Ek200 Standby UPS for Computer Use

Ek200 Standby UPS for Computer Use

100+
19 USD

add to cart
Model NO. EK200
Capacity 240W
Input Frequency 50Hz
Output Frequency 50Hz
Automatic Voltage Adjustment Yes
Dimension 101*279*142mm
Usage Car, Electric Power, Computer, Lighting, Bus, UPS
Discharge Rate Medium Discharge Rate
Electrolyte Acid
Rechargeable Chargeable
Transport Package Export Carton
Origin China
Type Lead-Acid Batteries
Input Voltage Scope 180-270V
Output Voltage Scope 220V
Switching Time Less Than 10ms
Weight 3.6kg
Display Mode LED
Nominal Voltage 12V
Shape Square Battery
Installation Fixed
Trademark EKSI
Specification CE
HS Code 85044020
EK200 series standby UPS is a high-efficient, small-sized, appearance-beautiful, performance-advanced & -reliable 300W (600W) power- uninterrupted 220 volt AC power supply system, which is a high quality electronic product designed specially for the microcomputer systems and the sophisticated electronic equipment users.users.sers.
When the commercial AC power is suddenly interrupted, or a certain frequency voltage is too high or too low Instantaneously, it will be immediately put into the power generation in a ten-thousandth second (10ms) high-speed and continue to provide the power for the load, so that the data and the software programs stored in the microcomputer system unaffected to ensure that the microcomputer and the sophisticated electronic equipment should keep on their operating normally.

Model

EK-205A

EK-206A

EK-210A

Capacity

240W

360W

600W

Input

voltage range

180V-270V

140V-290V

140V-290V

Frequency

50Hz/60Hz

Output

voltage range

220V±10%usmn;10%usmn;10%

Frequency

50Hz±10%usmn;10%usmn;10%

Conversion Time

≤10ms10ms10ms

Automatic voltage regulation

Yes

Appearance Dimension

Net weight

5kg

6.5kg

13.5kg

gross weight

5.5kg

7kg

14kg

Machine size

34*85*14

34*85*14

34*12.5*20

Battery

Model

12V4AH x 1

12V7A x 1

12V7A x 1

Typical recharge time

10-16 hour

Battery Protection

Automatically detect the engine room electrical protective

Standby Time

10-15min

10-15 min

10-30 min

Software interface

Software Interface RS232

NO

Status Display

LED
