Features:
High Reliability
l Long-life film capacitors design, inverter design life of 25 years
l Natural cooling, waterproof, anti-dust, excellent anti-corrosion ability
l With positive and negative islanding protection, grid relay redundancy protection, safe and reliable;
l Multi-layer, step software hardware over current, over voltage, over temperature and short circuit protection
l 6 strings fault monitoring, quickly positioning the string faults
Advanced control technology
Multi-level inverters with SPWM and SVPWM double modulation, smooth natural switch
Self-adaptive control, accommodate rough weak grid environment
Current harmonic compensation, grid current harmonic1%
Support reactive and active electric network management and SVG function;
Low voltage ride through function
User friendly and flexible
Multi-language LCD display screen, easy to set multi-operation parameter;
Inbuilt DC SPD and fuse, avoid DC combiner box to decrease user system cost;
Wall-mounted design, whole aluminum molding shell in one time and with DC breaker, safe and easy for maintenance;
Outdoor design with IP65;
More power generation
Transformer-less design;
Max. Conversion efficiency 98.6%, euro efficiency 98.4%;
3 MPP inputs maximize the power generation ability of the shadowed PV module;
Wide MPPT voltage range (320-900V), longer time of daily power generation
Intelligent MPPT algorithm, maximum power point not affected by the sun light change;
Wide working temperature -25~60ºC, continuously generating power in high temperature environment.nment.nment.
Technical specifications
