产品说明
OEM系列加湿器没有外部外壳，通常配有备件包装，包括水组件，电路板，蒸汽软管和蒸汽分配器等。主要用于电脑室空调，恒温恒湿室，遗物德
控制模式（开/开或比例）定位箱或其他类似产品作为蒸汽发生器。
客户在空调机内安装OEM加湿器，并将电路板放在电气柜内。客户需要额外的交流接触器，空气开关，电线，插头和其他配件来建立一个完整的加湿器系统。
产品组成
其中包括水装配，电路板，蒸汽软管和蒸汽分配器等。
应用
净化空调，AHU，风机盘管单元，恒温恒湿空调，冷库，文物保存，档案室，实验室，电脑室，通讯室，办公室，家庭房，酒店，手术室，印刷厂，电子工厂，香烟工厂，制药厂，纺织厂等。
采购通知
请提供以下信息：
加湿器的蒸汽容量
电源（电压，相位，频率）
蒸汽软管长度
蒸汽分配器长度
控制模式（开/关比例）
供水
领先技术
世界上唯一的电极加湿器是32位低功耗微处理芯片;
世界上唯一使用神经网络和人工智能算法的电极加湿器控制器;
世界唯一的电极加湿器，支持WIFI通信，用于监控和控制网络;
世界上唯一内置微型气缸的智能气缸工作过程控制;
世界上唯一具有高档漏电保护功能的电极加湿器;
世界上唯一的超级清洁功能电极加湿器;
模型
003M
蒸汽容量
公斤/小时
1-3
磅/小时
电压
V
220/1
相电流
A
3.5-10.5
功率
千瓦
0.75-2.25
控制器电压
V
气缸型号
迷你-C
尺寸（mm）
宽度
330
厚度
180
高度
230
蒸汽直径
出口
毫米
19
水的直径
进口
3 / 4'male threade线程 thread
水的直径
引流
毫米
22

Product descriptions
OEM series humidifier has no external enclosure and is usually supplied with spare parts package,which includes the water assembly,circuit board,steam hose and steam distributor,etc.It is mainly used to computer room air conditioning,constant temperature and humidity chamber,relics de
Control mode (on/of or proportional)posit box or other similar products as a steam generator.
Customer installs OEM humidifier inside the air conditioning units and put the circuit board within the electrical cabinet of AC. Customer needs additional AC contactors,air swithes,wires,plugs and other accessories to establish a complete humidifier system.
component of product
which includes the water assembly,circuit board,steam hose and steam distributor,etc.
Applications
Purifying air conditioning,AHU,fan coil unit,constant temperature and humidity air conditioning,cold storage,heritage preservation,archives,laboratories,computer rooms,communications room,office,family room,hotel,operating room,printing plants,electronic factories,cigarette factories,pharmaceutical plants,textile mills,etc.
purchasing Notification
Please provide information below:
Steam Capacity of humidifier
Power supply (voltage,phase,frequency)
Length of steam hose
Length of steam distributor
Control mode (on/of or proportional)
Water supply
Leading technology
The world's only electrode humidifier that 32-bit low-power micro-processing chip;
The world's only electrode humidifier controller that uses neural networks and artificial intellingence algorithms;
The world only electrode humidifier that supports WIFI communications for monitoring and controlling networks;
The world's only built-in micro-chip in cylinder for intelligent cylinder working process control;
The world's only electrode humidifier who has high-grade electric leakage protection function;
The world's only super-cleaning functioned electrode humidifier;
Model
003M
Steam Capacity
Kg/h
1-3
Lb/h
Voltage
V
220/1
Phase Current
A
3.5-10.5
Power
KW
0.75-2.25
Controller Voltage
V
Cylinder Model
MINI-C
Size(mm)
Width
330
Thickness
180
height
230
Diameter of steam
outlet
mm
19
Diameter of water
inlet
3/4′male threade thread thread
Diameter of water
drainage
mm
22
