| Model NO. | EK206A |
| Usage | UPS, Electric Power, Lighting, Computer |
| Discharge Rate | Medium Discharge Rate |
| Electrolyte | Acid |
| Rechargeable | Chargeable |
| Input Voltage | 12V |
| Frequency | High-Frequency |
| Specification | CE |
| HS Code | 85044020 |
| Type | Lead-Acid Batteries |
| Nominal Voltage | 12V |
| Shape | Square Battery |
| Installation | Fixed |
| Capacity | 360W |
| Output Voltage | 220V |
| Trademark | EKSI |
| Origin | China |
Model | EK-205A | EK-206A | EK-210A | |
Capacity | 240W | 360W | 600W | |
Input | voltage range | 180V-270V | 140V-290V | 140V-290V |
Frequency | 50Hz/60Hz | |||
Output | voltage range | 220V±10%usmn;10%usmn;10% | ||
Frequency | 50Hz±10%usmn;10%usmn;10% | |||
Conversion Time | ≤10ms10ms10ms | |||
Automatic voltage regulation | Yes | |||
Appearance Dimension | Net weight | 5kg | 6.5kg | 13.5kg |
gross weight | 5.5kg | 7kg | 14kg | |
Machine size | 34*85*14 | 34*85*14 | 34*12.5*20 | |
Battery | Model | 12V4AH x 1 | 12V7A x 1 | 12V7A x 1 |
Typical recharge time | 10-16 hour | |||
Battery Protection | Automatically detect the engine room electrical protective | |||
Standby Time | 10-15min | 10-15 min | 10-30 min | |
Software interface | Software Interface RS232 | NO | ||
Status Display | LED | |||
