Pneumatic Regulating Valve Ball Valve with V Type
V型气动调节阀球阀
| 型号。 | hsvq640f /小时 |
| 连接形式 | 轮缘 |
| 公称压力 | ansi课150-900 |
| 结构体 | 浮球阀 |
| 功能 | 吹气阀 |
| 应用 | 工业用水，工业用水 |
| 商标 | HS |
| 起源 | 青岛 |
| 材料 | 不锈钢 |
| 驾驶模式 | 电动 |
| 渠道 | 直通型 |
| 类型 | 浮球阀 |
| 温度 | 高温 |
| 直径 | DN15-DN300（可选） |
| 规范 | iso ce rohs |
| HS编码 | 8481804090 |
气动调节阀v型球阀
气动V型球阀，球芯为V形，可实现线性调节，范围广泛可调，当阀门关闭时，V型间隙与阀座之间产生楔形剪切功能，并且不仅具有自洁功能，而且防止球芯堵塞，特别适用于管道结垢和冷冻场合。适用于控制纸浆，污水，含纤维和固体颗粒悬浮介质和粉末颗粒介质。
产品规格
气动调节阀v型球阀
1）稳定的一块
2）金属，PTFE的密封
3）定位器，限位开关盒等
广泛应用于石油，化工，制药，轻工，自动化控制系统
设计标准
设计基础：gb / t12237，ansi b16.34，api 608
结构长度：GB / T12221，ASME B16.10，JIS B2002
端部法兰：gb / t9113，asme b16.5，jis b2212 / jis b2214
壁厚：ASME B16.34
防火测试：API 607 4th 1993
检测与试验：GB / T 13927，API598，JIS B2003
电动防爆球阀执行机构技术参数 | ||||||||||||||
| 执行器类型 | 3610R系列执行器参数 | HQ系列执行器参数 | ||||||||||||
| 电源电压 | 标准：220VAC可选：110V AC / 380 / 440V AC三相/ 24V / 110V / 220V AC | |||||||||||||
| 输出扭矩 | 50N @米〜1500N @米 | 50N @米〜3000N @米 | ||||||||||||
| 运动范围 | 0〜90°°deg;° | 0〜90°/ 0°〜270°（可选），例如;（可选）eg;(Optional) | ||||||||||||
| 启动时间 | 10秒/ 15秒/ 30秒 | 18S〜112S | ||||||||||||
| 保护装置 | 过热保护，过载保护 | 内置过热保护，过载保护 | ||||||||||||
| 保护装置 | -20℃〜+ 70℃〜+ 70℃rdm;C~+70ºC | |||||||||||||
| 手动操作 | 操作手柄 | 机械离合器机构，配合手轮操作 | ||||||||||||
| 机械极限 | 电气和机械双重限制 | 两个外部调整螺栓 | ||||||||||||
| 防护等级 | IP65 / IP67 | IP65 / IP67 / IP68（定制） | ||||||||||||
| 防爆等级 | exdii bt4 | exdii bt4 / exdii ct6 | ||||||||||||
| 位置测量 | 比例控制单元 | 电位计/比例控制单元 | ||||||||||||
| 驱动电机 | 交流可逆电机 | 鼠笼式感应电机 | ||||||||||||
| 壳材料 | 铝合金 | 钢，铝合金，铝青铜，聚碳酸酯 | ||||||||||||
| 外部涂料 | 干粉和环氧聚酯，具有很强的腐蚀功能 | |||||||||||||
| Model NO. | HSVQ640F/H |
| Connection Form | Flange |
| Nominal Pressure | ANSI CLASS 150-900 |
| Structure | Floating Ball Valve |
| Function | Blow-Down Valve |
| Application | Industrial Usage, Water Industrial Usage |
| Trademark | HS |
| Origin | Qingdao |
| Material | Stainless Steel |
| Driving Mode | Electric |
| Channel | Straight Through Type |
| Type | Floating Ball Valve |
| Temperature | High Temperature |
| Diameter | Dn15-Dn300(Optional) |
| Specification | ISO CE ROHS |
| HS Code | 8481804090 |
Pneumatic regulating valve v type ball valve
Pneumatic V-type ball valve, ball core is V-shape, can realize the linear adjustment, widely adjustable range, when the valve closed, between the V-type gap and the seat produced wedge shear function, and has not only self clean function, but also prevent the ball core jammed, especially suitable for pipeline scaling and frozen occasion. It is suitable for control pulp,sewage,contain fiber and solid particle suspended medium and powder granular media.
Specifications
Pneumatic regulating valve v type ball valve
1)Stable one piece
2)Seal for metal,PTFE
3)With positioner, limit switch box,etc
Widely used in petroleum, chemical, pharmaceutical, light industry, automatic control system
Design Standard
Design basis: GB/T12237, ANSI B16.34, API 608
Structure length: GB/T12221, ASME B16.10, JIS B2002
End flange: GB/T9113, ASME B16.5, JIS B2212/JIS B2214
Wall thickness: ASME B16.34
Fire test: API 607 4th 1993
Detection and Test: GB/T 13927, API598, JIS B2003
Electric Explosion-proof Ball Valve Actuator technology parameters | ||||||||||||||
| Type of actuator | 3610R series actuator parameters | HQ series actuator parameters | ||||||||||||
| Power voltage | Standard:220VAC Optional:110V AC /380/440V AC three-phase/24V/110V/220V AC | |||||||||||||
| Output Torque | 50N@M~1500N@M | 50N@M~3000N@M | ||||||||||||
| Movement range | 0~90°°deg;° | 0~90°/0°~270°(Optional)eg;(Optional)eg;(Optional) | ||||||||||||
| Actuation time | 10second /15second /30second | 18S~112S | ||||||||||||
| Protective device | Overheating protection, overload protection | Built-in overheating protection, overload protection | ||||||||||||
| Protective device | -20ºC~+70ºC~+70ºCrdm;C~+70ºC | |||||||||||||
| Manual operation | Operating handle | Mechanical clutch mechanism, match the handwheel operation | ||||||||||||
| Mechanical limit | Electrical and mechanical double limit | Two external adjustment bolts | ||||||||||||
| Protection grade | IP65/IP67 | IP65/IP67/IP68(Customizable) | ||||||||||||
| Explosion-proof grade | ExdII BT4 | ExdII BT4/ExdII CT6 | ||||||||||||
| Position measuring | Proportional control unit | potentiometer/Proportional control unit | ||||||||||||
| Drive motor | AC reversible motor | Squirrel cage induction motor | ||||||||||||
| Shell material | Aluminium alloy | Steel, aluminum alloy, aluminum bronze, polycarbonate | ||||||||||||
| External coatings | Dry powder, and epoxy polyester, it has strong corrosion function | |||||||||||||
