Model NO. | CFON600 |
Max Width | No |
Scan Speed | 100 scans/sec |
Usage | Barcode Scanner |
Interface Type | RS232, USB, IEEE |
Optical Resolution | 508dpi |
OS | Android 6.0 |
Memory | 1GB Lpddr RAM, 8GB Nand Flash ROM |
Camera | Rear 8.0m Pixels, Auto Focus, Flashlight |
WiFi | IEEE802.11b/G/N |
Barcode Scanner | 1d/2D Barcode Scanner Optional |
Trademark | Corewise |
Origin | Shenzhen Guangdong |
Type | Laser Scanner |
Kind | Flatbed Scanner |
Scanning Light Source | Laser |
Network Scanning | Support Network |
Scanning Element | Laser |
Application | Commercial Application |
Display | TFT LCD 4', Display Resolution:800*480800*480 |
Touch Screen | Capacitive Touch Screen |
GPS | GPS, Glonass Supported, 10m |
Bluetooth | Bt 4.0 with A2dp |
Frequency | GSM WCDMA CDMA TDS-CDMA Td-Lte:B38/B39/B40/B41 E |
Specification | 160 mm x 70 mm x 24 mm |
Physical Parameter | |||
Design | Bar phone | Keys | twenty eight |
Dimensions (L*W*D) | 160 mm x 70 mm x 24 mm | Weight | 350g |
Function Parameter | |||
Operating System | Android 6.0 | Memory | 1GB RAM,8GB ROM/1GB RAM,4GB ROM |
CPU | Qualcomm 8909, 1.2Ghz, Quad Core | Camera | Rear 8.0M Pixels, Auto Focus with Flash |
Memory and Extension | Micro SD Card, up to 32GB | Networks | GSM: 850/900/1800/1900 |
GPS | GPS,GLONASS supported,10m | WCDMA:B1/B2/B5 | |
Bluetooth | BT4.0 LTE | CDMA: BC0 | |
WIFI | IEEE 802.11b/g/n | TDS-CDMA:B34/B39 | |
Display | 4 inch TFT LCD, Resolution 800*480 | FDD-LTE:B1/B3 | |
Panel | Capacitive touch screen | TD-LTE:B38/B39/B40/B41 | |
Optional Functions | |||
NFC | Optional | ||
Barcode Scanner | |||
1D Linear Scanner : | 1D Linear Scanner : UPC/EAN, Bookland EAN, UCC Coupon Code, ISSN EAN, Code 128, GS1-128, ISBT 128, Code 39, Trioptic Code 39, Code 32, Code 93, Code 11, Interleaved 2of5, Discrete 2of5, Codabar, MSI, Chinese 2of5, Matrix 2of5, Inverse 1D, Korean 3of5, GS1 DataBar, Composite Codes | 2D Imager Scanner: | 2D Imager Scanner: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, Micro QR, QR Inverse, Aztec, Aztec Inverse, US Postnet, US Planet, US Postal, Japan Postal, Australian Postal, Netherlands KIX Code, USPS 4CB/One Code/Intelligent Mail, UPU FICS Postal |
Other Parameter | |||
Battery Pack | 3.7V, 4000mAh | Headphone | Supported, 3.5mm |
USB | Mini- USB 10pin | Speaker | Supported |
Voice Call | Supported | Charging interface | DC 5.5V 1.2A |
Reliability | MTBF no less than 5000 hours | ||
User Environment | |||
Operating Temp | -20ºC~+70ºC~+70ºCrdm;C~+70ºC | Working humidity | <90%RH0%RH |
Storage Temp | -40ºC~+70ºC~+70ºCrdm;C~+70ºC | Storage humidity | 20% ~93%RH(40ºC)rdm;C)rdm;C) |
The atmospheric pressure | 86Kpa~110Kpa | Drop Grade | IP65 |
