UHF Laundry Tag
UHF洗衣标签
| 型号。 | 洗衣标签 |
| 类型 | 智能卡 |
| 标签类别 | 被动 |
| 应用领域 | 市场 |
| 频率 | 超高频 |
| 商标 | Techcrepower |
| 起源 | 中国 |
| 功能 | 识别，信息 |
| 读写方式 | 非接触式 |
| 结构体 | 读写卡 |
| 电源模式 | 被动卡 |
| 数据传输模式 | 串行 |
| 规范 | CE |
可硅洗UHF RFID洗衣标签
RFID洗衣标签抵抗高温和洗衣应用中的极端化学环境。
它是通过两次注射成型尼龙材料生产的，并且可以用于需要强标签的许多其它应用中。
洗衣标签的应用程序rfid：
过程控制和工厂自动化ation
物品识别
主要特征：
尺寸：80 * 20 * 2,90 * 30 * 2mm
厚度：2mm
外壳：尼龙流苏，两次注塑
防水：是的，IP68
工作温度：-20〜+ 90℃
峰值温度：160℃35h，220℃30sec
电阻：化学腐蚀
可选RFID IC：
13.56mhz：1k / 4k / ultralight iso14443a;我编码sli iso15693; tag-it hf2048;
125KHz：EM马林EM4102 / 4100; 125KHz独特的GK4001; Hitag1 / 2; Atmel T5567;
阅读范围：放弃RFID技术和阅读器设计
RFID洗衣标签抵抗高温和洗衣应用中的极端化学环境。
它是通过两次注射成型尼龙材料生产的，并且可以用于需要强标签的许多其它应用中。
洗衣标签的应用程序rfid：
过程控制和工厂自动化ation
物品识别
主要特征：
尺寸：80 * 20 * 2,90 * 30 * 2mm
厚度：2mm
外壳：尼龙流苏，两次注塑
防水：是的，IP68
工作温度：-20〜+ 90℃
峰值温度：160℃35h，220℃30sec
电阻：化学腐蚀
产品介绍 | |||||||
卡>>钥匙卡 | |||||||
名称 | RFID洗衣标签 | ||||||
关键参数 | 芯片 | em4100 / tk4100 / s50 / s70 | |||||
频率 | 125khz / 13.56mhz | ||||||
阅读距离 | 1-10厘米/ 1-5厘米 | ||||||
尺寸 | 9,10,11,12,13,14,15,16,17,18,20,22,24,26,28,30mm | ||||||
材料 | PPS + epocy | ||||||
证明 | ce，fcc，rohs | ||||||
优点 | 高品质，高可靠性，快速交货，良好的服务，合理的价格 | ||||||
卡/标签/ Fob *系列*推荐 | |||||||
暴民 | 1只/ 10件/ 20只/ 50件/ 100个/ 200个/ 500个/ 1000个 | ||||||
交货时间 | 订单后2-10天 | ||||||
外壳材料 | 优质PVC / PET / ABS | ||||||
物理尺寸 | 各种常用标准尺寸或按需。 | ||||||
厚度 | 各种常用厚度，或按需 | ||||||
重量 | NW5.8g +/-0.5克 | ||||||
可用颜色 | 白色/红色/黄色/黑色/蓝色或按需 | ||||||
可用打印方式 | 偏移/ SilKscreen /银或金色效果/紫外线 | ||||||
其他可用选项 | 芯片编码 | ||||||
卡片表面 | 哑光/光泽度 | ||||||
证明 | ISO，CE，FCC，ROHS，SGS | ||||||
打印颜色 | 可以打印成两面全色，还有泛颜色或丝网色，光泽/亚光层压/ UV膜/沙质表面 | ||||||
付款燕鸥 | 我们接受exw / fob / cif，l / c，paypal，t / t，西联，托管 | ||||||
交货方式 | 快递快递（DHL / FedEx / UPS / TNT / EMS），空运或海运 | ||||||
套餐详情 | 瘦卡停车场：200个/箱，5000个/箱，毛重约35kg | ||||||
厚度卡包装：每箱100件，每箱2000件 | |||||||
纸箱尺寸 | 50x4x8cm | ||||||
可用的工艺品 | 光泽，哑光，磨砂层压/成品 | ||||||
磁条 | |||||||
签名面板和划线板 | |||||||
条码不同类型 | |||||||
烫金/银色 | |||||||
个性化：热/喷墨/压花/激光雕刻/ UV印刷中的数字或文字 | |||||||
芯片可用 | 低频125khz智能卡 | EM4100 | 64位只读 | ||||
EM4102 | 64位 | ||||||
TK4100，tk28，em4200，EM4305 | |||||||
Temic 5567，T5557，T5577 | |||||||
Hitag1 | 2048位 | ||||||
Hitag2（ISO11784 / 85） | 256位 | ||||||
高频13.56mhz智能卡 | M1经典S50 1K | 1K字节 | ISO14443A | ||||
