HID Compatible Thin Card
HID兼容薄卡
议价
加入意向| 型号。 | HID兼容薄卡 |
| 频率 | 在125kHz |
| 尺寸 | L86 * W54 * t0.8（+/- 0.04）毫米 |
| 商标 | Techcrepower |
| 起源 | 中国 |
| 芯片 | t5557，t5567，t5577 |
| 阅读距离 | 1-10cm |
| 材料 | PVC |
| 规范 | CE |
HID兼容薄卡
HID兼容卡
RF可编程
2.125 kHz
薄卡
4.26位或37位可选
产品规格：
兼容HID阅读器
RF-可编程
125 kHz厚卡
标准26位或37位可选
尺寸：L86×W54×T0.8（+/- 0.04）mm（+/- 0.04）mm (+/- 0.04)mm
重量：5.8g +/- 0.5g
标准颜色：白色
工作温度-50°至160°F（-45°至70°C），例如：至70℃）; C)eg; To 70° C)
应用：
企业，银行，交通，保险，超级营销，停车场，学校，图书馆管理，门禁等。
HID兼容卡
RF可编程
2.125 kHz
薄卡
4.26位或37位可选
产品规格：
兼容HID阅读器
RF-可编程
125 kHz厚卡
标准26位或37位可选
尺寸：L86×W54×T0.8（+/- 0.04）mm（+/- 0.04）mm (+/- 0.04)mm
重量：5.8g +/- 0.5g
标准颜色：白色
工作温度-50°至160°F（-45°至70°C），例如：至70℃）; C)eg; To 70° C)
产品介绍 | |||||||
卡>>厚卡/薄卡丹卡 | |||||||
名称 | HID兼容薄卡 | ||||||
关键参数 | 芯片 | t5557，t5567，t5577 | |||||
频率 | 在125kHz | ||||||
阅读距离 | 1-10cm | ||||||
尺寸 | L86 * W54 * t0.8（+/- 0.04）毫米 | ||||||
材料 | PVC | ||||||
证明 | ce，fcc，rohs | ||||||
优点 | 高品质，高可靠性，快速交货，良好的服务，合理的价格 | ||||||
卡/标签/ Fob *系列*推荐 | |||||||
MOQ | 1只/ 10件/ 20只/ 50件/ 100个/ 200个/ 500个/ 1000个 | ||||||
交货时间 | 订单后2-10天 | ||||||
外壳材料 | 优质PVC / PET / ABS | ||||||
物理尺寸 | 各种常用标准尺寸或按需。 | ||||||
厚度 | 各种常用厚度，或按需 | ||||||
重量 | NW5.8g +/-0.5克 | ||||||
可用颜色 | 白色/红色/黄色/黑色/蓝色或按需 | ||||||
可用打印方式 | 偏移/ SilKscreen /银或金色效果/紫外线 | ||||||
其他可用选项 | 芯片编码 | ||||||
卡片表面 | 哑光/光泽度 | ||||||
证明 | ISO，CE，FCC，ROHS，SGS | ||||||
打印颜色 | 可以打印成两面全色，还有泛颜色或丝网色，光泽/亚光层压/ UV膜/沙质表面 | ||||||
付款燕鸥 | 我们接受exw / fob / cif，l / c，paypal，t / t，西联，托管 | ||||||
交货方式 | 快递快递（DHL / FedEx / UPS / TNT / EMS），空运或海运 | ||||||
套餐详情 | 瘦卡停车场：200个/箱，5000个/箱，毛重约35kg | ||||||
厚度卡包装：每箱100件，每箱2000件 | |||||||
纸箱尺寸 | 50x4x8cm | ||||||
可用的工艺品 | 光泽，哑光，磨砂层压/成品 | ||||||
磁条 | |||||||
签名面板和划线板 | |||||||
条码不同类型 | |||||||
烫金/银色 | |||||||
个性化：热/喷墨/压花/激光雕刻/ UV印刷中的数字或文字 | |||||||
芯片可用 | 低频125khz智能卡 | EM4100 | 64位只读 | ||||
EM4102 | 64位 | ||||||
TK4100，tk28，em4200，EM4305 | |||||||
Temic 5567，T5557，T5577 | |||||||
Hitag1 | 2048位 | ||||||
Hitag2（ISO11784 / 85） | 256位 | ||||||
高频13.56mhz智能卡 | M1经典S50 1K | 1K字节 | ISO14443A | ||||
M1经典S70 4K | 4K字节 | ||||||
复旦fm11rf08 | 1K字节 | ||||||
tks50 | 1K字节 | ||||||
MF超轻 | 512bit的 | ||||||
mf灭火 | 2K / 4K / 8K字节 | ||||||
mf desfire ev1 | 2K / 4K / 8K字节 | ||||||
MF Plus | 2K / 4K字节 | ||||||
Icode SLI2 | 1024位 | iso 15693 / iso 18000 | |||||
icode sli-s | 2048位 | iso 15693 / iso 18000，epc | |||||
860MHz的〜960MHz的 | ucode hsl | 第2代 | |||||
ucode gen2 xl | |||||||
ata 5590 | |||||||
温度 | -10°C至+ 50°C + 50°Ceg;C+50°C | ||||||
工作湿度 | ≤80％; 80％;80% | ||||||
样品可用性 | 酒店可应要求提供免费样品 | ||||||
应用：
企业，银行，交通，保险，超级营销，停车场，学校，图书馆管理，门禁等。
| Model NO. | HID Compatible Thin card |
| Frequency | 125kHz |
| Dimension | L86*W54*T0.8(+/-0.04)mm |
| Trademark | Techcrepower |
| Origin | China |
| Chips | T5557, T5567, T5577 |
| Reading Distance | 1-10cm |
| Material | PVC |
| Specification | CE |
HID Compatible Thin card
HID compatible card
1. RF-programmable
2.125 kHz
3. Thin Card
4.26 bit or 37 bit Optional
Specifications:
Compatible with HID reader
RF-programmable
125 kHz Thick Card
Standard 26 bit or 37 bit Optional
Dimension: L86× W54× T0.8 (+/- 0.04)mm (+/- 0.04)mm (+/- 0.04)mm
Weight: 5.8g+/-0.5g
Standard Color: White
Operating Temperature -50° To 160° F (-45° To 70° C)eg; To 70° C); C)eg; To 70° C)
Applications:
Enterprises, bank, traffic, insurance, super marketing, parking, school, library management, access control ect.
