Embedded Computer with 7" Win CE6.0/Linux 2.6.32, IP64
嵌入式计算机7“Win CE6.0 / Linux 2.6.32，IP64
议价
加入意向| 型号。 | PC-765 |
| 证明 | ce，rohs，fcc |
| 规范 | ce，fcc，rohs |
| HS编码 | 8528591000 |
| 处理器类型 | 臂 |
| 类型 | 嵌入式系统 |
| 起源 | 中国 |
特征：
采用工业级嵌入式平台，系统稳定可靠，接口丰富。
无线通信，GPS导航，故障检测，视频采集等功能，可扩展为用户提供强大的车载移动多媒体信息系统。
可广泛应用于个人娱乐，应急指挥，运输调度，移动办公，多媒体广告，工业控制等领域。
符合IP64标准，防尘防水;防爆;roof;
强大的TI CPU;
3×USB 2.0接口;erface;
宽电源电压;
内置扬声器;
耐振动性强
rs232×3 / rs232×2，rs485×1. 2，rs485×1。es; 1. 2, RS485× 1.
可选的：
3G，Wi-Fi 802.11 b / g / n（内置），RS485，蓝牙（内置）。
应用：
信息显示;
数字标牌;
广告终端
家用控制设备;
智能能源应用;
安全监察ance;
一般沟通;
距离数据采集
基本A / V播放器
导航系统。
显示屏7'LED背光
分辨率800×480（1,152,000像素）像素）pixels)
触摸屏4线电阻
亮度450CD /
宽高比16：9
OS Windows CE 6.0 R3 / Linux 2.6.32
cpu ti omap3525，600mhz处理器
核心ARM Cortex-A8
内存256MB闪存ROM + 128MB LPDDR（默认）
512MB闪存+ 256MB lpddr（可选）
扩展存储Micro SD（TF）卡最多支持16G
LAN Ethernet 10 / 100M（RJ45）
传输接口USB Host 2.0×2，USB Device 2.0 X 12.0 X 12.0 X 1
rs232×3 / rs232×2，rs485×1 2，rs485×1mes; 1 2, RS485 × 1
音频耳机插槽×1次; 1imes; 1
演讲者（回）×1次; 1imes; 1
扬声器1W
功耗8W
工作温度-10 - 65ºCrdm; Crdm; C
储存温度-25 - 80ºCrdm; Crdm; C
电源DC 9-24V
尺寸（LWD）198×146×35mm×35mm 35 mm× 35 mm
重量740g
采用工业级嵌入式平台，系统稳定可靠，接口丰富。
无线通信，GPS导航，故障检测，视频采集等功能，可扩展为用户提供强大的车载移动多媒体信息系统。
可广泛应用于个人娱乐，应急指挥，运输调度，移动办公，多媒体广告，工业控制等领域。
符合IP64标准，防尘防水;防爆;roof;
强大的TI CPU;
3×USB 2.0接口;erface;
宽电源电压;
内置扬声器;
耐振动性强
rs232×3 / rs232×2，rs485×1. 2，rs485×1。es; 1. 2, RS485× 1.
可选的：
3G，Wi-Fi 802.11 b / g / n（内置），RS485，蓝牙（内置）。
应用：
信息显示;
数字标牌;
广告终端
家用控制设备;
智能能源应用;
安全监察ance;
一般沟通;
距离数据采集
基本A / V播放器
导航系统。
显示屏7'LED背光
分辨率800×480（1,152,000像素）像素）pixels)
触摸屏4线电阻
亮度450CD /
宽高比16：9
OS Windows CE 6.0 R3 / Linux 2.6.32
cpu ti omap3525，600mhz处理器
核心ARM Cortex-A8
内存256MB闪存ROM + 128MB LPDDR（默认）
512MB闪存+ 256MB lpddr（可选）
扩展存储Micro SD（TF）卡最多支持16G
LAN Ethernet 10 / 100M（RJ45）
传输接口USB Host 2.0×2，USB Device 2.0 X 12.0 X 12.0 X 1
rs232×3 / rs232×2，rs485×1 2，rs485×1mes; 1 2, RS485 × 1
音频耳机插槽×1次; 1imes; 1
演讲者（回）×1次; 1imes; 1
扬声器1W
功耗8W
工作温度-10 - 65ºCrdm; Crdm; C
储存温度-25 - 80ºCrdm; Crdm; C
电源DC 9-24V
尺寸（LWD）198×146×35mm×35mm 35 mm× 35 mm
重量740g
| Model NO. | PC-765 |
| Certification | CE, RoHS, FCC |
| Specification | CE, FCC, RoHs |
| HS Code | 8528591000 |
| Processor Type | ARM |
| Type | Embedded Systems |
| Origin | China |
Features:
Using industrial-grade embedded platform, the system is stable and reliable, it has rich interfaces.