M1经典S70 4K | 4K字节 | ||||||
复旦fm11rf08 | 1K字节 | ||||||
tks50 | 1K字节 | ||||||
MF超轻 | 512bit的 | ||||||
mf灭火 | 2K / 4K / 8K字节 | ||||||
mf desfire ev1 | 2K / 4K / 8K字节 | ||||||
MF Plus | 2K / 4K字节 | ||||||
Icode SLI2 | 1024位 | iso 15693 / iso 18000 | |||||
icode sli-s | 2048位 | iso 15693 / iso 18000，epc | |||||
860MHz的〜960MHz的 | ucode hsl | 第2代 | |||||
ucode gen2 xl | |||||||
ata 5590 | |||||||
温度 | -10°C至+ 50°C + 50°Ceg;C+50°C | ||||||
工作湿度 | ≤80％; 80％;80% | ||||||
样品可用性 | 酒店可应要求提供免费样品 | ||||||
可选RFID IC：
13.56mhz：1k / 4k / ultralight iso14443a;我编码sli iso15693; tag-it hf2048;
125KHz：EM马林EM4102 / 4100; 125KHz独特的GK4001; Hitag1 / 2; Atmel T5567;
阅读范围：放弃RFID技术和阅读器设计
| Model NO. | Laundry Tag |
| Type | Smart Card |
| Label Category | Passive |
| Application Field | Market |
| Frequency | Ultrahigh Frequency |
| Trademark | Techcrepower |
| Origin | China |
| Function | Identification, Information |
| Read-Write Method | Non-Contact Type |
| Structure | Read-Write Card |
| Power Supply Mode | Passive Card |
| Data Transmission Mode | Serial |
| Specification | CE |
Silicon Washable UHF RFID Laundry Tag
RFID laundry tag resists high temperature, and extreme chemical environment in laundry application.
It is produced by twice injection moulding with nylon material, and can be used in many other applications which require a strong tag.
Applications for the laundry tag rfid :
Process Control & Factory Automationationation
Item Identification
Key Features:
Dimensions: 80*20*2,90*30*2mm
Thickness: 2mm
Housing: Nylon flbre, Twice injection moulding
Water-proof: Yes, IP68
Operating Temperature: -20 to +90C
Peak Value Temperature: 160C 35h, 220C 30sec
Resistance: Harsh chemical
Optional RFID ICs:
13.56MHz: 1K/4K/Ultralight ISO14443A; I CODE SLI ISO15693; Tag-it HF2048;
125KHz: EM Marin EM4102/4100; 125KHz Unique GK4001; Hitag1/2; Atmel T5567;
Reading Range: Depanding on RFID technology and reader design
RFID laundry tag resists high temperature, and extreme chemical environment in laundry application.
It is produced by twice injection moulding with nylon material, and can be used in many other applications which require a strong tag.
