Light Truck Diesel Engine

Light Truck Diesel Engine

轻型柴油发动机

2500 USD

加入意向
型号。 k15 k10 3l16cf 4l18cf 4l22cf 4j28f 4j30f 4l30f
马力66HP： 速度：3600r /分钟
速度 高速
点火模式 压缩点火
冷却气瓶 水冷
气缸排列形式 H
规范 ISO9001质量认证;
HS编码 84089091
汽油 柴油发动机
进气压力脉冲 增压
活塞运动 往复式
气缸数 多缸机
中风次数 四条线
商标 LD
起源 中国山东莱阳

产品描述：采用涡轮增压直喷式冷却技术，电控高压共轨喷油系统，电动中冷EGR及DOC后处理技术，可以控制燃油喷射的喷射量，时间和压力，并更精确地控制排放。排放标准顺利实现EuroIV标准，另外提供过热保护，超速保护，涡轮增压保护等功能;噪音低，驾驶体验更舒适。由于产品推广已获得市场和用户的好评和认可。

技术特点：
1.采用涡轮增压直喷式冷却技术，电控高压共轨喷射系统，电冷却EGR以及DOC后处理技术。
开始快足够的电力
结构紧凑;美丽的设计
超低油耗;节能环保
小振动;低噪声
适用范围：支持广泛的光卡，微卡，SUV，MPV等领域。
产品参数：

型号。

K15

K10

3l16cf

4l18cf

4l22cf

4j28f

4j30f

4l30f

类型

共轨直喷+涡轮增压型间冷+ EGR（冷却）+后处理（DOC）

气缸数

4

3

3

4

4

4

4

4

孔径×行程（mm）ke（mm）ke (mm)

76×80.5es; 80.5es;80.5

76×80.5es; 80.5es;80.5

85×95imes; 95imes;95

80×90imes; 90imes;90

85×95imes; 95imes;95

93×102mes; 102mes;102

96×105mes; 105mes;105

96×105mes; 105mes;105

总排量（L）

1.461

1.095

1.617

1.809

2.156

2.774

3.04

3.04

额定功率/额定转速（kW）/（r / min）

45~58/3600

42/3600

42/3200

45/3200

58.8~60/

3200~3600

70/3600

75~90/3200

75/3200

最大。扭矩/转速（N.m）/（r / min）

140~180/

1800~2400

130/

1800~2400

130/2200

150~170/

2000~2400

187~206/

1800~2600

225/

1600~2400

264~300/2200

264/2200

满载最小燃料消耗率（g / kW.h）

≤210; 210;210

≤210; 210;210

≤220; 220;220

≤225; 225;225

≤220; 220;220

≤220; 220;220

≤215; 215;215

≤218; 218;218

尺寸

（毫米×毫米×毫米）;毫米×毫米）es;mm);mm×mm)

567.5×559mes; 559mes;559
×636mes; 636mes;636

536×610mes; 610mes;610
×662mes; 662mes;662

730×570mes; 570mes;570
×660mes; 660mes;660

830×565mes; 565mes;565
×630mes; 630mes;630

800×620mes; 620mes;620
×660mes; 660mes;660

781×627mes; 627mes;627
×740mes; 740mes;740

840×658mes; 658mes;658
×720mes; 720mes;720

840×658mes; 658mes;658
×720mes; 720mes;720

净重/公斤）

140

120

220

220

255

290

242

242

排放标准

EuroIV标准

EuroIV标准

EuroIV标准

EuroIV标准

EuroIV标准

EuroIV标准

EuroIV标准

EuroIV标准

后处理模式

DOC

DOC

DOC

DOC

DOC

DOC + DPF，SCR

DOC + DPF，SCR

DOC + DPF，SCR

Model NO. K15 K10 3L16CF 4L18CF 4L22CF 4J28F 4J30F 4L30F
Horse Power 66HP: Speed:3600r/Min
Speed High Speed
Ignition Mode Compression-Ignition
Cooling Cylinder Water-Cooled
Cylinder Arrangement Form H
Specification ISO9001 Quality Certificate;
HS Code 84089091
Fuel Diesel Engine
Intake Pressure Impulse Supercharged
Piston Movement Reciprocating
Number of Cylinders Multi-Cylinder Machines
Number of Strokes Four-Stroke
Trademark LD
Origin Laiyang, Shandong, China

Product Description:Apply turbo-charged direct injection inter-cooling technology, electrically-controlled high pressure common rail injection system, electric inter-cooled EGR as well as DOC post-processing technology.It's able to control the injection quantity, timing and pressure of fuel injection, as well as control the emission more precisely. Emission standard achievesEuroIV standard smoothly.Additionally it provides the overheat protection, over-speed protection, turbo charger protection and so forth functions;Lower noise and more comfortable driving experience. Since the product promotion has obtained the market and users of praise and recognition.

Technical Features:
1.Apply turbo-charged direct injection inter-cooling technology,electrically-controlled high pressure common rail injection system, electric inter-cooled EGR as well as DOC post-processing technology.
2.Start fast; sufficient power
3.Compact structure; beautiful design
4.Super-low fuel consumption; energy conservation and environmental protection
5.Minor vibration; low noise
Scope of application:Supporting a wide range of light card, micro card, SUV, MPV and other fields.
Product Parameters:

Model No.

K15

K10

3L16CF

4L18CF

4L22CF

4J28F

4J30F

4L30F

Type

Common rail direct injection + Turbo-charged inter-cooling +EGR(inter-cooling) + Post-processing (DOC)

Number of Cylinders

4

3

3

4

4

4

4

4

Bore × Stroke (mm)ke (mm)ke (mm)

76×80.5es;80.5es;80.5

76×80.5es;80.5es;80.5

85×95imes;95imes;95

80×90imes;90imes;90

85×95imes;95imes;95

93×102mes;102mes;102

96×105mes;105mes;105

96×105mes;105mes;105

Total Displacement(L)

1.461

1.095

1.617

1.809

2.156

2.774

3.04

3.04

Rated Power/Rated Rotating Speed (kW)/ (r/min)

45~58/3600

42/3600

42/3200

45/3200

58.8~60/

3200~3600

70/3600

75~90/3200

75/3200

Max. Torque /Rotating Speed (N.m) /(r/min)

140~180/

1800~2400

130/

1800~2400

130/2200

150~170/

2000~2400

187~206/

1800~2600

225/

1600~2400

264~300/2200

264/2200

Full-load Min. Fuel-consume Ratio (g/kW.h)

≤210;210;210

≤210;210;210

≤220;220;220

≤225;225;225

≤220;220;220

≤220;220;220

≤215;215;215

≤218;218;218

Dimension

(mm×mm×mm);mm×mm)es;mm);mm×mm)

567.5×559mes;559mes;559
×636mes;636mes;636

536×610mes;610mes;610
×662mes;662mes;662

730×570mes;570mes;570
×660mes;660mes;660

830×565mes;565mes;565
×630mes;630mes;630

800×620mes;620mes;620
×660mes;660mes;660

781×627mes;627mes;627
×740mes;740mes;740

840×658mes;658mes;658
×720mes;720mes;720

840×658mes;658mes;658
×720mes;720mes;720

Net Weight (kg)

140

120

220

220

255

290

242

242

Emission Standard

EuroIV Standard

EuroIV Standard

EuroIV Standard

EuroIV Standard

EuroIV Standard

EuroIV Standard

EuroIV Standard

EuroIV Standard

Post-processing Mode

DOC

DOC

DOC

DOC

DOC

DOC+DPF,SCR

DOC+DPF,SCR

DOC+DPF,SCR
