UK Perkins 240kw-320kw Diesel Silent Generator Set
bargain
add to cart| Model NO. | P350-P440 |
| Installation Method | Fixed |
| Cooling Method | Water Cooling |
| Speed | HSS |
| Usage | Common Units |
| Excitation Mode | AC Rotating Exciter |
| Engine Model | UK Engine |
| Advantage | Small Size, Large Horsepower, Fuel Efficiency |
| Color | Green or as Need |
| Application Area | Industry, Construction Project, Outdoor Use |
| Specification | ISO8528 |
| HS Code | 85021100 |
| Type | Self-Starting Diesel Generator |
| Stroke | Four Stroke |
| Output Type | AC Three Phase |
| Conditions of Use | Land Use |
| Landuse Type of Unit | Low Noise Automation Type |
| Certificates | ISO9001 |
| Alternator Standard | Bs5000, VDE0530, NEMA Mg1-32, IEC34, IEC60034, as |
| Types | Silent/Trailer/Open/Container/Base Oil Tank |
| Warranty | 1 Year or 1000 Operation Hours |
| Trademark | HONNY POWER |
| Origin | Guangdong, China |
UK Perkins 240kW-320kW Diesel Silent Generator Set
P350EM specifications:
1) Prime: 240kW/300kVA
2) Standby: 280kW/350kVA
3) 2306C-E14TAG1 UK Perkins engine
4) Dimensions (L x W x H): 3, 000 X 1, 000 X 1, 700mm
5) Weight: 3, 240kg
P400EM specifications:
1) Prime: 280kW/350kVA
2) Standby-320kW/400kVA
4) 2306C-E14TAG2 UK Perkins engine
5) Dimensions (L x W x H): 3, 000 X 1, 000 X 1, 700mm
6) Weight: 3, 300kg
P440EM specifications:
1) Prime: 320kW/400kVA
2) Standby 352kW/440kVA
3) 2306C E14TAG3 UK Perkins engine
4) Dimensions (L X W xH): 3, 000 X 1, 000 X 1, 700mm
5) Weight: 3, 350kg
Features:
1) Engine and alternator shall be mounted on a same frame steel skid
2) Built-in damper for anti-vibration
3) Small size, low weight, easy to operate, installation and maintenance
4) World most famous brand diesel engine: UK Perkins 2306 series engine-2306C E14TAG1(2, 3)
5) World famous brand AC alternator: Stamford, Marathon, Leroy Somer
6) Advanced and reliable control module: Key start, auto start, remote control by PC with RS232 / 485
7) Full range protects function and alarm shutdown feature
8) According to professional standards
Alternator features:
1) Brush-less, 4 poles, rotation magnet
2) IP21-23 (NEMA1) enclosure is standard for all industrial alternators
3) The insulation system is class H
4) Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts
5) Wide range of flange adapters and single bearing disc coupling
6) Standard 2/3 pitch windings avoid excessive neutral currents
PMG system (optional):
1) Permanent magnet generator (PMG) system provide constant excitation under all condition
2) Optional accessories available for easy paralleling with mains or other generators
3) AVR auto voltage regulator, auto exciter, auto adjustment
Accessories:
1) Standard accessories: Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, fuel-water separator, operation manual and document
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.
P350EM specifications:
1) Prime: 240kW/300kVA
2) Standby: 280kW/350kVA
3) 2306C-E14TAG1 UK Perkins engine
4) Dimensions (L x W x H): 3, 000 X 1, 000 X 1, 700mm
5) Weight: 3, 240kg
P400EM specifications:
1) Prime: 280kW/350kVA
2) Standby-320kW/400kVA
4) 2306C-E14TAG2 UK Perkins engine
5) Dimensions (L x W x H): 3, 000 X 1, 000 X 1, 700mm
6) Weight: 3, 300kg
P440EM specifications:
1) Prime: 320kW/400kVA
2) Standby 352kW/440kVA
3) 2306C E14TAG3 UK Perkins engine
4) Dimensions (L X W xH): 3, 000 X 1, 000 X 1, 700mm
5) Weight: 3, 350kg
Features:
1) Engine and alternator shall be mounted on a same frame steel skid
2) Built-in damper for anti-vibration
3) Small size, low weight, easy to operate, installation and maintenance
4) World most famous brand diesel engine: UK Perkins 2306 series engine-2306C E14TAG1(2, 3)
5) World famous brand AC alternator: Stamford, Marathon, Leroy Somer
6) Advanced and reliable control module: Key start, auto start, remote control by PC with RS232 / 485
7) Full range protects function and alarm shutdown feature
8) According to professional standards
Alternator features:
1) Brush-less, 4 poles, rotation magnet
2) IP21-23 (NEMA1) enclosure is standard for all industrial alternators
3) The insulation system is class H
4) Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts
5) Wide range of flange adapters and single bearing disc coupling
6) Standard 2/3 pitch windings avoid excessive neutral currents
PMG system (optional):
1) Permanent magnet generator (PMG) system provide constant excitation under all condition
2) Optional accessories available for easy paralleling with mains or other generators
3) AVR auto voltage regulator, auto exciter, auto adjustment
Accessories:
1) Standard accessories: Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, fuel-water separator, operation manual and document
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.