Applications for the laundry tag rfid :
Process Control & Factory Automationationation
Item Identification
Key Features:
Dimensions: 80*20*2,90*30*2mm
Thickness: 2mm
Housing: Nylon flbre, Twice injection moulding
Water-proof: Yes, IP68
Operating Temperature: -20 to +90C
Peak Value Temperature: 160C 35h, 220C 30sec
Resistance: Harsh chemical
Products Introduction | |||||||
Card ﹥﹥ Key Cardey Card | |||||||
Name | RFID Laundry Tag | ||||||
Key Parameter | Chips | EM4100 / TK4100 / S50 / S70 | |||||
Frequency | 125KHZ / 13.56MHZ | ||||||
Reading Distance | 1-10cm / 1-5cm | ||||||
Dimension | 9,10,11,12,13,14,15,16,17,18,20,22,24,26,28,30mm | ||||||
Material | PPS +epocy | ||||||
Certification | CE, FCC, RoHS | ||||||
Advantage | High Quality, High Reliability, Fast Delivery, Good Servies, Reasonable prices | ||||||
Card/Tag/Fob *Series* Recommend | |||||||
MOB | 1pcs/10pcs/20pcs/50pcs/100pcs/200pcs/500pcs/1000pcs | ||||||
Lead time | 2-10 days after order | ||||||
Housing Material | High quality PVC/PET/ABS | ||||||
Physical Dimension | All kinds of commonly used standard size, or on demand. | ||||||
Thickness | All kinds of commonly used thickness, or on demand | ||||||
Weight | NW5.8g+/-0.5g | ||||||
Available Colors | White/Red/Yellow/Black/Blue, or on demand | ||||||
Available Printing Method | Offset/SilKscreen/Silver or Gold Gilittering Effect/UV Pring | ||||||
Other Available Options | Chip Encoding | ||||||
Card Surface | Matte/ gloss finish | ||||||
Certification | ISO,CE,FCC,RoHS,SGS | ||||||
Printing Color | can be printed in 1 to full color on both sides, and also pantone colors or silk screen colors , glossy/matt laminated/UV film/sandy surface | ||||||
Payment terns | We accept EXW/FOB/CIF, L/C, PayPal, T/T, Western Union, ESCROW | ||||||
Delivery way | By Express Courier(DHL/FedEx/UPS/TNT/EMS), By Air or Sea shipment | ||||||
Package details | Thin card parkage: 200pcs/box, 5000pcs/carton,gross weight around 35kgs | ||||||
Thickness card package: 100pcs per box, 2000pcs per carton | |||||||
Carton Size | 50x4x8cm | ||||||
Available crafts | glossy, matt, frosted laminated/finished | ||||||
magnetic strip | |||||||
signature panel and scratch panel | |||||||
barcode in different types | |||||||
hotstamping gold/silver color | |||||||
personalization: numbers or texts in thermal/inkjet /embossed/laser engraved/UV printing | |||||||
Chip Available | Low frequency 125khz smart card | EM4100 | 64bit read only | ||||
EM4102 | 64bit | ||||||
TK4100,TK28,EM4200,EM4305 | |||||||
Temic 5567,T5557,T5577 | |||||||
Hitag1 | 2048bit | ||||||
Hitag2(ISO11784/85) | 256bit | ||||||
High frequency 13.56mhz smart card | M1 Classic S50 1K | 1K byte | ISO14443A | ||||
M1 Classic S70 4K | 4K byte | ||||||
FUDAN FM11RF08 | 1K byte | ||||||
TKS50 | 1K byte | ||||||
MF Ultralight | 512bit | ||||||
MF DESFire | 2K/4K/8K byte | ||||||
MF DESFire EV1 | 2K/4K/8K byte | ||||||
MF Plus | 2K/4K byte | ||||||
Icode SLI2 | 1024 bit | ISO 15693/ISO 18000 | |||||
Icode SLI-S | 2048 bit | ISO 15693/ISO 18000, EPC | |||||
860MHz~960MHz | UCODE HSL | GEN 2 | |||||
UCODE GEN2 XL | |||||||
ATA 5590 | |||||||
Temperature | -10°C to +50°C+50°Ceg;C+50°C | ||||||
Operating humidity | ≤80%;80%;80% | ||||||
Sample Availability | Free samples are available upon request | ||||||
Optional RFID ICs:
13.56MHz: 1K/4K/Ultralight ISO14443A; I CODE SLI ISO15693; Tag-it HF2048;
125KHz: EM Marin EM4102/4100; 125KHz Unique GK4001; Hitag1/2; Atmel T5567;
Reading Range: Depanding on RFID technology and reader design
