介绍：
BIO260是最先进的门禁控制面板，当与生物识别读取器和软件连接时，可以为任何门提供生物识别安全。这些面板是多功能的，可以连接F系列指纹读取器和KR系列RFID读卡器。这些读卡器可以连接到面板上的TCP / IP和RS 485连接。借助Access软件，用户将获得灵活性和可扩展性来对访问控制系统进行编程。该软件是基于Web的，因此可以通过Web浏览器从任何计算机访问。
参数索引：
真正的内部生物识别
BIO260面板执行面板上的指纹匹配。来自读卡器的指纹模板被传输到面板，面板将放置的手指与存储在数据库中的模板相匹配。使用强大的版本10算法，指纹匹配非常快速准确。
双通讯模式
BIO260支持双通信模式， E. TCP / IP模式和RS485模式。 TCP / IP通信提供了不平衡的速度和可靠性，但限于面板和读卡器之间的电缆长度为300英尺。使用RS 485可以将阅读器和面板之间的电缆长度延长至1公里。
LED指示灯
BIO260面板内部的五个LED指示灯用于指示电源，面板稳定运行，有效识别和从BIO260到读卡器的数据传输。
支持外部SD卡
BIO260可以在其内部存储器中存储100 000个交易。然而，对于需要更多存储容量的特殊项目或应用程序，可以向BIO260添加SD卡以存储数据。它还有助于备份控制器中的数据。
监控联动
用户可以将BIO260与DVR连接起来，并在ZKAccess5.0软件中具有视频监控联动功能。当连接建立时，用户可以监控实时视频。
显着的访问控制功能
联锁，反通，第一张卡打开，多卡打开，胁迫密码和指纹，远程监控，实时监控和电子地图链接。所有这些功能都与出口开关，PIR探测器，读卡器，报警器和RTE硬件等第三方配件兼容。
型号：BIO260
cpu：32位mips cpu
RAM：32M位
闪存：128M位
指纹容量：3000
卡容量：30,000
事件缓冲区：100,000
SD卡备份：支持
电源/电流：DC 9.6V-14.4V，额定最大1A
Wiegand读卡器端口：4ea（26bit Wiegand，8bit Burst for PIN）
RS485读卡器端口：1ea扩展RS485端口
通讯：RS485，TCP / IP
波特率：38,400BPS（推荐）/ 9600BPS，19,200BPS，57,600BPS（可选）
输入端口：4ea（退出按钮＃1，门传感器＃1;退出按钮＃2，门传感器＃2）
输出端口：2ea（2个form-c继电器输出，spdt 5a @ 36vdc / 8a @ 30vac）
2ea（2个辅助形式继电器输出，spdt 2a @ 30vdc）
LED指示灯：是，通讯，电源，状态和穿孔卡的LED指示灯
工作温度：0°至+ 55°C55°Cg; C55° C
工作湿度：10％至80％相对湿度无冷凝
尺寸（H * W * D）mm：185 * 106 * 36（单板）
400 * 330 * 90.5（带电源和金属机柜）
外壳材质：PVC

Introduction:
BIO260 is the most advanced access control panel which can provide biometric security for any door when connected with biometric readers and the software. These panels are versatile and can connect both F series of fingerprint readers and KR series of RFID readers. These readers can be connected with TCP/IP and RS 485 connectivity to the panels. With the help of Access software the user will get the flexibility and scalability to program the access control system. The software is web based and hence can be accessed from any computer with the help of a web browser.
Parameter index:
Truly Internal Biometric Identification
BIO260 panel carries out the matching of fingerprints on the panels. The fingerprint templates from the reader are transmitted to the panel and the panel will match the placed finger with the template stored in the database. With the powerful version 10 algorithm, the fingerprint matching is extremely fast and accurate.
Dual Communication Mode
BIO260 supports dual communication modes, i. E. TCP/IP mode and RS485 mode. TCP/IP communication offers unparallel speed and reliability but is limited to 300ft of cable length between the panel and the reader. With RS 485 you can extend the cable length between the reader and panel up to 1km.
LED Indicators
Five LED indicators inside the housing of BIO260 panel are used to indicate power, steady functioning of the panel, valid identification and data transfer from BIO260 to readers.
External SD card support
BIO260 can store 100, 000 transactions in its internal memory. However for special projects or applications which require more storage capacity, a SD card can be added to BIO260 for storage of data. It also helps in backing up the data from the controller.
Surveillance Linkage
Users could connect BIO260 with DVR, and have video surveillance linkage function in ZKAccess5.0 Software. When the linkage is established, users can monitor live video.
Salient Access Control Functions
Interlock, Anti-Pass Back, First Card Opening, Multi-Card Opening, Duress Password and Fingerprint, Remote Monitoring, Real-Time Monitoring and E-map Linkage. All of these functions are compatible with the third party accessories like exit switches, PIR detectors, card readers, alarms and RTE hardware.
Model: BIO260
CPU: 32bit MIPS CPU
RAM: 32M bits
Flash Memory: 128M bits
Fingerprint Capacity: 3000
Card Capacity: 30, 000
Event Buffer: 100, 000
SD Card Backup: Support
Power / Current: DC 9.6V-14.4V, Rated Max. 1A
Wiegand Reader Port: 4ea (26bit Wiegand, 8bit Burst for PIN)
RS485 Reader Port: 1ea Extended RS485 Port
Communication: RS485, TCP/IP
Baud Rate: 38, 400BPS (Recommended) / 9600BPS, 19, 200BPS, 57, 600BPS (selectable)
Input Port: 4ea (Exit Button#1, Door Sensor#1; Exit Button#2, Door Sensor#2)
Output Port: 2ea (2 FORM-C Relay Output, SPDT 5A@36VDC/8A@30VAC)
2ea (2 Aux FORM-C Relay Output, SPDT 2A@30VDC)
LED Indicator: Yes, LED indication for communication, power, status and punch card
Operating Temperature: 0° To +55° C55° Cg; C55° C
Operating Humidity: 10% to 80% relative humidity non-condensing
Dimension (H*W*D)mm: 185*106*36(single board)
400*330*90.5(with power supply and metal cabinet)
Housing Material: PVC
