Home UPS Line Interactive Design 500-1500va
| Model NO. | 500va-1500va(EW2000) |
| Type | Line Interactive |
| Application | Communication |
| Standby Time | Standard Machine |
| Output Capacity | Large Type |
| Brand | Must |
| AC Brownout Solution | 3-Step AC Voltage Regulation,Wide Input AC Range |
| Home UPS | AVR Line Interactive Design 500va to 1500va |
| Transport Package | Carton Gift Boxes |
| Origin | Shenzhen, China |
| Phase | Single Phase |
| Protection | Input Surge Voltage,Over(Load,Temperature)... |
| Classification | Lighting/Power |
| Standby UPS | Sine Wave Output UPS |
| Equipment Mode | Centralized Model |
| AC Blackout Solution | PWM Tech Inverter and Min 7ah Internal Battery |
| Communication and Power Management | USB + Winpower Shut-Down Software |
| Trademark | Must |
| Specification | CE |
| HS Code | 8504402000 |
Home ups line interactive design 500-1500va with usb communication interface
Feature:
1. Micro-processor intelligent control: Reliability;
2. PWM tech dc-ac inverter functions when ac blackout, provides some time backup from internal battery;
3. PWM inverter and internal battery manages ac-blackout problem;
4. Full ac voltage regulation from 3-step boost/buck avr allow ups work stably in a wide input voltage range
(145-290Vac), avoid battery discharge better, solve ac-brownout problem better;
5. Intelligent battery charge control(3-stage charge), and over-discharge protection/battery low;
6. Convenient usb communication port for easy power management, together with winpower software.
Feature:
1. Micro-processor intelligent control: Reliability;
2. PWM tech dc-ac inverter functions when ac blackout, provides some time backup from internal battery;
3. PWM inverter and internal battery manages ac-blackout problem;
4. Full ac voltage regulation from 3-step boost/buck avr allow ups work stably in a wide input voltage range
(145-290Vac), avoid battery discharge better, solve ac-brownout problem better;
5. Intelligent battery charge control(3-stage charge), and over-discharge protection/battery low;
6. Convenient usb communication port for easy power management, together with winpower software.
| MODEL | EA1000-500 | EA1000-650 | EA1000-800 | EA1000-1000 | |
| CAPACITY | 500VA/300W | 650VA/390W | 800VA/480W | 1000VA/600W | |
| INPUT | |||||
| Voltage | Nominal Voltage | 110/120 VAC or 220/230/240 VAC | |||
| Acceptable Voltage Range | 90-145 VAC/150-290 VAC | ||||
| Frequency Range | 50 /60 Hz | ||||
| OUTPUT | |||||
| AC Voltage Regulation (Batt. Mode) | ±10%usmn;10%usmn;10% | ||||
| Frequency Range (Batt. Mode) | 50 Hz or 60 Hz | ||||
| Transfer Time (Typical) | 2-6 ms | ||||
| Waveform (Batt. Mode) | Modified Sinewave | ||||
| BATTERY | |||||
| Battery Type & Numbersmbersmbers | 12 V 7 Ah x 1 | 12 V 7 Ah x 1 | 12 V 9 Ah x 1 | 12 V 7 Ah x 2 | |
| Back up Time(at a PC load | 8 minuters | 10 minuters | 20 minuters | 20 minuters | |
| Typical Recharge Time | 10 hours to 90% after complete discharge | ||||
| INDICATORS | |||||
| AC Mode | Green LED lighting | ||||
| Battery Mode | Green LED flashing every 4 seconds | ||||
| Low Battery at Battery Mode | Green LED flashing every second | ||||
| Fault | Red LED lighting | ||||
| Battery Fault at AC modes | Green LED flashing three times every 2 seconds | ||||
| Battery Week at AC modes | Red LED flashing every 2 seconds for 30 seconds | ||||
| Overload | Red LED flashing every twice every second | ||||
| ALARM | |||||
| Battery Mode | Sounding every 4 seconds | ||||
| Low Battery | Sounding every second | ||||
| Fault | Continuously sounding | ||||
| PHYSICAL | |||||
| Dimension, D X W X H (mm) | 295*95*140 | ||||
| Net Weight (kgs) | 5.5 | 6.2 | 6.8 | 10.5 | |
| ENVIRONMENT | |||||
| Humidity | 0 to 90% Relative Humidity(Non-condensing) | ||||
| Operating Temperature | 0°Cto 40°C 40°Ceg;C 40°C | ||||
