Cooling Unit for Data Center/ Cold Asile Containment
数据中心/冷遏制冷柜
议价
加入意向| 型号。 | WB-铜001 |
| 证明 | CE |
| 显示类型 | LED |
| 标准走道宽度 | 1200mm和1800mm |
| 面板匹配机柜宽度 | 600mm，700mm和800mm |
| 商标 | Webitelecomms |
| HS编码 | 8517709000 |
| 用法 | 冷气机 |
| 控制类型 | 数字 |
| 材料 | 钢 |
| 面板材料 | 有线玻璃或钢 |
| Customzied | 公认 |
| 起源 | 中国制造 |
特征：
隔离冷通道气流从热通道气流
最大化冷通道的冷却效果
减少电脑室空调的工作量
能源成本低
低碳足迹
被动冷却版本
FireProofing具有自动化面板打开功能的活动版本
完全集成柜体基础设施
没有连接到建筑物
可以快速安装
轻松搬迁
CannonGuard远程管理升级
可以使用定制套件将其改装成现有的机柜
在通道照明升级
-----
规范
完全兼容PDU，吸烟，湿度和遥控系统
高透明度聚碳酸酯玻璃面板
替代面板材料：有线玻璃或钢
标准通道宽度包括1200mm和1800mm;可供选择的通道宽度
面板匹配机柜宽度（600mm，700mm和800mm）
可选择茧面板宽度
铰链门或滑动过道门
半釉端门，增加防损性能
使用各种通道的远程温度监控。
电动执行器打开活动进风门，用于喷水器进水
将适合任何柜体尺寸
可以扩展形成一个完整的数据中心“pod”进行灾难恢复开发或临时使用
我们的服务
样品服务：我们将收取一些样品费用，在您下订单后将退款。
包装设计支持：我们有您的定制设计的品牌团队。
公司信息
WEBITELECOMMS成立于2008年，2010年被授予进出口权。
产品范围：19“网络机柜，网架，服务器机柜，服务器机架，接线板，PDU，网线，光缆，户外机柜，电池柜，IPAD充电柜
审计报告：ce，rohs，iso。
展示厅：约100平方米的展厅。
欢迎来到WEBITELECOMMS，相信我们的专业团队和服务将帮助您在市场上领先一步。
常问问题
1）您的付款条件是什么？
--- TT，LC，西联汇款可以接受。
2）你的贸易术语是什么？
--- exw，fob，cnf，cif也可以。
3）什么是加载端口？
---宁波，上海。
4）你的最小起订量是多少？
---我们大部分产品的最小起订量为5件，不同的商品将不同。我们已经在价格表中列出了每个项目的最小起订量。
5）您的产品保修是什么？
---作为欧洲市场，我们的产品拥有CE RoHS等国际安全标准。
---作为其他市场，也提供国际安全标准证书。
隔离冷通道气流从热通道气流
最大化冷通道的冷却效果
减少电脑室空调的工作量
能源成本低
低碳足迹
被动冷却版本
FireProofing具有自动化面板打开功能的活动版本
完全集成柜体基础设施
没有连接到建筑物
可以快速安装
轻松搬迁
CannonGuard远程管理升级
可以使用定制套件将其改装成现有的机柜
在通道照明升级
-----
规范
完全兼容PDU，吸烟，湿度和遥控系统
高透明度聚碳酸酯玻璃面板
替代面板材料：有线玻璃或钢
标准通道宽度包括1200mm和1800mm;可供选择的通道宽度
面板匹配机柜宽度（600mm，700mm和800mm）
可选择茧面板宽度
铰链门或滑动过道门
半釉端门，增加防损性能
使用各种通道的远程温度监控。
电动执行器打开活动进风门，用于喷水器进水
将适合任何柜体尺寸
可以扩展形成一个完整的数据中心“pod”进行灾难恢复开发或临时使用
| 室内机 | wb023a | wb040a |
| 制冷量 | ||
| 40c db / 20％rh | ||
| 总冷量（kw） | 24.5 | 42.6 |
| 明智的制冷量（kw） | 24.5 | 42.6 |
| 37c db / 24％rh | ||
| 总冷量（kw） | 22.9 | 40 |
| 明智的制冷量（kw） | 22.9 | 40 |
| 35c db / 26％rh | ||
| 总冷量（kw） | 21.3 | 38.2 |
| 明智的制冷量（kw） | 21.3 | 38.2 |
| 32c db / 34％rh | ||
| 总冷量（kw） | 19.5 | 36.7 |
| 明智的制冷量（kw） | 19.5 | 34.7 |
| 气流 | ||
| 气流（立方米/小时） | 5000 | 8000 |
我们的服务
样品服务：我们将收取一些样品费用，在您下订单后将退款。
包装设计支持：我们有您的定制设计的品牌团队。
公司信息
WEBITELECOMMS成立于2008年，2010年被授予进出口权。
产品范围：19“网络机柜，网架，服务器机柜，服务器机架，接线板，PDU，网线，光缆，户外机柜，电池柜，IPAD充电柜
审计报告：ce，rohs，iso。
展示厅：约100平方米的展厅。
欢迎来到WEBITELECOMMS，相信我们的专业团队和服务将帮助您在市场上领先一步。
常问问题
1）您的付款条件是什么？
--- TT，LC，西联汇款可以接受。
2）你的贸易术语是什么？
--- exw，fob，cnf，cif也可以。
3）什么是加载端口？
---宁波，上海。
4）你的最小起订量是多少？
---我们大部分产品的最小起订量为5件，不同的商品将不同。我们已经在价格表中列出了每个项目的最小起订量。
5）您的产品保修是什么？
---作为欧洲市场，我们的产品拥有CE RoHS等国际安全标准。
---作为其他市场，也提供国际安全标准证书。
| Model NO. | WB-CU-001 |
| Certification | CE |
| Display Type | LED |
| Standard Aisle Widths | 1200mm and 1800mm |
| Panels to Match Cabinet Widths | 600mm, 700mm and 800mm |
| Trademark | Webitelecomms |
| HS Code | 8517709000 |
| Usage | Air Conditioner |
| Control Type | Digital |
| Material | Steel |
| Panel Materials | Wired Glass or Steel |
| Customzied | Accepted |
| Origin | Made in China |
Features:
Segregated cold aisle air flow from hot aisle air flow
Maximises cooling effect of cold aisle
Reduces workload of computer room air conditioning
Low energy cost
Low carbon footprint
Passive cooling versions
Active versions with automated panel opening for FireProofing
Totally integrated with cabinet infrastructure
Not connected to the building
Can be quickly installed
Easily Relocated
CannonGuard remote management upgrades
Can be retrofitted to existing bays of enclosures with the use of customising kits
Within aisle lighting upgrades
-----
Specification
Fully compatible with PDU, smoking, humidity, and romote control systems
High transparency polycarbonate glazing in panels
Alternative panel materials: Wired glass or steel
Standard aisle widths include 1200mm and 1800mm; Alternative aisle widths are available
Panels to match cabinet widths (600mm, 700mm and 800mm)
Alternative cocooning panel widths are available
Hinge door or sliding aisle end doors
Half glazed end doors for increased damage resistance
Remote temperature monitoring of various aisle points using.
