Factory direct supply S-35-24V 35W single output switching power supply 24V output

Factory direct supply S-35-24V 35W single output switching power supply 24V output

5+
35 CNY (5.1USD)
10+
33 CNY (4.81USD)
20+
31 CNY (4.52USD)

add to cart

Product parameters:

  • Brand: Chongqing Ming Wei
  • Model: S-35-24V
  • Type: AC/DC power supplies
  • Modulation mode: pulse-width modulation (PWM)
  • Transistor connector: half-bridge
  • Input voltage: 220
  • Output power: 35
  • Output voltage: 5, 7.5, 12 15 24 30 48
  • Efficiency: 78
  • Load regulation: 1
  • Output current: 1.5A


Low price, high reliability
• 105 ° c output capacitors
• Global AC input voltage
• High efficiency, low working temperature
• Soft-start current, effectively reduce the AC input impact
• Short circuit protection, overload protection
• Small size and light weight
• 100% full-load burning test
• Built-in EMI filter, ripple small
Performance//modelS-35-5S-35-12S-35-15S-35-24
DC output voltage5V12V15V24V
Output voltage tolerance (2)± 2%± 1%± 1%± 1%
Rated output current7A3A2.4A1.5A
Output current range0-7A0-3A0-2.4A0-1.5A
Ripple and noise (3)75mVp-p100mVp-p100mVp-p100mVp-p
Into the line of stability (Note 4)± 0.5%± 0.5%± 0.5%± 0.5%
Load stability (Note 5)± 1%± 0.5%± 0.5%± 0.5%
DC output power35W36W36W36W
Efficiency70%76%78%78%
Adjustable DC voltage range± 10,-5%± 10%± 10%± 10%
Input voltage range85~ 132VAC/170~ 264VAC switch selection
Input current0.85A/115V 0.45A/230V
Impulse currentCold-start current 18A/115V 36A/230V
Leakage current﹤0.5mA/240VAC
Overload protection type105%~ 150% type: FOLDBACK cut output reset: auto recovery
Over voltage protection……
High-temperature protection……
Temperature coefficient± 0.03% (0~ 50 c)
Start up time200ms,100ms,30ms
Shock resistance10~ 500Hz,2G 10min./1 cycle duration 60 minutes, each axis
Pressure resistanceInput/output: 1.5KVAC, type shell: 1.5KVAC, output housing: 0.5KVAC
Isolation resistanceBetween input and output, input and shell, output from the shell: 0500VAC/100M Ohms
Temperature, humidity-10℃~ +60℃, 20%~ 90%RH
Storage temperature, the temperature-20℃~ +85℃,10%~ 95RH
Overall dimensions129*98*38mm CASE: 903
Weight0.4Kgs
Safety standardsMeet the UL1012 requirements
EMC standardsTo meet FCC PART15JCONDUCTION CLASS b
Note: 1, the above test conditions: 230VAC input, rated load, 25 ° c 70% RH. humidity.
2, tolerance: including tolerance, line stability, stability (Note 5).
3, ripple test: 20MHz with A12' twisted, 0.1uF&47uF capacitors for interrupt a short circuit.
4, the incoming line voltage stability test: the minimum voltage to high voltage at full load into line.
5, load stability test: the load is from 0% to 100%.