Wireless communication, GPS navigation, fault detection, video acquisition and other functions, extensible to provide users with a powerful vehicle-mounted mobile multimedia information systems.
It can be widely used in personal entertainment, emergency command, transportation scheduling, mobile office, multimedia advertising, industrial control and other fields.
Comply with IP64 Standard, dust & water-proof;proof;roof;
Powerful TI CPU;
3 × USB 2.0 interface;erface;erface;
Wide power voltage;
Built-in speaker;
Strong vibration resistance;
RS232× 3 / RS232× 2, RS485× 1. 2, RS485× 1.es; 1. 2, RS485× 1.
Optional:
3G, Wi-Fi 802.11 b/g/n (built-in), RS485, Bluetooth (built-in).
Applications:
Information Display;
Digital Signage;
Advertising Terminal;
In-Home Control Device;
Smart Energy Application;
Security & Surveillance;ance;ance;
General Communication;
Distance Data Acquisition;
Basic A/V Player;
Navigation System.
Display Screen 7' LED backlitbacklit
Resolution 800× 480 (1, 152, 000 pixels)pixels)pixels)
Touch Panel 4-wire resistive
Brightness 450CD/
Aspect Ratio 16: 9
OS Windows CE 6.0 R3 / Linux 2.6.32
CPU TI OMAP3525, 600MHz processor
Core ARM Cortex-A8
Memory 256MB Flash ROM + 128MB LPDDR (default)
512MB Flash ROM + 256MB LPDDR (optional)
Expansion Storage Micro SD (TF) card supports up to 16G
LAN Ethernet 10/100M (RJ45)
Transfer Interface USB Host 2.0 × 2, USB Device 2.0 X 12.0 X 12.0 X 1
RS232 × 3 / RS232 × 2, RS485 × 1 2, RS485 × 1mes; 1 2, RS485 × 1
Audio Ear phone slot × 1imes; 1imes; 1
Speaker (back) × 1imes; 1imes; 1
Speaker 1W
Power consumption 8W
Working Temperature -10 - 65º Crdm; Crdm; C
Storage Temperature -25 - 80º Crdm; Crdm; C
Power Supply DC 9-24V
Dimension(LWD) 198 × 146 × 35 mm× 35 mm 35 mm× 35 mm
Weight 740g
Using industrial-grade embedded platform, the system is stable and reliable, it has rich interfaces.
Wireless communication, GPS navigation, fault detection, video acquisition and other functions, extensible to provide users with a powerful vehicle-mounted mobile multimedia information systems.
It can be widely used in personal entertainment, emergency command, transportation scheduling, mobile office, multimedia advertising, industrial control and other fields.
Comply with IP64 Standard, dust & water-proof;proof;roof;
Powerful TI CPU;
3 × USB 2.0 interface;erface;erface;
Wide power voltage;
Built-in speaker;
Strong vibration resistance;
RS232× 3 / RS232× 2, RS485× 1. 2, RS485× 1.es; 1. 2, RS485× 1.
Optional:
3G, Wi-Fi 802.11 b/g/n (built-in), RS485, Bluetooth (built-in).
Applications:
Information Display;
Digital Signage;
Advertising Terminal;
In-Home Control Device;
Smart Energy Application;
Security & Surveillance;ance;ance;
General Communication;
Distance Data Acquisition;
Basic A/V Player;
Navigation System.
Display Screen 7' LED backlitbacklit
Resolution 800× 480 (1, 152, 000 pixels)pixels)pixels)
Touch Panel 4-wire resistive
Brightness 450CD/
Aspect Ratio 16: 9
OS Windows CE 6.0 R3 / Linux 2.6.32
CPU TI OMAP3525, 600MHz processor
Core ARM Cortex-A8
Memory 256MB Flash ROM + 128MB LPDDR (default)
512MB Flash ROM + 256MB LPDDR (optional)
Expansion Storage Micro SD (TF) card supports up to 16G
LAN Ethernet 10/100M (RJ45)
Transfer Interface USB Host 2.0 × 2, USB Device 2.0 X 12.0 X 12.0 X 1
RS232 × 3 / RS232 × 2, RS485 × 1 2, RS485 × 1mes; 1 2, RS485 × 1
Audio Ear phone slot × 1imes; 1imes; 1
Speaker (back) × 1imes; 1imes; 1
Speaker 1W
Power consumption 8W
Working Temperature -10 - 65º Crdm; Crdm; C
Storage Temperature -25 - 80º Crdm; Crdm; C
Power Supply DC 9-24V
Dimension(LWD) 198 × 146 × 35 mm× 35 mm 35 mm× 35 mm
Weight 740g
