Product parameters:
Performance and characteristics: LS-35HG 50HG 75HG 100HG (full automatic microcomputer)
1. high quality stainless material
2. handwheel sliding fast-open door structure
3. safety interlocking device
4. computer-controlled automatic cycle set at random sterilization procedure
5. digital display working status, touch buttons
6. over temperature, over pressure automatic protection function
7. steam and water circulation, do not release steam into the outside environment is clean and dry
8. Since the rose seal
9. water protection control
10. Optional drying system
11. sterilization automatic stop when end buzzer warning
12. equipped with double stainless steel basket
Technical parameters:
Technical parameters | LS-35HG | LS-50HG | LS-75HG | LS-100HG |
Sterilization Chamber volume | 35L (φ318×450)mm | 50L (φ340×550)mm | 75L (φ400×600)mm | 100L (φ440×650)mm |
Rated working pressure | 0.22MPa | |||
Rating working temperature | 134 c | |||
Maximum working pressure | 0.23Mpa | |||
Heat uniformity | ≤ ± 1 ℃ | |||
Time selection range | 0~ 99min or 0~ 99hour59 min | |||
Temperature selection range | 0~ 134 c | |||
Power supply voltage | 2.5KW/AC220V.50Hz | 3KW /AC220V.50Hz | 4.5KW /AC220V.50Hz | |
Overall dimension (mm) | 600x410x1030 | 650x410x1140 | 690x470x1140 | 730x510x1270 |
Transport volume (mm) | 730x500x1170 | 730x500x1290 | 760x550x1290 | 820x600x1380 |
Gross/net weight | 96Kg/ 77Kg | 102Kg/ 83Kg | 120Kg/98Kg | 135/110Kg |
