7.4V 6.6ah Lithium Polymer Battery Packs
7.4V 6.6ah锂聚合物电池组
| 型号。 | 7.4v 6.6ah |
| 连接方式 | 系列和并行 |
| 放电率 | 中等放电率 |
| 配件类型 | 电池 |
| 标准电压 | 8.4v〜12v |
| 电解液 | 酸 |
| 规范 | 108 *65毫米 |
| HS编码 | 85078020 |
| 类型 | 锂离子电池组 |
| 充电 | 收费 |
| 尺寸 | 中 |
| 额定容量 | > 1000mah00mah |
| 用法 | 电子产品 |
| 商标 | UPT品牌 |
| 起源 | 中国广东省 |
质量7.4V 6.6Ah锂离子电池
型号可充电锂电池
标称电压7.4V
容量6.6Ah
尺寸108 * 65mm
重量300g
外套PVC收缩管
规范：
最大充电电压：8.4V
放电截止电压：6V
最大连续充电电流：1C5A
最大连续充电电流：2C5A
内阻：<60mΩ60mΩ
电池重量：约300g
标准充电：恒流0.5C5A，恒压4.2V，截止电流0.01C5A
快速充电：恒流1C5A，电源电压4.2V，截止电压2.75V
工作温度：充电：0ºC-44ºCCC-44ºCrdm;CC-44ºC
放电：-20ºC-60ºC; C-60ºCdm;C;C-60ºC
储存温度：不超过3个月：-20ºC-45ºC小于1年：-20ºC-25ºC-20ºC-25ºC-25ºC -20ºC-25ºC
保护性能：包含PTC热熔丝
应用：
1.内存备份：CMOS内存，RTC（实时时钟）和电脑备份。
2. AMR电表：电表，燃气表和水表等
3.无线报警传感器：烟雾报警系统，温度监视器等
4.远程监控系统：GPS，海上浮标，救生衣灯，救生灯，货物定位系统等。
5.汽车和电子：汽车安全系统，轮胎压力监测系统等
电子收费标签：收费站
7.军事电子：无线电通信，夜视设备，跟踪和定位系统
等等
型号可充电锂电池
标称电压7.4V
容量6.6Ah
尺寸108 * 65mm
重量300g
外套PVC收缩管
规范：
最大充电电压：8.4V
放电截止电压：6V
最大连续充电电流：1C5A
最大连续充电电流：2C5A
内阻：<60mΩ60mΩ
电池重量：约300g
标准充电：恒流0.5C5A，恒压4.2V，截止电流0.01C5A
快速充电：恒流1C5A，电源电压4.2V，截止电压2.75V
工作温度：充电：0ºC-44ºCCC-44ºCrdm;CC-44ºC
放电：-20ºC-60ºC; C-60ºCdm;C;C-60ºC
储存温度：不超过3个月：-20ºC-45ºC小于1年：-20ºC-25ºC-20ºC-25ºC-25ºC -20ºC-25ºC
保护性能：包含PTC热熔丝
应用：
1.内存备份：CMOS内存，RTC（实时时钟）和电脑备份。
2. AMR电表：电表，燃气表和水表等
3.无线报警传感器：烟雾报警系统，温度监视器等
4.远程监控系统：GPS，海上浮标，救生衣灯，救生灯，货物定位系统等。
5.汽车和电子：汽车安全系统，轮胎压力监测系统等
电子收费标签：收费站
7.军事电子：无线电通信，夜视设备，跟踪和定位系统
等等
| Model NO. | 7.4V 6.6Ah |
| Connection Mode | Series and Parallel |
| Discharge Rate | Medium Discharge Rate |
| Accessories Type | Battery |
| Standard Voltage | 8.4V~ 12V |
| Electrolyte | Acid |
| Specification | 108*65mm |
| HS Code | 85078020 |
| Type | Lithium-Ion Battery Pack |
| Rechargeable | Chargeable |
| Size | Medium |
| Rated Capacity | ﹥1000MAH00MAH |
| Usage | Electronics Products |
| Trademark | UPT brand |
| Origin | Guangdong Province, China |
Quality 7.4V 6.6Ah Li-ion battery
Model No. Rechargeable lithium battery
Nominal Voltage 7.4V
Capacity 6.6Ah
Size 108*65mm
Weight 300g
Jacket PVC Shrink tube
Specification:
Maximum charge voltage :8.4V
Discharge Cut-off voltage: 6V
Maximum continuous charge current : 1C5A
Maximum continuous charge current: 2C5A
Internal Impedance:<60mΩ60mΩ
Battery Weight: Approx 300g
Standard charge: Constant Current 0.5C5A ,Constant Voltage 4.2V, Cut-off current 0.01C5A
Rapid Charge: Constant current 1C5A,Contant voltage 4.2V ,Cut-off Voltage 2.75V
Operation Temperature: Charge: 0ºC-44ºCC-44ºCrdm;CC-44ºC
Discharge: -20ºC-60ºC;C-60ºCdm;C;C-60ºC
Storge Temperature: Less than 3months:-20ºC-45ºC Less than 1 year: -20ºC-25ºC -20ºC-25ºC-25ºC -20ºC-25ºC
Protect Performance: Contain PTC heat-fuse
Applications:
1. Memory backup: CMOS memory, RTC(real time clock) and computer backup.
2. AMR utility meters: Electricity meter, gas meter and water meter etc.
3. Wireless alarm sensors: Smoke alarm systems, temperature monitors etc.
4. Remote monitor systems: GPS, sea buoys, lifejacket lights, lifecraft lights, cargo-locating systems etc.
5. Automotive and electronics: Automotive security systems, tire-pressure monitoring systems etc.
6. Electronics toll tags: Toll gates
7. Military electronics: Radio communication, night vision equipment, tracking and positioning systems
etc.
Model No. Rechargeable lithium battery
Nominal Voltage 7.4V
Capacity 6.6Ah
Size 108*65mm
Weight 300g
Jacket PVC Shrink tube
Specification:
Maximum charge voltage :8.4V
Discharge Cut-off voltage: 6V
Maximum continuous charge current : 1C5A
Maximum continuous charge current: 2C5A
Internal Impedance:<60mΩ60mΩ
Battery Weight: Approx 300g
Standard charge: Constant Current 0.5C5A ,Constant Voltage 4.2V, Cut-off current 0.01C5A
Rapid Charge: Constant current 1C5A,Contant voltage 4.2V ,Cut-off Voltage 2.75V
Operation Temperature: Charge: 0ºC-44ºCC-44ºCrdm;CC-44ºC
Discharge: -20ºC-60ºC;C-60ºCdm;C;C-60ºC
Storge Temperature: Less than 3months:-20ºC-45ºC Less than 1 year: -20ºC-25ºC -20ºC-25ºC-25ºC -20ºC-25ºC
Protect Performance: Contain PTC heat-fuse
Applications:
1. Memory backup: CMOS memory, RTC(real time clock) and computer backup.
2. AMR utility meters: Electricity meter, gas meter and water meter etc.
3. Wireless alarm sensors: Smoke alarm systems, temperature monitors etc.
4. Remote monitor systems: GPS, sea buoys, lifejacket lights, lifecraft lights, cargo-locating systems etc.
5. Automotive and electronics: Automotive security systems, tire-pressure monitoring systems etc.
6. Electronics toll tags: Toll gates
7. Military electronics: Radio communication, night vision equipment, tracking and positioning systems
etc.
