Mini Duct Electrode Humidifier for Power 220V 50Hz
迷你管道电极加湿器电源220V 50Hz
| 型号。 | 迷你df d |
| 类型 | 汽化器/暖雾 |
| 证明 | ce，rohs，iso |
| 加湿方法 | 雾化放电 |
| 定时功能 | 具有定时功能 |
| 使用 | 家居，商业，别墅 |
| 体积大小 | 迷你加湿器 |
| 主要材料 | 不锈钢或铝合金 |
| 控制 | 流量传感器 |
| 形成一套 | 新鲜空气系统 |
| 商标 | giantsteam |
| 起源 | 中国制造 |
| 样式 | 天花板 |
| 用法 | 家居，工业，别墅 |
| 湿度控制 | 自动 |
| 电源类型 | 交流电源 |
| 缺水关机保护 | 缺水断电保护 |
| 提示 | 一个闹钟 |
| 电压 | 2p-220v 230v |
| 保养 | 方便 |
| 湿度 | 90％Rh |
| 核心技术 | 领先技术 |
| 规范 | ce fc iso |
| HS编码 | 8509809000 |
产品说明
MINI系列加湿器适用于需要小型蒸汽加湿器的小型交流电机组，如风机盘管，小型新鲜空气机组，恒温恒湿室，特别适用于天花板或其他高度限制的场所。
特征
紧凑的设计，特别是260mm的高度，使得该装置可以安装在里面的天花板内。
体积小，效率高，清洁无菌，维护方便。
微电脑控制，自动运行。
自动清洗，减量，延长使用寿命。
将湿度提高到90％RH以上。
内置空气流量传感器，确保加湿器功率只有当空气流动时
应用
净化空调，AHU，风机盘管单元，恒温恒湿空调，冷库，文物保存，档案室，实验室，电脑室，通讯室，办公室，家庭房，酒店，手术室，印刷厂，电子工厂，香烟工厂，制药厂，纺织厂等。
技术参数
模型
蒸汽容量
（千克/小时）
电源
功率
千瓦
适合面积
m 2
适合空气
m 3 /
宽度
毫米
厚度
毫米
高度
毫米
重量
公斤
迷你-1D
0.5-1.0
AC220V±10％usmn; 10％usmn;10%
0.75
20-100
100-200
490
380
260
6.5
微型2D
0.5-2.0
1.50
20-200
200-400
迷你3D
0.5-3.0
2.25
20-300
300-600
迷你6D
3.0-6.0
4.50
300-600
500-1200
710
380
260
9
领先技术
世界上唯一的电极加湿器是32位低功耗微处理芯片;
世界上唯一使用神经网络和人工智能算法的电极加湿器控制器;
世界唯一的电极加湿器，支持WIFI通信，用于监控和控制网络;
世界上唯一内置微型气缸的智能气缸工作过程控制;
世界上唯一具有高档漏电保护功能的电极加湿器;
世界上唯一的超级清洁功能电极加湿器;
MINI系列加湿器适用于需要小型蒸汽加湿器的小型交流电机组，如风机盘管，小型新鲜空气机组，恒温恒湿室，特别适用于天花板或其他高度限制的场所。
特征
紧凑的设计，特别是260mm的高度，使得该装置可以安装在里面的天花板内。
体积小，效率高，清洁无菌，维护方便。
微电脑控制，自动运行。
自动清洗，减量，延长使用寿命。
将湿度提高到90％RH以上。
内置空气流量传感器，确保加湿器功率只有当空气流动时
应用
净化空调，AHU，风机盘管单元，恒温恒湿空调，冷库，文物保存，档案室，实验室，电脑室，通讯室，办公室，家庭房，酒店，手术室，印刷厂，电子工厂，香烟工厂，制药厂，纺织厂等。
技术参数
模型
蒸汽容量
（千克/小时）
电源
功率
千瓦
适合面积
m 2
适合空气
m 3 /
宽度
毫米
厚度
毫米
高度
毫米
重量
公斤
迷你-1D
0.5-1.0
AC220V±10％usmn; 10％usmn;10%
0.75
20-100
100-200
490
380
260
6.5
微型2D
0.5-2.0
1.50
20-200
200-400
迷你3D
0.5-3.0
2.25
20-300
300-600
迷你6D
3.0-6.0
4.50
300-600
500-1200
710
380
260
9
领先技术
世界上唯一的电极加湿器是32位低功耗微处理芯片;
世界上唯一使用神经网络和人工智能算法的电极加湿器控制器;
世界唯一的电极加湿器，支持WIFI通信，用于监控和控制网络;
世界上唯一内置微型气缸的智能气缸工作过程控制;
世界上唯一具有高档漏电保护功能的电极加湿器;
世界上唯一的超级清洁功能电极加湿器;
| Model NO. | MINI DF D |
| Type | Vaporizer / Warm Mist |
| Certification | CE, RoHS, ISO |
| Humidification Method | Mist Discharge |
| Timing Function | With Timing Function |
| Use | Household, Commercial, Villa |
| Volume Size | Mini Humidifier |
| Main Material | Stainless Steel or Aluminum Alloy |
| Control | Flow Sensor |
| Form a Complete Set of | Fresh Air System |
| Trademark | GIANTSTEAM |
| Origin | Made in China |
| Style | Ceiling |
| Usage | Home, Industry, Villa |
| Humidity Control | Automatic |
| Power Type | AC Source |
| Water Shortage Power-off Protection | With Water Shortage Power-off Protection |
| Prompt | an Alarm |
| Voltage | 2p-220V 230V |
| Maintenance | Convenient |
| Humidity | 90% Rh |
| Core Technology | Leading Technology |
| Specification | CE FC ISO |
| HS Code | 8509809000 |
Product descriptions
MINI series humidifier is used for small AC units,such as fan coil units,small fresh air units,constant temperature and humidity chambers,when a small steam humidifier is needed.It is particularly suitable for installation in ceiling or other height-restricted places.
