1. Used switching power technology, with small size, low weight, high efficiency and excellent function.
2. MCU control charging quickly based on all kinds of battery charging curve, check correctly the whole process of the charge and the discharge, ensuring battery full of charge.
3. Protection for over current, over voltage, over temperature, short circuit, battery polarity anti-connected
4. Adjusting voltage automatically according to weather with temperature compensation function, the battery temperature rising is very slight, with pulse charging mode, rehabilitate battery prolonging the service life of the battery
5. Adjust every segment charging max current, bulk or cyclic voltage and float charge time in the operating position.
6. Suitable for 6V, 12V, 24V, 36V, 48V and 72V battery etc.
7. Wide range of output current for option, from 1A to 100A by user.
8. Check automatically battery and its connector status while switch on
9. It is welcome to be designed for charging Ni-MH, Ni-CA and Li-ion Battery
Capacity:
* YMC12-10/12VDC10A
* YMC12-20/12VDC20A
* YMC12-30/12VDC30A
* YMC12-40/12VDC40A
* YMC12-60/12VDC60A
* YMC24-5/24VDC5A
* YMC24-8/24VDC8A
* YMC24-10/24VDC10A
* YMC24-12/24VDC12A
* YMC24-20/24VDC24A
* YMC24-30/24VDC30A
* YMC24-40/24VDC40A
* YMC36-3/36VDC3A
* YMC36-5/36VDC5A
* YMC36-8/36VDC8A
* YMC36-10/36VDC10A
* YMC48-5/48VDC5A
* YMC48-8/48VDC8A
* YMC48-10/48VDC10A
* YMC48-12/48VDC12A
* YMC48-20/48VDC20A
* YMC48-30/48VDC30A
AC input:
* 110V or 220V
Charger Current:
* 1A--40A
Input DC range:
* 6VDC--48VDC.