Active entrace doors opened by electronic actuators for sprinkler water ingress
Will fit any cabinet size
Can be extended to form a complete data center 'pod' for disaster recovery development or temporary use
Our Services
Sample Service: We will collect some sample fees, will refund after you place order.
Package design support: We have brand team for your customized design.
Company Information
WEBITELECOMMS was established in 2008 and was awarded the rights of import and export in 2010.
Products range: 19''network cabinet,network rack,server cabinet,server rack,patch panel,PDU,network cable,fiber cable,outdoor cabinet,battery cabinet,IPAD charging cabinet
Audit Report: CE,ROHS,ISO.
Showroom: About 100 square meters showroom.
Welcome to WEBITELECOMMS, believe that our professional team and service will help you stay step ahead in the market.
FAQ
1) What is your Payment term?
---TT, LC, Western Union is could be accept.
2) What is your Trade term?
---EXW, FOB, CNF, CIF is also ok.
3) What is the Loading Port?
--- Ningbo,Shanghai.
4) What is your MOQ?
---MOQ of most our products is 5pcs, different items will be different. We have indicated the MOQ for each item in the price list.
5) What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market, international safety standard certificate is also be provided.
Segregated cold aisle air flow from hot aisle air flow
Maximises cooling effect of cold aisle
Reduces workload of computer room air conditioning
Low energy cost
Low carbon footprint
Passive cooling versions
Active versions with automated panel opening for FireProofing
Totally integrated with cabinet infrastructure
Not connected to the building
Can be quickly installed
Easily Relocated
CannonGuard remote management upgrades
Can be retrofitted to existing bays of enclosures with the use of customising kits
Within aisle lighting upgrades
-----
Specification
Fully compatible with PDU, smoking, humidity, and romote control systems
High transparency polycarbonate glazing in panels
Alternative panel materials: Wired glass or steel
Standard aisle widths include 1200mm and 1800mm; Alternative aisle widths are available
Panels to match cabinet widths (600mm, 700mm and 800mm)
Alternative cocooning panel widths are available
Hinge door or sliding aisle end doors
Half glazed end doors for increased damage resistance
Remote temperature monitoring of various aisle points using.
Active entrace doors opened by electronic actuators for sprinkler water ingress
Will fit any cabinet size
Can be extended to form a complete data center 'pod' for disaster recovery development or temporary use
| Indoor unit | WB023A | WB040A |
| Cooling capacity | ||
| 40c DB/20% RH | ||
| Total cooling capacity(kw) | 24.5 | 42.6 |
| Sensible cooling capacity(kw) | 24.5 | 42.6 |
| 37c DB/24%RH | ||
| Total cooling capacity(kw) | 22.9 | 40 |
| Sensible cooling capacity(kw) | 22.9 | 40 |
| 35c DB/26% RH | ||
| Total cooling capacity(kw) | 21.3 | 38.2 |
| Sensible cooling capacity(kw) | 21.3 | 38.2 |
| 32c DB/34%RH | ||
| Total cooling capacity (kw) | 19.5 | 36.7 |
| Sensible cooling capacity (kw) | 19.5 | 34.7 |
| Airflow | ||
| Airflow(m3/h) | 5000 | 8000 |
Our Services
Sample Service: We will collect some sample fees, will refund after you place order.
Package design support: We have brand team for your customized design.
Company Information
WEBITELECOMMS was established in 2008 and was awarded the rights of import and export in 2010.
Products range: 19''network cabinet,network rack,server cabinet,server rack,patch panel,PDU,network cable,fiber cable,outdoor cabinet,battery cabinet,IPAD charging cabinet
Audit Report: CE,ROHS,ISO.
Showroom: About 100 square meters showroom.
Welcome to WEBITELECOMMS, believe that our professional team and service will help you stay step ahead in the market.
FAQ
1) What is your Payment term?
---TT, LC, Western Union is could be accept.
2) What is your Trade term?
---EXW, FOB, CNF, CIF is also ok.
3) What is the Loading Port?
--- Ningbo,Shanghai.
4) What is your MOQ?
---MOQ of most our products is 5pcs, different items will be different. We have indicated the MOQ for each item in the price list.
5) What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market, international safety standard certificate is also be provided.