Features
The compact design,especially the height of 260mm,enables the unit be installed inside thenarrow ceiling.
Small volume, high efficiency, clean sterile, maintenance is convenient.
Microcomputer control, automatic operation.
Automatic cleaning, reduce scale, prolong life.
Improve the humidity to 90% RH or more.
Built-in air flow sensors, ensuring that the humidifier power only when the air flow
Applications
Purifying air conditioning,AHU,fan coil unit,constant temperature and humidity air conditioning,cold storage,heritage preservation,archives,laboratories,computer rooms,communications room,office,family room,hotel,operating room,printing plants,electronic factories,cigarette factories,pharmaceutical plants,textile mills,etc.
Technical parameters
Model
Steam Capacity
(kg/h)
Power supply
Power
KW
Suitable for area
m 2
Suitable for air
m 3 /
Width
mm
Thickness
mm
Height
mm
Weight
kg
MINI-1D
0.5-1.0
AC220V±10%usmn;10%usmn;10%
0.75
20-100
100-200
490
380
260
6.5
MINI-2D
0.5-2.0
1.50
20-200
200-400
MINI-3D
0.5-3.0
2.25
20-300
300-600
MINI-6D
3.0-6.0
4.50
300-600
500-1200
710
380
260
9
Leading technology
The world's only electrode humidifier that 32-bit low-power micro-processing chip;
The world's only electrode humidifier controller that uses neural networks and artificial intellingence algorithms;
The world only electrode humidifier that supports WIFI communications for monitoring and controlling networks;
The world's only built-in micro-chip in cylinder for intelligent cylinder working process control;
The world's only electrode humidifier who has high-grade electric leakage protection function;
The world's only super-cleaning functioned electrode humidifier;
MINI series humidifier is used for small AC units,such as fan coil units,small fresh air units,constant temperature and humidity chambers,when a small steam humidifier is needed.It is particularly suitable for installation in ceiling or other height-restricted places.
Features
The compact design,especially the height of 260mm,enables the unit be installed inside thenarrow ceiling.
Small volume, high efficiency, clean sterile, maintenance is convenient.
Microcomputer control, automatic operation.
Automatic cleaning, reduce scale, prolong life.
Improve the humidity to 90% RH or more.
Built-in air flow sensors, ensuring that the humidifier power only when the air flow
Applications
Purifying air conditioning,AHU,fan coil unit,constant temperature and humidity air conditioning,cold storage,heritage preservation,archives,laboratories,computer rooms,communications room,office,family room,hotel,operating room,printing plants,electronic factories,cigarette factories,pharmaceutical plants,textile mills,etc.
Technical parameters
Model
Steam Capacity
(kg/h)
Power supply
Power
KW
Suitable for area
m 2
Suitable for air
m 3 /
Width
mm
Thickness
mm
Height
mm
Weight
kg
MINI-1D
0.5-1.0
AC220V±10%usmn;10%usmn;10%
0.75
20-100
100-200
490
380
260
6.5
MINI-2D
0.5-2.0
1.50
20-200
200-400
MINI-3D
0.5-3.0
2.25
20-300
300-600
MINI-6D
3.0-6.0
4.50
300-600
500-1200
710
380
260
9
Leading technology
The world's only electrode humidifier that 32-bit low-power micro-processing chip;
The world's only electrode humidifier controller that uses neural networks and artificial intellingence algorithms;
The world only electrode humidifier that supports WIFI communications for monitoring and controlling networks;
The world's only built-in micro-chip in cylinder for intelligent cylinder working process control;
The world's only electrode humidifier who has high-grade electric leakage protection function;
The world's only super-cleaning functioned electrode humidifier;