HID compatible card
1. RF-programmable
2.125 kHz
3. Thin Card
4.26 bit or 37 bit Optional
Specifications:
Compatible with HID reader
RF-programmable
125 kHz Thick Card
Standard 26 bit or 37 bit Optional
Dimension: L86× W54× T0.8 (+/- 0.04)mm (+/- 0.04)mm (+/- 0.04)mm
Weight: 5.8g+/-0.5g
Standard Color: White
Operating Temperature -50° To 160° F (-45° To 70° C)eg; To 70° C); C)eg; To 70° C)
Products Introduction | |||||||
Card ﹥﹥ Thick Card / Thin Cardin Card | |||||||
Name | HID Compatible Thin Card | ||||||
Key Parameter | Chips | T5557, T5567, T5577 | |||||
Frequency | 125KHZ | ||||||
Reading Distance | 1-10cm | ||||||
Dimension | L86*W54*T0.8(+/-0.04)mm | ||||||
Material | PVC | ||||||
Certification | CE, FCC, RoHS | ||||||
Advantage | High Quality, High Reliability, Fast Delivery, Good Servies, Reasonable prices | ||||||
Card/Tag/Fob *Series* Recommend | |||||||
MOQ | 1pcs/10pcs/20pcs/50pcs/100pcs/200pcs/500pcs/1000pcs | ||||||
Lead time | 2-10 days after order | ||||||
Housing Material | High quality PVC/PET/ABS | ||||||
Physical Dimension | All kinds of commonly used standard size, or on demand. | ||||||
Thickness | All kinds of commonly used thickness, or on demand | ||||||
Weight | NW5.8g+/-0.5g | ||||||
Available Colors | White/Red/Yellow/Black/Blue, or on demand | ||||||
Available Printing Method | Offset/SilKscreen/Silver or Gold Gilittering Effect/UV Pring | ||||||
Other Available Options | Chip Encoding | ||||||
Card Surface | Matte/ gloss finish | ||||||
Certification | ISO,CE,FCC,RoHS,SGS | ||||||
Printing Color | can be printed in 1 to full color on both sides, and also pantone colors or silk screen colors , glossy/matt laminated/UV film/sandy surface | ||||||
Payment terns | We accept EXW/FOB/CIF, L/C, PayPal, T/T, Western Union, ESCROW | ||||||
Delivery way | By Express Courier(DHL/FedEx/UPS/TNT/EMS), By Air or Sea shipment | ||||||
Package details | Thin card parkage: 200pcs/box, 5000pcs/carton,gross weight around 35kgs | ||||||
Thickness card package: 100pcs per box, 2000pcs per carton | |||||||
Carton Size | 50x4x8cm | ||||||
Available crafts | glossy, matt, frosted laminated/finished | ||||||
magnetic strip | |||||||
signature panel and scratch panel | |||||||
barcode in different types | |||||||
hotstamping gold/silver color | |||||||
personalization: numbers or texts in thermal/inkjet /embossed/laser engraved/UV printing | |||||||
Chip Available | Low frequency 125khz smart card | EM4100 | 64bit read only | ||||
EM4102 | 64bit | ||||||
TK4100,TK28,EM4200,EM4305 | |||||||
Temic 5567,T5557,T5577 | |||||||
Hitag1 | 2048bit | ||||||
Hitag2(ISO11784/85) | 256bit | ||||||
High frequency 13.56mhz smart card | M1 Classic S50 1K | 1K byte | ISO14443A | ||||
M1 Classic S70 4K | 4K byte | ||||||
FUDAN FM11RF08 | 1K byte | ||||||
TKS50 | 1K byte | ||||||
MF Ultralight | 512bit | ||||||
MF DESFire | 2K/4K/8K byte | ||||||
MF DESFire EV1 | 2K/4K/8K byte | ||||||
MF Plus | 2K/4K byte | ||||||
Icode SLI2 | 1024 bit | ISO 15693/ISO 18000 | |||||
Icode SLI-S | 2048 bit | ISO 15693/ISO 18000, EPC | |||||
860MHz~960MHz | UCODE HSL | GEN 2 | |||||
UCODE GEN2 XL | |||||||
ATA 5590 | |||||||
Temperature | -10°C to +50°C+50°Ceg;C+50°C | ||||||
Operating humidity | ≤80%;80%;80% | ||||||
Sample Availability | Free samples are available upon request | ||||||
Applications:
Enterprises, bank, traffic, insurance, super marketing, parking, school, library management, access control ect.
