LED配置

1r1g1b 3合1 smd


像素密度

40,000像素/平方米


模块尺寸

160 *160毫米


驱动IC

MBI5024


驾驶方法

1/8扫描,恒定电流


机柜重量

42公斤/平方米。


机械等级


悬挂重量支持

2T


表面平整度

间隙<0.5mm.5mm


光学等级


亮度

> 2400cd / m2 / m2


视角

150°/ 150°/ 150°deg;/150°


灰度

8位输入,14位校正


显示颜色

16.7M


亮度调整

0~100%


电源


操作电源

90〜260v 50〜60hz


最大。能量消耗

850W / m2


平均功耗

280W / m2


控制系统


控制模式

DVI同步显示控制PC


帧更新频率

60〜85Hz的


屏幕刷新频率

300〜1000Hz的


伽玛校正

-5.0~+5.0


支持输入

复合,S视频,组件,VGA,DVI,HDMI,HD_SDI


控制距离

以太网电缆<120m or Fiber Optic<10Kmlt;10Km


支持VGA模式

1024×768,1280×1024,1600×1200,1920×1280mes; 1200,1920×1280s;1280mes;1200, 1920×1280


亮度校正

像素,模块,机柜


环境的


工作温度

-20°〜+ 60°〜+ 60°deg;~+60°


工作湿度

10〜95%rh


使用寿命

100000小时


MTBF

5000小时


防护等级

~


失控率

<0.02%


包装运输
专业包装:环保纸箱,木箱或飞行箱。
包装方式可以防止LED屏幕在运输过程中的碰撞,如损坏等。
无故解决您在运输中的烦恼。
关于英雄
LED屏幕7年的经验,我厂具有加工,研发LED显示屏的能力,确保多样化。严格的质量控制流程,确保LED显示屏具有高品质。
售后服务
1)保修:
免费解决质量问题,确保设备在保修期内正常运行。在任何时候,我们承担所有的责任,当问题来自产品本身。
2)免费保修:
保修期内免费保修。
仅在保修期内收取原材料成本,提供最低价格的备件和维修服务。
3)快速反应:
2小时内响应,24小时内无人为故障,一般故障解决,48小时内可接受故障解决。
4)免费支持:
通过电话或网络实时提供服务支持,或借助网络进行远程调试支持(软件),解决问题。
Model NO. P5
Display Function Video Display
Pixel Configuration Red, Green and Blue 3 in 1
Scanning Mode 1/8 Scan
Display Type LED Video Display
IP Rating IP43
Lifespan 100,000 Hours
Function Display,Decorate,Promote
Specification CE, ROHS, EMC, CCC, ISO9001
HS Code 8528591090
Tube Chip Color Full Color
Pixel Pitch 5mm
Pixel Density 40,000 dots / m²m²up2;m²
System Operating Platform Windows XP,Win98,Win7
Application Advertising
Certification CE, RoHS, CCC
Warranty 2 Years
Trademark Led-Hero
Origin Shenzhen City, Guangdong Province, China

P5 led display specification:

Part Number

HERO-IDS4F-8S


Resolution

32(H)×32(V)s;32(V)s;32(V)


Pixel Pitch

5mm


LED Configuration

1R1G1B 3-IN-1 SMD


Pixel Density

40,000 pixels/ m2


Module Size

160*160mm


Driving IC

MBI5024


Driving Method

1/8 Scan, Constant Current


Cabinet Weight

42kg/sq.m.


Mechanical Ratings


Hanging Weight Support

2T


Surface Flatness

Gap<0.5mm.5mm


Optical Ratings


Brightness

﹥2,400cd/ m2/ m2


View Angle

150°/150°/150°deg;/150°


Gray Scale

8bits input, correction with 14bits


Display COLOR

16.7M


Brightness Adjustment

0~100%


Power Supply


Operation Power

90~260V 50~60Hz


Max. Power Consumption

850W/ m2


Average Power Consumption

280W/ m2


Control System


Control Mode

Synchronous display with control PC by DVI


Frame Update Frequency

60~85Hz


Screen Refresh Frequency

300~1000Hz


Gamma Correction

-5.0~+5.0


Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI


Control Distance

Ethernet cable<120m or Fiber Optic<10Kmlt;10Km


Support VGA Mode

1024×768, 1280×1024, 1600×1200, 1920×1280mes;1200, 1920×1280s;1280mes;1200, 1920×1280


Brightness Correction

Pixel, Module, Cabinet


Environmental


Operating Temperature

-20°~+60°~+60°deg;~+60°


Operating Humidity

10~95% RH


Operating Life

100,000hours


MTBF

5000hours


Protection Level

~


Out of Control Rate

<0.02%


Packing and transportation
Professional packaging:environmental carton, wooden box or flight case.
The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.
Faultlessly solve your worries in the transportation.
About Hero
7-year's experience in LED screen, our factory has the ability of processing, researching and developing led display to ensure the prolificacy.A strict quality control process to make sure the led display screens is with high quality.
After-sale service
1) Warranty:
Free to solve the quality problems to ensure that equipment normal operation in the warranty period . At any time, we bear all the responsibility, when the problem is from the product itself.
2) Free warranty:
Free warranty in the warranty period.
Only charge the cost of raw materials, provide spare parts and maintenance services for the lowest price after the warranty period.
3)quick response:
Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
4) Free support:
Through telephone or network to provide service support in real time, or with the help of a network for remote debugging support (software), to solve the problem.
